Pioneer DEH-P4400R Manual de usuario

English Español Deutsch Français Italiano Nederlands

Multi-CD control High power CD player

with RDS tuner

Operation Manual

DEH-P4400R

DEH-P4400RB

Before You Start

About this unit 4

About this manual 4

Precautions 4

In case of trouble 4

Protecting your unit from theft 4

• Removing the front panel 5

• Attaching the front panel 5

What’s What 6

• Head unit 6

• Optional remote control 7

• Using the remote control with PGM

button 7

Power ON/OFF

Turning the unit on 8

Selecting a source 8

Turning the unit off 8

Tuner

Listening to the radio 9

Introduction of advanced tuner

operation 10

Storing and recalling broadcast

frequencies 11

Tuning in strong signals 11

Storing the strongest broadcast

frequencies 12

RDS

Introduction of RDS operation 13

Switching the RDS display 14

Selecting alternative frequencies 14

• Using PI seek 14

• Using auto PI seek for preset

stations 15

• Limiting stations to regional program-

ming 15

Receiving traffic announcements 15

• Responding to the TP alarm 16

Using PTY functions 16

• Using news program interruption 16

• Receiving PTY alarm broadcasts 16

PTY list 17

Built-in CD Player

Playing a CD 18

Introduction of advanced built-in CD

player operation 19

Repeating play 19

Playing tracks in a random order 19

Scanning tracks of a CD 20

Pausing CD playback 20

Using disc title functions 20

• Entering disc titles 20

• Displaying disc titles 21

Multi-CD Player

Playing a CD 22

50-disc multi-CD player 22

Introduction of advanced multi-CD player

operation 23

Repeating play 23

Playing tracks in a random order 24

Scanning CDs and tracks 24

Pausing CD playback 24

Using ITS playlists 25

• Creating a playlist with ITS program-

ming 25

• Playback from your ITS playlist 25

• Erasing a track from your ITS

playlist 26

• Erasing a CD from your ITS playlist 26

Using disc title functions 26

• Entering disc titles 26

• Displaying disc titles 27

• Selecting discs from the disc

title list 28

Thank you for buying this Pioneer product.

Please read through these operating instructions so you will know how to oper-

ate your model properly. After you have finished reading the instructions, put them

away in a safe place for future reference.

Contents

Section

Using CD TEXT functions 28

• Displaying titles on CD TEXT discs 28

• Scrolling titles in the display 28

Using compression and bass emphasis 29

Audio Adjustments

Introduction of audio adjustments 30

Setting the sound focus equalizer 31

Using balance adjustment 31

Using the equalizer 32

• Recalling equalizer curves 32

• Adjusting equalizer curves 32

• Equalizer curve fine adjustment 33

Adjusting bass 33

Adjusting treble 34

Adjusting loudness 34

Using subwoofer output 34

• Adjusting subwoofer settings 35

Adjusting source levels 35

Initial Settings

Adjusting initial settings 36

Setting the FM tuning step 36

Switching auto PI seek 36

Switching the warning tone 37

Switching the auxiliary setting 37

Switching the dimmer setting 37

Switching the rear output setting 37

Switching the handsfree telephoning 38

Switching the telephone

muting/attenuation 38

Switching the telephone standby 38

Other Functions

Using the AUX source 39

• Selecting AUX as the source 39

• Setting the AUX title 39

Using the telephone muting/attenuation

and handsfree telephoning function 40

• Telephone muting/attenuation

function 40

• Handsfree telephoning function 40

Additional Information

CD player and care 41

CD-R/CD-RW discs 41

Understanding built-in CD player error

messages 42

Specifications 43

Contents

En 3

English Español Deutsch Français Italiano Nederlands

Section

Before You Start

About this unit

The tuner frequencies on this unit are allocated

for use in Western Europe, Asia, the Middle

East, Africa and Oceania. Use in other areas

may result in improper reception. The RDS func-

tion operates only in areas with FM stations

broadcasting RDS signals.

About this manual

This unit features a number of sophisticated

functions ensuring superior reception and oper-

ation. All the functions have been designed for

the easiest possible use, but many are not self-

explanatory. This operation manual will help you

benefit fully from this product’s potential and to

maximize your listening enjoyment.

We recommend that you familiarize yourself

with the functions and their operation by read-

ing through the manual before you begin using

this unit. It is especially important that you read

and observe precautions on this page and in

other sections.

This manual explains head unit operation. You

can perform the same operations with the steer-

ing remote control (sold separately).

Precautions

•ACLASS 1 LASER PRODUCT label is affixed

to the bottom of this unit.

• The Pioneer CarStereo-Pass is for use only in

Germany.

• Keep this manual handy as a reference for

operating procedures and precautions.

• Always keep the volume low enough so you

can hear sounds outside of the car.

• Protect this product from moisture.

