Pickering 40-884B Manual de usuario
Page (II) PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering
Page (II) REED RELAY MODULE 40-110/115/120/125
pickering
© COPYRIGHT (2021) PICKERING INTERFACES. ALL RIGHTS RESERVED.
No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by
any means without the written permission of Pickering Interfaces.
Technical details contained within this publication are subject to change without notice.
ISO 9001
Reg No. FM38792
Page (III)
PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering
Page (III)
REED RELAY MODULE 40-110/115/120/125
pickering
TECHNICAL SUPPORT
For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.
WARRANTY
All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of
three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be
defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.
Products serviced and repaired outside of the warranty period are warranted for ninety days.
Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.
ENVIRONMENTAL POLICY
Pickering Interfaces operates under an environmental management system similar to ISO 14001.
Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the
environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and
safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can
be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.
Worldwide Technical Support and Product Information
pickeringtest.com
Germany
Tel: +49 89 125 953 160
E-mail: [email protected]
Sweden
Tel: +46 340-69 06 69
E-mail: [email protected]
USA
Tel: (West) +1 541 471 0700
Tel: (East) +1 781 897 1710
E-mail: [email protected]
Czech Republic
Tel: +420 558 987 613
E-mail: [email protected]
France
Tel +33 9 72 58 77 00
E-mail [email protected]
Pickering Interfaces Headquarters
Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom
Tel: +44 (0)1255-687900
E-Mail: [email protected]
China
Tel: +86 4008 799 765
E-mail: [email protected]
Page (IV) PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering
Page (IV) REED RELAY MODULE 40-110/115/120/125
pickering
MEANING / DESCRIPTION SYMBOL
PROTECTIVE EARTH (GROUND)
To identify any terminal which is intended for connection to an external conductor for
protection against electric shock in case of a fault, or the terminal of a protective earth
(ground) electrode.
DANGEROUS VOLTAGE
To indicate hazards arising from dangerous voltages.
WARNING / CAUTION
An appropriate safety instruction should be followed or caution to a potential hazard
exists.
Refer to the relevant instructions detailed within the product manual.
HEAVY
If this product is heavy reference should be made to the safety instructions for
provisions of lifting and moving.
STATIC SENSITIVE
To indicate that static sensitive devices are present and handling precautions should
be followed.
!
kg
SAFETY SYMBOLS
PRODUCT SAFETY
The following safety symbols may be used on the product and throughout the product documentation.
Page (V)
PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering
Copyright Statement ...................................................................II
Technical Support and Warranty................................................III
Product Safety .............................................................................IV
Contents (this page)....................................................................V
Warnings and Cautions ..............................................................VII
Section 1
Technical Specication...............................................................1.1
Section 2
Technical Description .................................................................2.1
Functional Description..........................................................2.1
Section 3
Installation....................................................................................3.1
Pre Operation Checks...........................................................3.1
Hardware Installation ............................................................3.2
Software Installation .............................................................3.2
Testing Operation ..................................................................3.3
Section 4
Programming Guide....................................................................4.1
Programming Options For Pickering PXI/PXIe Modules ...4.1
Matrix Module Architecture ..................................................4.2
Programming The Matrix Module.........................................4.3
Section 5
Connector Information................................................................5.1
Section 6
Trouble Shooting .........................................................................6.1
Section 7
Maintenance Information............................................................7.1
CONTENTS
Page (VI) PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering
THIS PAGE INTENTIONALLY BLANK
Page (VII)
PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering
Page (VII)
REED RELAY MODULE 40-110/115/120/125
pickering
WARNINGS AND CAUTIONS
WARNING - HAZARDOUS ENVIRONMENTS SYMBOL
atmospheres. If the product is to be used in hazardous environments we recommend that the user
ensures suitable protective measures are taken.
!
WARNING - DANGER OF ELECTRIC SHOCK SYMBOL
This module may contain hazardous voltages. Before removing the module from the rack remove all
supplies and disconnect user I/O signals.
