Philips FWM998X/77 Manual de usuario

www.philips.com/welcome

EN User manual

English

Enhance bass 16

Virtual surround 16

Customize sound for room acoustics 17

8 Listen to radio 17

Tune to a radio station 17

Program radio stations automatically 17

Program radio stations manually 18

Select a preset radio station 18

9 USB/SD record 18

Record to a USB/SD device 18

Schedule radio-to-USB/SD record 19

10 Other features 20

Set the alarm timer 20

Set the sleep timer 20

Listen to an external device 20

Delete from a USB/SD device 21

Copy les between SD and USB device 21

Karaoke 21

11 Product information 22

Specications 22

USB playability information 23

Supported MP3 disc formats 23

Maintenance 23

12 Troubleshooting 24

Contents

1 Important 4

Safety 4

Notice 5

2 Your Mini Hi-Fi System 6

Introduction 6

What’s in the box 6

Overview of the main unit 7

Overview of the remote control 9

3 Connect 10

Connect FM antenna 10

Connect AM antenna 10

Connect speakers 11

Connect power 11

4 Get started 12

Prepare the remote control 12

Auto install radio stations 13

Set clock 13

Turn on 13

5 Play 14

Play disc 14

Play from a USB device 14

Play from an SD card 15

Play from an external device 15

6 Play options 15

Repeat and random play 15

Program tracks 15

Display play information 15

7 Adjust volume level and sound

effect 16

Adjust volume level 16

Mute sound 16

Boost loudness 16

Select a preset sound effect 16

lUnplug this apparatus during lightning

storms or when unused for long periods

of time.

m Referallservicingtoqualiedservice

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the apparatus,

the apparatus has been exposed to rain

or moisture, does not operate normally,

or has been dropped.

nBattery usage CAUTION – To prevent

battery leakage which may result in

bodily injury, property damage, or

damage to the unit:

Install all batteries correctly, + and -•

as marked on the unit.

Do not mix batteries (old and new •

or carbon and alkaline, etc.).

Remove batteries when the unit is •

not used for a long time.

oApparatus shall not be exposed to

dripping or splashing.

pDo not place any sources of danger on

theapparatus(e.g.liquidlledobjects,

lighted candles).

qThis product may contain lead and

mercury. Disposal of these materials

may be regulated due to environmental

considerations. For disposal or recycling

information, please contact your local

authorities or the Electronic Industries

Alliance: www.eiae.org.

rWhere the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain

readily operable.

1 Important

Safety

aRead these instructions.

bKeep these instructions.

cHeed all warnings.

dFollow all instructions.

eDo not use this apparatus near water.

fClean only with dry cloth.

gDo not block any ventilation openings.

Install in accordance with the

manufacturer’s instructions.

hDo not install near any heat sources

such as radiators, heat registers, stoves,

orotherapparatus(includingampliers)

that produce heat.

iProtect the power cord from being

walked on or pinched, particularly at

plugs, convenience receptacles, and

the point where they exit from the

apparatus.

jOnly use attachments/accessories

speciedbythemanufacturer.

kUse only with the cart, stand, tripod,

bracket,ortablespeciedbythe

manufacturer or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination

to avoid injury from tip-over.

packaging materials, exhausted batteries and

old equipment.

Windows Media and the Windows logo are

trademarks, or registered trademarks of

Microsoft Corporation in the United States

and/or other countries.

This apparatus includes this label:

Warning

Never remove the casing of this apparatus.•

Never lubricate any part of this apparatus.•

Never place this apparatus on other electrical•

equipment.

Keep this apparatus away from direct sunlight,

•

naked ames or heat.

Never look into the laser beam inside this

•

apparatus.

Ensure that you always have easy access to the

•

power cord, plug or adaptor to disconnect this

apparatus from the power.

Caution

Use of controls or adjustments or•

performance of procedures other than herein

may result in hazardous radiation exposure or

other unsafe operation.