• If the battery is disconnected or discharged,

the preset memory will be erased and must be

reprogrammed.

In case of trouble

Should this product fail to operate properly,

contact your dealer or nearest authorized

Pioneer Service Station.

Protecting your unit from theft

The front panel can be detached from the head

unit and stored in the protective case provided

to discourage theft.

• If the front panel is not detached from the

head unit within five seconds of turning off

the ignition, a warning tone will sound.

• You can turn off the warning tone. See

Switching the warning tone on page 37.

Important

• Never use force or grip the display and the

buttons tightly when removing or attaching.

• Avoid subjecting the front panel to excessive

shocks.

• Keep the front panel out of direct sunlight and

high temperatures.

CLASS 1

LASER PRODUCT

This product complies with the EMC

Directives (89/336/EEC, 92/31/EEC) and

CE Marking Directive (93/68/EEC).

Section

Before You Start

En 5

English Español Deutsch Français Italiano Nederlands

Removing the front panel

1 Press OPEN to open the front panel.

2 Grip the left side of the front panel and pull

it gently outward.

Take care not to grip it tightly or drop it.

3 Put the front panel into the protective case

provided for safe keeping.

Attaching the front panel

Replace the front panel by holding it upright

to this unit and clipping it securely into the

mounting hooks.

Section

Before You Start

What’s What

Head unit

1DISPLAY button

Press to select different displays.

2FUNCTION button

Press to select functions.

3OPEN button

Press to open the front panel.

4AUDIO button

Press to select various sound quality con-

trols.

55/∞/2/3buttons

Press to do manual seek tuning, fast for-

ward, reverse and track search controls. Also

used for controlling functions.

6SFEQ button

Press to select a natural sound with pres-

ence.

7BAND/ESC button

Press to select among three FM or MW/LW

bands and cancel the control mode of func-

tions.

81–6 (PRESET TUNING) buttons

Press for preset tuning and disc number

search when using a multi-CD player.

9SOURCE button

This unit is switched on by selecting a

source. Press to cycle through all of the

available sources.

0EQ button

Press to select various equalizer curves.

-VOLUME button

When you press VOLUME, it extends outward

so that it becomes easier to turn.

To retract the VOLUME, press it again.

Rotate to increase or decrease the volume.

=TA button

Press to switch traffic announcements func-

tion on or off.

SELECT

AUDIO

EQ SFEQ

!2 qwe

!0 u

Section

Before You Start

En 7

English Español Deutsch Français Italiano Nederlands

Optional remote control

The steering remote control CD-SR80 is sold

separately. Operation is the same as when

using the button on the head unit. See the

explanation of the head unit about the operation

of each button with the exception of ATT, which

is explained below.

~ATT button

Press to quickly lower the volume level, by

about 90%. Press once more to return to the

original volume level.

!VOLUME button

Press to increase or decrease the volume.

Using the remote control with PGM

button

The remote control CD-R600, which is sold sep-

arately, can also operate this unit. It has a PGM

(program) button in which frequently used func-

tions are preprogrammed for each source.

Press PGM to active functions as follows:

Source Function name Page

Tuner BSM (on/off) 12

(Hold for 2 seconds)

Built-in CD player Pause (on/off) 20

Multi-CD player Pause (on/off) 24

TV BSSM (on/off)

(Hold for 2 seconds)

Note

• For the details of TV functions refer to the TV’s

manual.

Section

Power ON/OFF

Turning the unit on

Press SOURCE to turn the unit on.

When you select a source the unit is turned on.

Selecting a source

You can select a source you want to listen to. To

switch to the built-in CD player, load a disc in

this unit (refer to page 18).

Press SOURCE to select a source.

Press SOURCE repeatedly to switch between

the following sources:

Built-in CD player—TV—Tuner—Multi-CD

player—External unit—AUX—Telephone standby

Notes

• In the following cases, the sound source will

not change:

— When a product corresponding to each

source is not connected to this unit.

— When no disc is set in this unit.

— When no magazine is set in the multi-CD

player.

— When the AUX (auxiliary) is set to off (refer

to page 37).

— When the telephone standby is set to OFF

(refer to page 38).

• External unit refers to a Pioneer product (such

as one available in the future) that, although

incompatible as a source, enables control of

basic functions by this unit. Only one external

unit can be controlled by this unit.

• When this unit’s blue/white lead is connected

to the car’s auto-antenna relay control termi-

nal, the car’s antenna extends when this

unit’s source is switched on. To retract the

antenna, switch the source off.

Turning the unit off

Press SOURCE and hold for at least one sec-

ond to turn the unit off.

Section

Tuner

En 9

English Español Deutsch Français Italiano Nederlands

Listening to the radio

These are the basic steps necessary to operate

the radio. More advanced tuner operation is

explained starting on page 10.

This unit’s AF (alternative frequencies search)

function can be switched on and off. AF should

be off for normal tuning operation (refer to page

14).

