Philips 320WN6 Manual de usuario

Page 1 of 1320wn6

Product Information

Product Features • Technical Specifications • Resolution & Preset

Modes • Philips Pixel Defect Policy • Automatic Power Saving •

Physical Specification • Pin Assignment • Product Views

Product Features

320WN6

zLess management effort for maximum productivity

{Multiple displays form a daisy chain to show uniform

{Monitor is network controllable for remote management

{Input connectors: CVBS, S-video, SCART, YPbPr, and RF (TV

input)

zBetter front of screen experience

{Motion adaptive deinterlacing for razor sharp images

{3D comb filter separates color for a razor-sharp image

{WXGA, wide format 1366 x 768 resolution for sharper display

{Adaptive brightness intensifier technology

{Ready to display SDTV, EDTV, and HDTV formats

zGreat convenience

{Zoom function to enable tiled matrix application

{Support hight-bandwidth digital content protection decryption

{Split screen for dual video/PC display

{Picture in picture for public display

* RF(TV input) is only available for 320WN6QS

RETURN TO TOP OF THE PAGE

Technical Specifications*

LCD PANEL

• Type TFT LCD

• Screen size 31.51inch

• Pixel Pitch 0.17 x 0.511 mm

• LCD Panel type 1366 x 768 pixels

R.G.B. vertical stripe

Hard coating surface, anti-glare polarizer

• Effective viewing area 697.7 x 392.2 mm

Page 1 of 8Product Information

• Display Colors 8 bits interface (16.7M colors)

PC SCANNING

• Vertical refresh rate 56Hz-75Hz

• Horizontal frequency 30kHz-63kHz

PC VIDEO

• Video dot rate < 85 MHz

• Input impedance

- Video 75 ohm

- Sync 2.2K ohm

• Input signal levels 0.7 Vpp

• Sync input signal Separate sync

• Sync polarities Positive and negative

• Input Frequency

WXGA Hsync 48 kHz, Vsync 60 Hz

(N.I.)

SVGA Hsync 38 kHz, Vsync 60 Hz

(N.I.)

VGA/DVI-D Hsync 31 kHz, Vsync 60 Hz

(N.I.)

• Video interface D-sub, S-Video, TV-RF, SCART

composite, components video, and DVI

AUDIO

• Input level for

PC/SVHS/SCART 500 mV nominal

• Loudspeaker 10W Stereo Audio (10W/channel RMS x2,

200Hz~10kHz, 8 ohm, 10% THD)

OPTICAL CHARACTERISTICS

• Contrast ratio 1200:1(with DCR on)

• Brightness 500 cd/m2(typ.)

• Peak contrast angle 6 o'clock

• White Chromaticity x: 0.283 y: 0.297 (at 9300°K)

x: 0.313 y: 0.329 (at 6500°K)

x: 0.328 y: 0.344 (at 5700°K)

• Viewing Angle (C/R >5) Upper >89° (typ.)

Lower >89° (typ.)

Left >89° (typ.)

Right >89° (typ.)

Page 2 of 8Product Information

* This data is subject to change without notice.

RETURN TO TOP OF THE PAGE

Resolution & Preset Modes

• Response time (G to G) 8ms(typ.) 12ms(max.)

sRGB

sRGB is a standard for ensuring correct exchange of colors between different

devices (e.g. digital cameras, monitors, printers, scanners, etc.)

Using a standard unified color space, sRGB will help represent pictures taken

by an sRGB compatible device correctly on your sRGB enabled Philips

monitors. In that way, the colors are calibrated and you can rely on the

correctness of the colors shown on your screen.

Important with the use of sRGB is that the brightness and contrast of your

monitor is fixed to a predefined setting as well as the color gamut. Therefore

it is important to select the sRGB setting in the monitor's OSD.

To do so, at PC mode, open the OSD by pressing the MENU button of your

monitor. Use the down button to go to COLOR SETTINGS and press MENU

again. Then move the down button to go to NORMAL COLOR and press

MENU again.

• Recommended 1360 x 768 at 60Hz

10 factory preset modes:

Resolution Mode H. freq (kHz) V. freq (Hz)

640x350 VGA-1 31.469 70.086

640x480 VGA VESA 60 31.469 59.940

640x480 VGA VESA 75 37.500 75.000

720x400 IBM VGA 3H 31.468 70.087

800x600 SVGA VESA 56 35.156 56.250

800x600 SVGA VESA 60 37.879 60.317

800x600 SVGA VESA 75 46.875 75.000

1280x1024 XGA VESA 60 48.363 60.004

1280x1024 XGA VESA 75 60.023 75.029

1280x768 GTF 60 47.700 60.000

Page 3 of 8Product Information

RETURN TO TOP OF THE PAGE

Automatic Power Saving

If you have VESA DPMS compliance display card or software installed in your

PC, the monitor can automatically reduce its power consumption when not in

use. If an input from a keyboard, mouse or other input device is detected, the

monitor will then 'wake up' automatically. The following table shows the power

consumption and signaling of this automatic power saving feature:

RETURN TO TOP OF THE PAGE

Physical Specifications

1280x768 Wincomm 45.113 56.260

1360x768 VESA 47.700 60.000

Video

720x480 480i 15.734 59.940

720x576 576i 15.625 50.000

720x480 480p 31.470 60.000

720x576 576p 31.250 50.000

1280x720 720p 28.200 50.000

1280x720 720p 33.750 60.000

1920x1080 1080i 37.500 50.000

1920x1080 1080i 45.000 60.000

Power Management Definition

VESA

Mode Video H-sync V-

sync Power

Used LED

color

Active On Yes Yes 100 W (typ.) Blue

Sleep Off No No < 5 W Amber

Switch Off Off - - < 3 W Off

• Dimension (WxHxD) * 1014mm x 517mm x 244mm (incl. Pedestal,

Speakers)

Page 4 of 8Product Information

* This data is subject to change without notice.

RETURN TO TOP OF THE PAGE

Pin Assignment

1. The digital only connector (DVI-D) contains 24 signal contacts organized in

three rows of eight contacts. Signal pin assignments are listed in the following

table:

794mm x 490mm x 130mm (w/o Pedestal,

Speakers)

• Weight 19.2 kg (incl. Pedestal, Speakers)

• Power supply 100 — 240 VAC, 60 — 50 Hz

• Power consumption PC Mode: 100 W (typ.)

TV Mode: 130 W (typ.)

• Temperature (operating) 5° C to 35° C

• Relative humidity 20% to 80%

• System MTBF 50K hrs (excluding CCFL 40Khrs)

No. Signal

Assignment

No. Signal

Assignment

No. Signal

Assignment

1T.M.D.S. Data2- 9T.M.D.S. Data1- 17 T.M.D.S. Data0-

2T.M.D.S.

Data2+ 10 T.M.D.S.

Data1+ 18 T.M.D.S.

Data0+

3T.M.D.S.

Data2/4 Shield 11 T.M.D.S.

Data1/3 Shield 19 T.M.D.S.

Data0/5 Shield

4No connect 12 No connect 20 No connect

5No connect 13 No connect 21 No connect

6DDC Clock 14 +5V Power 22 T.M.D.S. Clock

Shield

7DDC Data 15 Hot Plug Detect 23 T.M.D.S.

Clock+

Ground (for

Page 5 of 8Product Information

2. The 15-pin D-sub connector (male) of the signal cable:

3. RS232 Connector

D-sub 9-pin male connector for communication with plasma engine or PC.

8No connect 16 +5V) 24 T.M.D.S. Clock-

No. Assignment Pin

No. Assignment

1Red video input 9DDC +5V

2Green video input 10 Cable detect

3Blue video input 11 Identical output,

connected to pin 10

4Ground 12 Serial data line

(SDA)

5NC 13 H. Sync / H+V

6Red video ground 14 V. Sync

7Green video

ground 15 Data clock line (SCL)

8Blue video ground

Pin No. RS-232 (EIA-232-A) Function

3Transmit Data (TD) from DTE to DCE

2Receive Data (RD) from DCE to DTE

7Request to Send (RTS)

8Clear to Send (CTS)

6DCE Ready (DSR)

5Signal Ground (SG)

Page 6 of 8Product Information

4. SCART Connector

1Received Line Signal Detector (DCD)

4DTE Ready (DTR)

9Ring Indicator

No. Signal Pin

No.

1Audio right channel output (0.5 Vrms,

< 1K ohms) 2

2Audio right channel input (0.5 Vrms, >

10K ohms) 1

3Audio left channel output (0.5 Vrms, <

1K ohms) 6

4Audio ground 4

5Blue signal ground 5

6Audio left channel input (0.5 Vrms, >

10K ohms) 3

7Blue signal I/O (0.7 Vp-p, 75 ohms) 7

8Function switching I/O (L: < 2V, H: >

10V, 10K ohms) 8

9Green signal ground 9

10 Intercommunication data line No. 1 10

11 Green signal I/O (0.7 Vp-p, 75 ohms) 11

12 Intercommunication data line No. 2 12

13 Red signal ground 13

14 Blanking signal ground 14

15 Red signal I/O (0.7 Vp-p, 75 ohms) 15

16 Blanking signal I/O (L: < 0.4V, H:

>1.0V, 75 ohms) 16

17 Composite video signal ground 18

18 Blanking signal ground 17

19 Composite video signal output (1 Vp- 20

Page 7 of 8Product Information

RETURN TO TOP OF THE PAGE

Product Views

Follow the links to see various views of the monitor and its components.

Product Description

RETURN TO TOP OF THE PAGE

p, 75 ohms, sync: negative)

20 Composite video signal input (1 Vp-p,

75 ohms, sync: negative) 19

21 Plug shield (common ground) 21

Page 8 of 8Product Information

Installing your LCD Monitor/TV

Product Description • Connecting to Your PC, TV antenna, DVD/VCR etc. •

Getting Started • Optimizing Performance

Product Description

Installing your LCD Monitor/TV

Side View (Left)

Page 1 of 4Installing your LCD Monitor/TV