Notice

Any changes or modications made to this

device that are not expressly approved by

Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

The making of unauthorized copies of

copy-protected material, including computer

programs, les, broadcasts and sound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

English

What’s in the box

Check and identify the contents of your

package:

Main unit x 1•

AC power cable x 1•

Power plug adaptor x 1•

Front speakers x 2•

Rear speakers x 2•

Subwoofers x 2•

Remote control with 2 AAA batteries•

FM wire antenna x 1•

AM loop antenna x 1•

MP3 link cable x 1•

Quick start guide x 1•

User manual x 1•

2 Your Mini Hi-Fi

System

Congratulations on your purchase, and

welcome to Philips! To fully benet from the

support that Philips offers, register your product

at www.Philips.com/welcome.

Introduction

With this unit, you can enjoy audio from discs,

USB devices, iPod players, external devices, or

radio stations.

For your convenience, you can load up to three

discs at once.

To enrich sound, this unit offers you these

sound effects:

MAX sound for instant power boost•

Digital Sound Control (DSC)•

Dynamic Bass Boost (DBB)•

Incredible surround (IS)•

Virtual Ambience-based Control (VAC)•

The unit supports the following media formats:

dSource selection keys

Select a source.•

eUSB RECORD

Record to a USB device.•

fUSB to SD

Copy audio les from a USB device •

to an SD card.

Overview of the main unit

{

}



€



Turn on the unit or switch to •

standby mode.

bDISPLAY

Select display information.•

cMODE

Select repeat play or random play.•

English

Start or pause play.•

wMAX SOUND

Turn on or off instant power boost •

for sound.

xVAC

Select an ambiance-based equalizer•

setting.

yIS

Turn on or off incredible surround.•

zDBB

Turn on or off dynamic bass•

enhancement.

{SD DELETE

Delete audio les stored on an SD •

device.

|SD RECORD

Record to an SD card.•

}SD to USB

Copy audio les from an SD card to •

a USB device.

~PROG

Program tracks.•

Program radio stations.•

CLOCK

Set the clock/View the clock.•

€LIGHT

Turn on or off the lighting effect.•

Display panel

Show status.•

gUSB DELETE

Delete audio les stored on a USB •

device.

hVOLUME

Adjust volume.•

iDSC

Select a preset sound equalizer•

setting.

jDISC 1/2/3

Select a disc.•

Skip to the previous/next track.•

Search within a track/disc/USB/SD •

device/DOCK.

Tune to a radio station.•

Adjust time.•

Stop play or erase a program.•

mALBUM/PRESET+/-

Skip to the previous/next album.•

Select a preset radio station.•

Adjust time.•

Select 12 hour or 24 hour format.•

nOPEN/CLOSE

Open or close the disc•

compartment.

oDisc compartment door

pMIC VOL

Adjust microphone volume.•

qMicrophone port

Jack for a microphone.•

Jack for a USB mass storage device.•

sMP3 LINK

Audio input jack (3.5mm) for an•

external audio device.

tSD card slot

uDISC CHANGE

Change a disc.•

Turn on the unit or switch to •

standby mode.

bSource selection keys

Select a source.•

cSLEEP

Set the sleep timer.•

dMODE

Select repeat play or random play.•

eUSB DELETE

Delete audio les stored on a USB •

device.

fMUTE

Mute volume.•

gUSB RECORD

Record to a USB device.•

Start or pause play.•

Skip to the previous/next track.•

jUSB to SD

Copy audio les from a USB device •

to an SD card.

kALBUM/PRESET+/-

Skip to the previous/next album.•

Select a preset radio station.•

Adjust time.•

Select 12 hour or 24 hour format.•

lNumeric keypad

Select a track from a disc directly.•

mPROG

Program tracks.•

Program radio stations.•

nMAX SOUND

Turn on or off instant power boost •

for sound.

oDSC

Select a preset sound equalizer•

setting.

Overview of the remote

control

{

English

3 Connect

Connect FM antenna

1Connect the supplied FM antenna to the

FM jack on the back of the main unit.

Connect AM antenna

1Assemble the AM loop antenna.

2Connect the AM loop antenna to the AM

jack on the back of the main unit.

pDBB

Turn on or off dynamic bass•

enhancement.

qVAC/IS

Select an ambiance-based equalizer•

setting.

