Philips MCM704D/37B Manual de usuario

MCM704D

What’s in the Box?

You should find these items upon opening the box.

FM antenna

AM antenna

Quick start guide

Remote Control

Pull out the plastic

protective sheet

before use.

Quick Start Guide

User Manual

1X Docking cradle

8 X iPod dock adaptors

Control cable

User Manual

Quick Start Guide

Docking cable

MCM704D QSG_Eng 2007.4.7, 14:561

Connect the speaker cables.

Connect the FM and AM antennas.

Connect the control cable.

Connect the docking cradle.

Connect the power cord of the system.

iPod portable player

Docking cradle

Docking cable

Speaker

(right)

Speaker

(left)

FM antenna

AM antenna

AC power cord

Tip

See the User Manual for how to

connect other equipment to this

system.

MCM704D QSG_Eng 2007.4.7, 14:562

In standby mode, press and hold CLOCK on the remote.

When the hour digits flash, turn VOLUME-/+ on the system or press VOL+/- on the

remote to set the hours.

Press CLOCK again and the minute digits flash.Then turn VOLUME-/+ on the system or

press VOL+/- on the remote to set the minutes.

Press CLOCK again to confirm the time setting.

Setting the clock

IMPORTANT!

– To set clock in the Eco Power mode, press and hold ECO POWER/STANDBY-ON

on the set for 3

seconds or more to switch to normal standby mode first before proceeding with the procedures below.

Playing a disc

Press SOURCE on the top of the system to select DISC or press

CD on the remote.

Press çto open the CD compartment.

Insert a disc with the printed side facing up. Press çagain to close

the compartment.

Playback will start automatically.

To stop playback, press 9.

MCM704D QSG_Eng 2007.4.7, 14:563

PDCC-JS/JW-0714

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more (or USB on the remote control) to select USB.

Play the USB’s audio files as you do with the albums/tracks on a CD.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

Playing Apple iPod using MCM704D

Select the correct dock adaptor, as indicated on each adaptor, then fit it in

the dock.

Correctly place the compatible iPod player into the dock.

Press SOURCE on the system repeatedly or iPod on the remote control

to select the iPod source.

Power on your iPod player.

Select and play your favourite songs stored in the iPod player.

MCM704D QSG_Eng 2007.4.7, 14:564
