Philips MCB204/05 Manual de usuario

MCB204

What’s in the Box?

You should find these items upon opening the box.

Quick start guide

Remote Control

Pull out the plastic

protective sheet

before use.

Quick Start Guide

User Manual

Quick Start Guide User Manual

MCB204 QSG_Eng 4/17/07, 2:02 PM1

FM/DAB antenna

AUX

HEADPHONE

RIGHT LEFT

AC power adaptor

Speaker

(right)

Speaker

(left)

Tip

See the User Manual for how to

connect other equipment to this

system.

In standby or active mode, press CLOCK on the remote.

When the hour digits flash, press TUNING 4 ¢ on the front panel (or ¡ / ™on the

remote control) to set the hours.

Press CLOCK again and the minute digits flash.Then press TUNING 4 ¢ or ¡ / ™

again to set the minutes.

Press CLOCK again to confirm the time setting.

Connect the speaker cables.

Connect the power cord of the system..

Setting the clock

MCB204 QSG_Eng 4/17/07, 2:02 PM2

Playing a disc

Press SOURCE on the front panel to select CD or press DISC on the remote control.

Press OPEN/CLOSE çto open the CD compartment.

Insert a disc with the printed side facing up. Press OPEN/CLOSE çagain to close the

compartment.

Press ÉÅ to start playback.

To stop playback, press 9.

Tip

See the User Manual for detailed playback operations.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more (or USB on the remote control) to select USB.

Play the USB’s audio files as you do with the albums/tracks on a CD.

MCB204 QSG_Eng 4/17/07, 2:02 PM3

Tuning to DAB stations

Press SOURCE on the front panel to select DAB (or press DAB/FM on the remote

control) to start automatic search for available DAB stations.

Press and hold SCAN on the front panel (or SMART SCAN on the remote control)

to scan all band III frequencies.

At the completion of full scan, press S/Ton the front panel or press ¡ / ™on the

remote control to select your desired DAB channels.

Press ENTER/ÉÅ to confirm and tune to your selected channel.

Tips

–If the reception is poor, hang up one end of the T-shape FM/DAB antenna

and keep the other end at horizontal angle to it.

–See the User Manuals for detailed instructions on DAB operations.

PDCC-SY/ZC-0714

Programming and tuning to radio stations

Press SOURCE on the front panel repeatedly (or DAB/FM on the remote

control) to select the tuner source.

Press PROGRAM for more than two seconds to program all available stations.

Press ALBUM/PRESET 4or 3(or ¡ / ™on the remote control) until the

desired preset station is displayed.

Tip

Detailed playback features and additional functions are described

in the accompany owner's manual.

CRoyal Philips Electronics N.V. 2007

MCB204 QSG_Eng 4/17/07, 2:02 PM4
