Pioneer DEH-P545R Manual de usuario
MULTI-CD CONTROL HIGH POWER CD PLAYER WITH RDS TUNER
DEH-P545R X1P/EW
DEH-P544R X1P/EW
DEH-P443R X1P/EW
Se
r
v
i
c
e
M
a
nu
a
l
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880
C PIONEER ELECTRONIC CORPORATION 1998
ORDER NO.
CRT2251
K-ZZA. AUG. 1998 Printed in Japan
-This additional service manual is designed to be used together with Model DEH-P545R/EW, DEH-
P544R/EW and DEH-P443R/EW Service Manual CRT2148. Refer to it for finding parts numbers and
adjustment,etc. which are not shown in this manual.
EXPLODED VIEWS AND PARTS LIST
PACKING(Page 3)
-PACKING SECTION PARTS LIST
* : Non spare part
Part No.
Mark No. Description DEH-P545R/EW DEH-P545R/X1P/EW
2 Accessory Assy CEA1917 UEA1917
3 Screw CBA1284 CBA1304
5 Bush CNV1009 CNV3930
* 6 Polyethylene Bag E36-615 CEG-127
17 Polyethylene Bag CEG-162 UEG-012
18-1 Polyethylene Bag CEG1116 UEG1116
18-2 Owner's Manual CRD2568 URD2568
18-3 Owner's Manual CRD2569 URD2569
18-4 Owner's Manual CRD2570 URD2570
19-1 Polyethylene Bag CEG1116 UEG1116
19-2 Installation Manual CRD2571 URD2571
19-4 Passport CRY1013 *CRY1014
* 19-5 Warranty Card CRY1087 URY1087
21 Carton CHG3440 UHG-106
22 Contain Box CHL3440 UHL-039
2
DEH-P545R,P544R,P443R
* : Non spare part
Part No.
Mark No. Description DEH-P544R/EW DEH-P544R/X1P/EW
2 Accessory Assy CEA1917 UEA1917
3 Screw CBA1284 CBA1304
5 Bush CNV1009 CNV3930
* 6 Polyethylene Bag E36-615 CEG-127
17 Polyethylene Bag CEG-162 UEG-012
18-1 Polyethylene Bag CEG1116 UEG1116
18-5 Owner's Manual CRD2631 URD2631
18-6 Installation Manual CRD2632 URD2632
* 18-9 Warranty Card CRY1087 URY1087
21 Carton CHG3441 UHG-105
22 Contain Box CHL3441 UHL-038
23 Protector CHP1766 UHP1766
24 Protector CHP1767 UHP1767
26 Case Assy CXB1063 UXB1063
* : Non spare part
Part No.
Mark No. Description DEH-P443R/EW DEH-P443R/X1P/EW
2 Accessory Assy CEA1917 UEA1917
3 Screw CBA1284 CBA1304
5 Bush CNV1009 CNV3930
* 6 Polyethylene Bag E36-615 CEG-127
17 Polyethylene Bag CEG-162 UEG-012
18-1 Polyethylene Bag CEG1116 UEG1116
18-5 Owner's Manual CRD2633 URD2633
18-6 Installation Manual CRD2634 URD2634
18-8 Passport CRY1013 *CRY1014
* 18-9 Warranty Card CRY1087 URY1087
21 Carton CHG3442 UHG-104
22 Contain Box CHL3442 UHL-037
23 Protector CHP1766 UHP1766
24 Protector CHP1767 UHP1767
26 Case Assy CXB1063 UXB1063
Part No.
Mark No. Description DEH-P545R/EW DEH-P545R/X1P/EW
23 Protector CHP1766 UHP1766
24 Protector CHP1767 UHP1767
26 Case Assy CXB1063 UXB1063
3
DEH-P545R,P544R,P443R
EXTERIOR(Page 8)
-EXTERIOR SECTION PARTS LIST
Part No.
