Philips MCM720/05 Manual de usuario

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

FM antenna MW antenna Remote Control

Quick Start Guide

User manual

MCM720

MCM720 QUG_Eng 2006.2.24, 14:461

Connect the speaker cables.

Connect the MW and FM antennas.

Connect the power cable of the system.

Speaker Speaker

Tip

See the User Manual for how to connect other

equipment to this system.

MCM720 QUG_Eng 2006.2.24, 14:462

Enjoy

Playing a disc

Press OPEN•CLOSEçto open the disc tray and load in a disc, then press the same

button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Press ÉÅ to start playback.

To stop playback, press STOP 9.

VOLUME

INCREDIBLE

SURROUND

PROGRAM

TUNING

ALBUM

PRESET

SOURCE

TIMER SET

DBBDSC

RDS

CLOCK SETBAND

STANDBY-ON

ECO POWER

RECORD DISPLAY

WMA-MP3-CD/CD-R/CD-RW COMPATIBLE

MCM720 MICRO SYSTEM

OPEN/

USB DIRECT

RDS

CLOCK SET

Setting the clock

In standby mode, press and hold CLOCK SET/RDS on the system.

When the hour digits flash, turn the VOLUME control on the front panel to

set the hours.

Press CLOCK SET/RDS again and the minute digits flash.Then turn the

VOLUME control on the front panel to set the minutes.

Press CLOCK SET/RDS again to confirm the time setting.

IMPORTANT!

– To set clock in the Eco Power mode, press and hold ECO POWER/

STANDBY-ON

on the set for 3 seconds or more to switch to normal

standby mode first before proceeding with the procedures below.

MCM720 QUG_Eng 2006.2.24, 14:463

VOLUME

INCREDIBLE

SURROUND

PROGRAM

TUNING

ALBUM

PRESET

SOURCE

TIMER SET

DBBDSC

RDS

CLOCK SETBAND

STANDBY-ON

ECO POWER

RECORD DISPLAY

WMA-MP3-CD/CD-R/CD-RW COMPATIBLE

MCM720 MICRO SYSTEM

OPEN/

USB DIRECT

PROGRAM

SOURCE

Enjoy

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more to select USB (or CD/USB on the remote control).

Play the USB’s audio files as you do with the albums/tracks on a CD.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

2005 CKoninklijie Philips Electronics

http://www.philips.com PDCC-JS/JW-0608 GB

Programming and tuning to

radio stations

Press SOURCE repeatedly to select the tuner source.

Press PROGRAM for more than two seconds to program all

available stations in order of waveband.

Press 4or 3until the desired preset station is displayed.

MCM720 QUG_Eng 2006.2.24, 14:464
