Philips

Micro Hi-Fi System

MCM276R

Unique style and Docking ready

Trendy and progressive, unique innovation and style appeals to you. And so will the vividly

chic MCM276R with MP3/WMA-CD & USB Direct playback. Enjoy your Philips GoGear

and iPod music via DC276 docking kit.

Unlimited listening pleasure

• Enjoy MP3/WMA music directly from your portable USB drives

• Dock and play your GoGear or iPod players

• Play MP3/WMA-CD, CD and CD-RW

Enrich your sound experience

• Digital Sound Control for optimized music style settings

• Dynamic Bass Boost for deep and dramatic sound

• 10W RMS total output power

Start the day your way

• Wake up and sleep timer functions

• Digital tuning with 40 preset stations for extra convenience

Watch your disc spin

• Front motorized CD door with viewing window

• Wall-mountable option for flexible placement

MCM276R/37

Highlights

Micro Hi-Fi System

USB Direct for MP3/WMA music

Simply plug in your device to the USB port on

your Philips Hi-Fi system. Your digital music

will be played directly from the device. Now

you can share your favorite moments with

family and friends.

Digital Sound Control

Digital Sound Control offers you a choice of

pre-set Jazz, Rock, Pop and Classic controls

you can use to optimise the frequency ranges

for different musical styles. Each mode uses

graphic equalizing technology to automatically

adjust the sound balance and enhance the most

important sound frequencies in your chosen

music style. Ultimately, Digital Sound Control

makes it easy for you get the most out of your

music by precisely adjusting the sound balance

to match the type of music you are playing.

Dynamic Bass Boost

Dynamic Bass Boost maximizes your music

enjoyment by emphasizing the bass content of

the music throughout the range of volume

settings - from low to high – at the touch of a

button! Bottom-end bass frequencies usually

get lost when the volume is set at a low level.

To counteract this, Dynamic Bass Boost can be

switched on to boost bass levels, so you can

enjoy consistent sound even when you turn

down the volume.

Issue date 2014-02-06

Version: 1.1.8

12 NC: 8670 000 24979

UPC: 6 09585 12117 1

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

MCM276R/37

Specifications

Micro Hi-Fi System

Sound

• Output Power: 10W Total Power

• Output power (RMS): 2 x 5 W

• Sound Enhancement: Dynamic Bass Boost, Digital

Sound Control

Loudspeakers

• Main Speaker: 2 way, Bass Reflex Speaker System,

Piezo tweeter, 4" woofer

Audio Playback

• Playback Media: CD, CD-R, CD-RW, MP3-CD,

WMA-CD

• Disc Playback Modes: 40-Track Programmable,

Repeat/one/all/program, Shuffle Play

• Loader Type: Front, Motorised

• ID3-tag support

• USB Direct Modes: Fast Backward/Fast Forward,

Play/Pause, Previous/Next, Program Play, Repeat,

Shuffle, Stop

Tuner/Reception/Transmission

• Tuner Bands: FM Stereo, AM

• Auto digital tuning

• Station presets: 40

• Tuner Enhancements: Auto Store

Connectivity

• Headphone: 3.5 mm

• Other connections: FM Antenna, AM Antenna,

Cradle connection

Convenience

• Alarms: CD Alarm, Radio Alarm, Sleep timer

• Clock: On main display

• Display Type: LCD

• Backlight color: Blue

• Eco Power Standby: 1 watt

Accessories

• Included accessories: Screws for wall mounting x2,

AM/FM Antenna

• Remote control: 24-key with battery

• Cradle: Cradle and adaptors for GoGear and iPod

(Optional)

• Quick start guide: Eng,Spa,Fre

• User Manual: Eng, Spa, Fre

Dimensions

•Setdimensions(Wx H x D): 194 x 269 x 90 mm

• Main speaker dimensions (W x H x D):

160x 269 x 90 mm

• Packaging dimensions (W x H x D):

310x 314 x 238 mm

• Weight incl. Packaging: 5.5 kg

Power

• Power supply: 120V, 60Hz

•