Mark No. Description DEH-P545R/EW DEH-P545R/X1P/EW
14 Screw CBA1284 CBA1304
16 Bush CNV1009 CNV3930
19 Holder CNC6798 UNC6798
25 Tuner Amp Unit CWM5624 UWM5624
29 Clamper CEF1009(×2) CEF1009(×1)
30 Pin Jack(CN253) CKB1028 CKB1035
48 Case Assy CXB1063 UXB1063
52 Detach Grille Assy CXB1998 UXB1998
68 Keyboard Unit CWM5638 UWM5638
70 Cord CDE5665 UDE5665
81 Button CAC5180 CAC4836
89 Arm CNV4951 CNV4728
93 CD Mechanism Module CXK5004 UXK5004
Part No.
Mark No. Description DEH-P544R/EW DEH-P544R/X1P/EW
14 Screw CBA1284 CBA1304
16 Bush CNV1009 CNV3930
19 Holder CNC6798 UNC6798
25 Tuner Amp Unit CWM5624 UWM5624
29 Clamper CEF1009(×2) CEF1009(×1)
30 Pin Jack(CN253) CKB1028 CKB1035
48 Case Assy CXB1063 UXB1063
52 Detach Grille Assy CXB1999 UXB1999
68 Keyboard Unit CWM5639 UWM5639
70 Cord CDE5665 UDE5665
81 Button CAC5180 CAC4836
89 Arm CNV4951 CNV4728
93 CD Mechanism Module CXK5004 UXK5004
Part No.
Mark No. Description DEH-P443R/EW DEH-P443R/X1P/EW
14 Screw CBA1284 CBA1304
16 Bush CNV1009 CNV3930
19 Holder CNC6798 UNC6798
25 Tuner Amp Unit CWM5621 UWM5621
48 Case Assy CXB1063 UXB1063
52 Detach Grille Assy CXB2002 UXB2002
68 Keyboard Unit CWM5635 UWM5635
70 Cord CDE5665 UDE5665
81 Button CAC5180 CAC4836
89 Arm CNV4951 CNV4728
93 CD Mechanism Module CXK5004 UXK5004
94 IC(IC201) TDA7384 TDA7384A
DEH-P545R,P544R,P443R
ELECTRICAL PARTS LIST(Page 50)
TUNER AMP UNIT
Part No.
DEH-P545R/EW DEH-P545R/X1P/EW
Circuit Symbol and No. Part Name DEH-P544R/EW DEH-P544R/X1P/EW
IC 731 IC PMW001B PM4006B
Q 101, 801 Chip Transistor 2SA1162 2SA1037K
Q 501, 806, 923, 957 Transistor 2SC2712 2SC2412K
Q 851 Chip Transistor 2SA1162 2SA1037K
D 501 Diode MA152WK DAN202K
D 901, 902, 911, 922 Diode ERA15-02VH 1SR139-400
D 931, 932 Diode ERA15-02VH 1SR139-400
C 501, 502 CCSQCH150K50 CCSQCH150J50
C 514 CKSQYB473K16 CKSQYB473K25
C 532 CKSQYB473K16 CKSQYB473K25
Part No.
Circuit Symbol and No. Part Name DEH-P443R/EW DEH-P443R/X1P/EW
IC 201 IC TDA7384 TDA7384A
IC 731 IC PMW001B PM4006B
Q 101, 801 Chip Transistor 2SA1162 2SA1037K
Q 501, 806, 923, 957 Transistor 2SC2712 2SC2412K
C 501, 502 CCSQCH150K50 CCSQCH150J50
C 532 CKSQYB473K16 CKSQYB473K25
CONTROL UNIT
Part No.
DEH-P545R/EW DEH-P545R/X1P/EW
DEH-P544R/EW DEH-P544R/X1P/EW
Circuit Symbol and No. Part Name DEH-P443R/EW DEH-P443R/X1P/EW
C 102, 122, 124 CKSQYB104K16 CKSQYB104K25
C 110, 202, 203, 602 CKSQYB104K16 CKSQYB104K25
C 112 CKSQYB473K16 CKSQYB473K25
CD MECHANISM MODULE(Page 12)
-CD MECHANISM MODULE SECTION PARTS LIST
Part No.
DEH-P545R/EW DEH-P545R/X1P/EW
DEH-P544R/EW DEH-P544R/X1P/EW
Mark No. Description DEH-P443R/EW DEH-P443R/X1P/EW
1 Control Unit CWX2285 UWX2224
