PHONIC CORPORATIONES 153 SERVICE MANUAL
Page 2
ES 153 SERVICE MANUALPHONIC CORPORATION Page 3
CONTENTS
PANEL LAYOUT ......................................................................................................... 3
POWER SUPPLY........................................................................................................ 4
BOM ............................................................................................................................ 5
MISCELLANEOUS ITEMS ......................................................................................... 5
WOOD CASE-PART LIST .......................................................................................... 6
PAGE
PHONIC CORPORATIONES 153 SERVICE MANUAL
Page 2
ES 153 SERVICE MANUALPHONIC CORPORATION Page 3
PANEL LAYOUT
PHONIC CORPORATIONES 153 SERVICE MANUAL
Page 4 ES 153 SERVICE MANUALPHONIC CORPORATION Page 5
Ref. Phonic Part No. Specications
POWER SUPPLY
PHONIC CORPORATIONES 153 SERVICE MANUAL
Page 4 ES 153 SERVICE MANUALPHONIC CORPORATION Page 5
Ref. Phonic Part No. Specications
MISCELLANEOUS ITEMS
BOM
R1.2 003-13078-602-0 CEMENT RES. 13 J 30W
R4 003-2008B-601-0 CEMENT RES. 2ohm 25W J AL
R3 003-2508B-601-0 CEMENT RES. 2.5ohm 25W J AL
C4 051-10534-050-0 M.P/C 1UF 250V J MKP -25__85
C3 051-10634-150-0 M.P/C 10UF 250V J MKP -25__85
C5 051-30534-050-0 M.P/C 3UF 250V J MKP -25__85
C1 051-40634-050-0 M.P/C 40UF 250V J SPIRIT -25__85
C2 051-47634-050-0 M.P/C 47UF 250V J SPIRIT -25__85
L3 075-12011-000-0 INDUCTANCE 1.2mH J L=1.0mm
L2 075-28011-000-0 INDUCTANCE 2.8mH J L=1.2mm
L1 075-35011-000-0 INDUCTANCE 3.5mH J L=1.2mm
L4 075-50001-000-0 INDUCTANCE 0.5mH J L=1.0mm
211-01602-000-0 JACK D6.3mm BJ12-2 1/4”
211-03400-021-0 SPEAKON/J SVP563S-CH
211-13000-700-0 LAMP JACK D17*10t PH=5mm
262-24000-700-0 LAMP 24V/75W
290-70026-001-0 ES153 PCB 233*190*1.6
290-70215-000-0 ES153 108*87*1.6
321-00000-020-0 CABLE TIE 140MM
WOOFER 380-60200-000-0 WIRE.UL1015#16 L=550 2*205#PIN RED/BLK
MID SPK. 380-60250-000-0 WIRE.UL1015#16 L=800 2*205# PIN BRO/GRE
TWEETER 380-60260-000-0 WIRE.UL1015#16 L=700 2*205# PIN YEL/BLU
380-60270-000-0 WIRE.UL1015#14 L=600 ORANGE
380-60280-000-0 WIRE.UL1015#14 L=600 WHT
552-60032-500-0 140*160*2t ES153
552-60029-500-F TERMAINAL PANEL ES153
JACK*4 590-03012-200-0 M/E FLT SCR. M3.0*12 BLK D=5.6mm
BOSS*4 590-53008-200-0 M/E SET SCR. M3.0*8 D=6 BLK
592-54020-200-0 W/O SET D4*20 BLK
600-00302-210-0 HEX. NUT M3.0*2.2 NI
600-00822-000-0 HEX.NUT M9*12*2 NI
615-70006-630-0 BOSS M3*5*27.5
633-70001-000-0 RUBBER 25*25*5t BLK
PHONIC CORPORATIONES 153 SERVICE MANUAL
Page 6
Ref. Phonic Part No. Specications
ES 153 SERVICE MANUALPHONIC CORPORATION Page 7
Ref. Phonic Part No. Specications
WOOD CASE-PART LIST
000-00112-003-0 60MM*33Y
321-00000-020-0 CABLE TIE 140MM
341-00807-700-0 MID SPK. 8” 8R 300W
341-01801-001-0 SPK. 1 3/4” 8R 100W
341-15003-000-0 WOOFER 15” 8R 300W ES152/252/153/ESM152
512-20680-010-0 LOGO PANEL ES-II 58*90*0.3t
512-20690-090-0 LOGO PANEL 56*39.5*3t ES-II
524-20010-010-0 HANDLE 56*180 3.6mm
525-60018-010-0 FEET D38*D5*10t BLK
528-70018-000-0 NET 726*451*1t BLK
552-20078-420-0 HANDEL (外框) 181*220*4.5t ABS BLK
560-70061-000-0 CARTON 914H*654.5L*517.5W K=A ES153
562-70063-000-0 TOP/BOT PULP 636(375.5)*486*60 A=A
562-70064-000-0 FRONT PULP 558*774*30 A=A
562-70065-000-0 REAR PULP 774*314*30 A=A
562-70066-000-0 L/R PULP 495*774*30 A=A
566-70021-000-0 45’*50Y*40t 18kg/m
568-00003-000-0 #10 240*340*0.05
568-70019-000-0 PE BAG 960*1300*0.1t 打6孔
572-00000-050-0 DRYER 5g
573-20421-030-0 LABEL 8.9*93.4*1.3 PVC ESV.2
BOM
PHONIC CORPORATIONES 153 SERVICE MANUAL
Page 6
Ref. Phonic Part No. Specications
ES 153 SERVICE MANUALPHONIC CORPORATION Page 7
Ref. Phonic Part No. Specications
573-60240-000-0 BAR CODE LABEL PHONIC
574-00ES1-110-0 OWN.MANU. ES-series V.3
HANDLE*8 590-05035-200-0 M/E FLT M5*35 D8.5 BLK
590-06030-200-0 M/E FLT SCR. M6*30 D11 BLK
TWEETER&WOOFER 590-55035-200-0 M/E SET SCR. M5*35 BLK D8
NET*1 591-55050-200-0 T/P SET SCR. D5*50 BLK
HANDLE*10 592-04022-200-0 W/O FLT SCR. 4*22 BLK D8.5
TERMINAL PANEL*6 592-54018-200-0 W/O SET SCR. M4.0*18 BLK D8
TWEETER&WOOFER*12 592-54030-200-0 W/O SET SCREW D4*30 BLK
NET*4,FEET*4 593-54020-200-0 T/B SCR. 4*20 BLK D6.5 附D11
600-70001-000-7 M5 WHT
600-70002-000-0 NUT M6 WHT Fe
615-70003-210-0 BOT BOSS D35*D108*89 SFJ308
NET*1 615-70007-640-0 PVC BOSS D6.0*D12*25.5 BLK
636-70011-002-0 2*50m
638-44100-080-0 Driver 44mm 100W 8R ESM152/122/ES122/152
639-00000-420-0 HORN ES102/153V.3
700-00900-000-7 9mm 1220*2440mm
700-01500-000-7 15mm 1220*2440mm
700-11800-000-7 18*1220*2440mm
700-12500-000-7 25*1220*2440mm
710-70000-000-7 PT-3670
