Philips MCM906/12 Manual de usuario

3

1

2

MCM906

What’s in the Box?

You should Þnd these items upon opening the box.

FM antenna

Quick Start Guide

Remote Control

Quick Start Guide Power cordUser Manual

MCM906_QSG_Eng.indd 1MCM906_QSG_Eng.indd 1 2008-9-22 9:58:222008-9-22 9:58:22

1

2

3

4

In standby mode, press and hold CLOCK on the remote control.

When the hour digits ßash, turn VOLUME on the system or press VOL+/- on the remote

control to set the hours.

Press CLOCK again and the minute digits ßash.Then turn VOLUME on the system or press

VOL+/- on the remote control to set the minutes.

Press CLOCK again to conÞrm the time setting.

1

2

3

Connect the speaker cables.

Connect the FM antenna.

Connect the power cord of the system.

Speaker

(right)

Speaker

(left)

FM antenna

AC power

Setting the clock

IMPORTANT!

– To set clock in the Eco Power mode, press and hold STANDBY-ON 2on the set for 3 seconds or more to switch to normal

standby mode Þrst before proceeding with the procedures below.

Tip

See the User Manual for how to connect

other equipment to this system.

1

2

3

MCM906_QSG_Eng.indd 2MCM906_QSG_Eng.indd 2 2008-9-22 9:58:232008-9-22 9:58:23

4

3

2

1

Playing a disc

Press SOURCE on the front panel to select DISC or press CD on the

remote control.

Press çto open the CD compartment.

Insert a disc with the printed side facing up. Press çagain to close the

compartment.

Playback will start automatically. If not, press ÉÅ.

To stop playback, press 9.

CD

5

1

2

3

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more (or USB on the remote control) to select USB.

Play the USB’s audio Þles as you do with the albums/tracks on a CD.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB ßash memory (USB 2.0 or USB1.1),

USB ßash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

MCM906_QSG_Eng.indd 3MCM906_QSG_Eng.indd 3 2008-9-22 9:58:242008-9-22 9:58:24

1

2

3

Press SOURCE (TUNER on the remote control) to select tuner source.

Press PROGRAM on the remote control for more than two seconds to program all available

stations in order of waveband.

Press ¡/ ™until the desired preset station is displayed.

Programming and tuning to radio stations

PDCC-JS-WP-0829

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

CRoyal Philips Electronics N.V. 2008

All rights reserved.

http://www.philips.com

MCM906_QSG_Eng.indd 4MCM906_QSG_Eng.indd 4 2008-9-22 9:58:252008-9-22 9:58:25