1BAND indicator

Shows which band the radio is tuned to, MW,

LW or FM.

2FREQUENCY indicator

Shows to which frequency the tuner is

tuned.

3PRESET NUMBER indicator

Shows what preset has been selected.

4STEREO () indicator

Shows that the frequency selected is being

broadcast in stereo.

1 Press SOURCE to select the tuner.

2UseVOLUME to adjust the sound level.

Rotate to increase or decrease the volume.

3 Press BAND/ESC to select a band.

Press BAND/ESC until the desired band is dis-

played, F1, F2, F3 for FM or MW/LW.

4 To perform manual tuning, press 2or 3

with quick presses.

The frequencies move up or down step by step.

5 To perform seek tuning, press and hold 2

or 3for about one second and release.

The tuner will scan the frequencies until a

broadcast strong enough for good reception is

found.

• You can cancel seek tuning by pressing either

2or 3with a quick press.

• If you press and hold 2or 3you can skip

broadcasting stations. Seek tuning starts as

soon as you release the buttons.

Note

• When the frequency selected is being broad-

cast in stereo the STEREO ()indicator will

light.

142

Section

Tuner

Introduction of advanced tuner

operation

1FUNCTION display

Shows the function status.

2PRESET NUMBER indicator

Shows what preset has been selected.

Press FUNCTION to display the function

names.

Press FUNCTION repeatedly to switch between

the following functions:

BSM (best stations memory)—REG (regional)—

LOCAL (local seek tuning)—TA (traffic

announcement standby)—NEWS (news pro-

gram interruption)—AF (alternative frequencies

search)

• To return to the frequency display, press

BAND/ESC.

• If MW/LW band is selected, you can only

select BSM or LOCAL.

Note

• If you do not operate the function within about

30 seconds, the display is automatically

returned to the frequency display.

Otros manuales para DEH-P4400R

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Receptor de coche de Pioneer

Pioneer

Pioneer DEH-X4900BT Manual de usuario

Pioneer

Pioneer KEH-P8010R Manual de usuario

Pioneer

Pioneer DEH-P8300UB Manual de usuario

Pioneer

Pioneer DEH-X1810UB/XNUC Manual de usuario

Pioneer

Pioneer MVH-X385BT Manual de usuario

Pioneer

Pioneer DEH-S1100UB Manual de usuario

Pioneer

Pioneer DEH-X36UI/XNUC Manual de usuario

Pioneer

Pioneer XV-HTD7 Manual de usuario

Pioneer

Pioneer AVIC-8000NEX Manual de usuario

Pioneer

Pioneer DEH 2800MP - Radio / CD Manual de usuario

Pioneer

Pioneer SUPER TUNER IIID DEH-1900MP Manual de usuario

Pioneer

Pioneer AVIC-88DVD - Navigation System With DVD-ROM Manual de usuario

Pioneer

Pioneer DEH-P3500MP Manual de usuario

Pioneer

Pioneer DEH-3850MP Manual de usuario

Pioneer

Pioneer DEH-X3600S Manual de usuario

Pioneer

Pioneer CDX-FM1287 - CD Changer Manual de usuario

Pioneer

Pioneer DEH-P4100UB Manual de usuario

Pioneer

Pioneer KP-007 Manual de usuario

Pioneer

Pioneer DEH-S1153UB Manual de usuario

Pioneer

Pioneer DEH-P4900IB - Radio / CD Manual de usuario

Pioneer

Pioneer Super Tuner IIID DEH-P6900UB Manual de usuario

Pioneer

Pioneer DEH-P3700MP - Radio / CD Manual de usuario

Pioneer

Pioneer DEH-8450BT Manual de usuario

Pioneer

Pioneer DEH2950P Manual de usuario

Manuales populares de Receptor de coche de otras marcas

Motorola

Motorola VWA63 Manual de usuario

Nextar

Nextar D3201 Manual de usuario

Alpine

Alpine CDE-163BT Manual de usuario

Axxera

Axxera XDMA7600 Instrucciones de funcionamiento

XM OnyX Manual de usuario

Sound Storm

Sound Storm STM93R Manual de usuario

Soundstream

Soundstream VIR-5000 Manual de usuario

Avson

Avson MKT Platform Manual de usuario

Sony

Sony MEX-1HD - Audio Library System Manual de usuario

JVC

JVC KD-AHD69 Manual de usuario

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manual de usuario

Sony

Sony CDX-4160 - Cd Receiver Manual de usuario

XFIRE AUDIO

XFIRE AUDIO BMW42S Manual de usuario

VDO

VDO CD 2253 Manual de usuario

Volvo

Volvo 13 84 580 Manual de usuario

ZENEC

ZENEC ZE-160DVD Manual de usuario

Medion

Medion Car Audio Manual de usuario

Philips

Philips CEM5000 Manual de usuario
