Pioneer KEH-P2276ZFA Manual de usuario

PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.

PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880

C PIONEER ELECTRONIC CORPORATION 1998 K-ZZB. AUG. 1998 Printed in Japan

ORDER NO.

CRT2248

MULTI-CD CONTROL HIGH POWER CASSETTE PLAYER WITH RDS TUNER

KEH-P2276ZFA X1BEW

- This additional service manual is designed to be used together with Model KEH-P4530R/X1M/EW

Service Manual CRT2084. Refer to it for finding parts numbers and adjustment,etc. which are not

shown in this manual.

VEHICLE DESTINATION PRODUCED AFTER PART No. ID No. PIONEER MODEL No.

FIAT 600 EUROPE December 1998 F-P6004R KEH-P2276ZFA/X1BEW

FIAT

KEH-P2276ZFA

ELECTRICAL PARTS LIST(Page 42)

Tuner Amp Unit

Part No.

Symbol and Description KEH-P4530R/X1M/EW KEH-P2276ZFA/X1BEW

C311 CKSYB224K16 CKSYB224K25

C705 CKSYB104K16 CKSYB104K50

Keyboard Unit

Part No.

Symbol and Description KEH-P4530R/X1M/EW KEH-P2276ZFA/X1BEW

D903 QLMJ-P014 (LED) BG2222S-B1 (Diode)

IL901,902 Lump 14V 40mA CEL1477 CEL1578

IL903,904,905 Lump 14V 40mA CEL1508 CEL1579

EXPLODED VIEWS AND PARTS LIST

PACKING (Page 3)

-PACKING SECTION PARTS LIST *: Non Spare Part

Part No.

Mark No. Description KEH-P4530R/X1M/EW KEH-P2276ZFA/X1BEW

1 Carton CHG3354 UHG-097

2-1 Owner's Manual CRD2495 URD-069

2-2 Owner's Manual CRD2496 URD-070

2-3 Owner's Manual CRD2497 URD-071

2-4 Installation Manual CRD2498 URD-072

* 2-5 Warranty Card CRY1087 URY1087

* 2-6 Passport CRY1013 CRY1014

3 Polyethylene Bag CEG-162 UEG-012

4 Protector CHP1622 UHP1622

5 Protector CHP1623 UHP1623

6 Case Assy CXB1063 UXB1063

8 Accessory Assy CEA1917 UEA1917

9 Contain Box CHL3354 UHL-030

* Caution Card Not used URP-002

-Accessory Assy

CEA1917 UEA1917

* Polyethylene Bag E36-615 CEG-127

EXTERIOR (Page 4)

-EXTERIOR SECTION PARTS LIST

Part No.

Mark No. Description KEH-P4530R/X1M/EW KEH-P2276ZFA/X1BEW

6 Holder Unit CXB2687 CNC5394(Holder)

16 Tuner Amp Unit CWM5653 UWM5653

37 Detach Grille Assy CXB2033 UXB-006

52 Keyboard Unit CWM5657 UWM-015

59 Grille Unit CXB2328 UXB-008

69 Panel Unit CXB2485 UXA-039

73 Case Assy CXB1063 UXB1063

* Cover Not used CNM5906