Turn on or off incredible surround.•

rDISPLAY

Select display information.•

sVOL +/-

Adjust volume.•

Stop play or erase a program.•

uSD to USB

Copy audio les from an SD card to •

a USB device.

Skip to the previous/next track.•

Search within a track/disc/USB/SD •

device/DOCK.

Tune to a radio station.•

Adjust time.•

wSD RECORD

Record to an SD card.•

xCLOCK

Set the clock/View the clock.•

ySD DELETE

Delete audio les stored on an SD •

device.

zLIGHT

Turn on or off the lighting effect.•

{TIMER

Set the alarm timer.•

Connect the rear speakers

3Find “REAR SPEAKERS” sockets on the

main unit.

4Insert the gray connector of the rear

right speaker wire to “R”, and the gray

connector of the rear left speaker wire to

“L”.

Connect the subwoofers

5Insert the blue connectors of the

subwoofer wires to “SUB WOOFER”

sockets.

Connect power

Caution

Risk of product damage! Ensure that the •

power supply voltage corresponds to the

voltage set on the voltage selector on the back

of the unit.

Ensure that the power supply socket used can

•

support at least 10A current loading.

Before connecting the AC power cord, ensure

•

that you have completed all other connections.

Connect speakers

Note

For optimal sound, use the supplied speakers•

only.

Connect only speakers with impedance that is

•

the same or higher than the supplied speakers.

Refer to the Specications section of this manual.

A: front speakers; B: rear speakers; C:

subwoofers

Connect the front speakers

1Find “SPEAKERS” sockets on the main

unit.

2Insert the black connector of the front

right speaker wire to “R”, and the black

connector of the front left speaker wire

to “L”.

English

Otros manuales para FWM998X/77

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema estéreo de Philips

Philips

Philips FW-C85 Manual de usuario

Philips

Philips FW-R8/17 Manual de usuario

Philips

Philips FWM996 Manual de usuario

Philips

Philips Streamium WACS4500 Guía de inicio rápido

Philips

Philips Streamium MCI730/05 Manual de usuario

Philips

Philips FW-C28/25 Manual de usuario

Philips

Philips DCM3100 Manual de usuario

Philips

Philips FWD185/94 Manual de funcionamiento

Philips

Philips FW15 Manual de usuario

Philips

Philips FW-C550 Manual de usuario

Philips

Philips FW360C/25 Manual de usuario

Philips

Philips WACS7500 - Streamium Wireless Music Center&Station Network Audio... Manual de usuario

Philips

Philips AS 550 Manual de usuario

Philips

Philips MCM 761 Manual de usuario

Philips

Philips MC147 Manual de usuario

Philips

Philips MCD370 Manual de usuario

Philips

Philips WACS7500 - Streamium Wireless Music Center&Station Network Audio... Manual de usuario

Philips

Philips FWD570/21M Manual de usuario

Philips

Philips MCM239/96 Manual de usuario

Philips

Philips NTRX500X/78 Manual de usuario

Philips

Philips MCM330 Manual de usuario

Philips

Philips AZ127/73/93 Manual de usuario

Philips

Philips MCD290 Manual de usuario

Philips

Philips MCL 707 Manual de usuario

Manuales populares de Sistema estéreo de otras marcas

LG CM3330B Manual de usuario

Sony

Sony SS-CEP50 Manual de usuario

Cetacea Sound

Cetacea Sound CVS-II Manual de usuario

Aiwa

Aiwa XR-H66MD Manual de usuario

Denon

Denon UCD-250 Manual de usuario

Sanyo

Sanyo DC-MX41i Manual de usuario

Sharp

Sharp CD-ES600V Manual de usuario

Exibel

Exibel BDX600-UK Manual de usuario

Sanyo

Sanyo DC-F320 Manual de usuario

Sharp

Sharp CD-C462 Manual de usuario

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manual de usuario

Aiwa

Aiwa XR-EM70 Manual de usuario

Cyrus

Cyrus Lyric Manual de usuario

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manual de usuario

RCA

RCA RS3965SB Manual de usuario

Sharp

Sharp XL-UH240 Manual de usuario

LG FB165DAB Manual de usuario

Sanyo

Sanyo DC-UB1475M/XE/UK Manual de usuario