Unused slots in the host chassis are populated with blanking plates to prevent access to user
I/O signals that may be present. Blanking panels are available to order from Pickering in a variety
of slot widths. If the product is not used in this manner for example by using an extender card then
additional care must be taken to avoid contact with exposed signals.
CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL
Certain semiconductor devices used in this equipment are liable to damage due to static voltage.
Observe the following precautions when handling these devices in their unterminated state, or
sub-assemblies containing these devices:
1. Persons removing sub-assemblies from equipment using these devices must be earthed by a
wrist strap and a resistor at the point provided on the equipment.
2. Soldering irons used during the repair operations must be low voltage types with earthed tips and
isolated from the mains voltage by a double insulated transformer.
3. Outer clothing worn must be unable to generate static charges.
4.
anti-static bags.
CAUTION - PRODUCT DOCUMENTATION SYMBOL
and understood before attempting to install or operate the product.
!
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O
signals (refer to the Maintenance Section).
• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or
the combined weight of the modules & chassis.
• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the
chassis and the user I/O signals.
• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.
• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on
the front of the unit.
Page (VIII) PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering
THIS PAGE INTENTIONALLY BLANK
Page 1.1
PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering SECTION 1 - TECHNICAL SPECIFICATION
SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
PXI/PXI 50 Ω 4x4 Terminated 8 GHz Matrix 40/42-884B
ISSUE 1.0 FEB 2021
yAvailable as PXI or PXIe Module
yWide Frequency Range 10 MHz to 8 GHz
yHigh Performance Solid State Switch
y4x4 Matrix
yAutomatic Termination
y+30 dBm Input Power Handling
yExcellent Crosstalk & Isolation
yCompact 3 Slot Form Factor
yFast Operating Speed
yLong Servce Life
ySMA Coaxial Connectors
yVISA, IVI & Kernel Drivers Supplied for Windows
yPXI Version Supported in PXI or LXI Chassis
y3 Year Warranty
X1
X2
X3
X4
50Ω
50Ω
50Ω
50Ω
Y1
Y2
Y3
Y4
50Ω
50Ω
50Ω
50Ω RF 4x4 Matrix
40/42-884B-001 4x4 Terminated 8 GHz
Matrix Simplified Functional Diagram
The 40-884B (PXI) and 42-884B (PXIe) are all solid state
microwave matrices which can operate beyond 8 GHz and
handle RF power to +30 dBm. The matrix can support up 4
point to point connections at the same time.
An innovative construction method ensures the 40/42-
884B provides a compact 3 slot solution with excellent RF
performance. A 4x4 matrix allows concurrent testing of up
to 4 devices with 4 different sets of test equipment. This
improves speed of test in RF systems and makes efficient
use of expensive test equipment.
The design has high isolation between selected paths,
ensuring a high degree of independence in test processes.
Fast operating speed reduces the time taken in setting
switches for the following test. With the ability to handle
signals up to +30 dBm and an IP3 of typically +60 dBm
the module can switch signals with levels found in most
applications without introducing appreciable distortion.
RF connections are made via SMA connectors ensuring
cabling maintains the high performance of the matrix.
The 40/42-884B is supplied with drivers that allow support
in all popular software environments. The PXI version
can also be supported in all Pickering’s LXI Modular
Switching chassis, allowing the use of a PXI or LAN
controlled switching solution with the same high levels of
performance.
Page 1.2 PXI/PXIe 50Ω 4x4 Terminated 8GHz Matrix 40/42-884B
pickering
SECTION 1 - TECHNICAL SPECIFICATION
4x4 Terminated 8 GHz Matrix, 40/42-884B
pickeringtest.com
Specifications
Insertion loss for 40/42-884B-001
for all matrix paths up to 8.5 GHz
VSWR for 40/42-884B-001
for X to Y paths up to 8.5 GHz
VSWR for 40/42-884B-001
for Y to X paths up to 8.5 GHz
Crosstalk for 40/42-884B-001
for adjacent paths up to 8.5 GHz
Isolation for 40/42-884B-001
no path selected up to 8.5 GHz
