Philips FWM200D/05 Manual de usuario

FWM200D/05

www.philips.com/welcome

EN User manual

FWM200D_UM_ENG_05_1.1.indd Sec3:1 2011-3-9 10:07:55

English

7 Other features 14

Set alarm timer 14

Set sleep timer 14

8 Product information 15

Specications 15

Amplier 15

Disc 15

Tuner 15

FM 15

Speakers 15

General information 15

USB playability information 16

Supported MP3 disc formats 16

Maintenance 16

9 Troubleshooting 17

10 Notice 18

Contents

1 Important 2

Safety 2

Know these safety symbols 2

Important Safety Instructions 2

2 Your Mini Hi-Fi System 4

Introduction 4

What’s in the box 4

Overview of the main unit 5

Overview of the remote control 6

3 Get started 8

Connect speaker 8

Prepare the remote control 8

Connect power 9

Set clock 9

Turn on 9

Switch to standby mode 9

4 Play 10

Basic play operations 10

Play disc 10

Play from iPod/iPhone 10

Compatible iPod/iPhone 10

Listen to audio from iPod/iPhone 10

Charge the iPod/iPhone 11

Play from USB 11

Play audio from an external device 11

5 Play options 12

Adjust sound 12

Repeat and shufe play 12

Program tracks 12

Display different information 12

6 Listen to FM radio 13

Tune to FM radio stations 13

Store FM radio stations automatically 13

Store FM radio stations manually 13

Select a preset radio station 13

FWM200D_UM_ENG_05_1.1.indd Sec1:1 2011-3-9 10:08:16

2EN

Important Safety Instructions

Read these instructions.•

Heed all warnings.•

Follow all instructions.•

Do not block any ventilation•

openings. Install in accordance with

the manufacturer’s instructions.

Do not install near any heat sources•

such as radiators, heat registers,

stoves, or other unit (including

ampliers) that produce heat.

Protect the power cord from being•

walked on or pinched, particularly at

plugs, convenience receptacles, and

the point where they exit from the

clock radio.

Only use attachments/accessories•

specied by the manufacturer.

Use only with the cart, stand, tripod,•

bracket, or table specied by the

manufacturer or sold with the Hi-Fi

system. When a cart is used, use

caution when moving the cart/unit

combination to avoid injury from

tip-over.

Unplug this Hi-Fi system during•

lightning storms or when unused for

long periods of time.

Refer all servicing to qualied service•

personnel. Servicing is required

when the Hi-Fi system has been

damaged in any way, such as power-

supply cord or plug is damaged, liquid

has been spilled or objects have

fallen into the Hi-Fi system, the Hi-Fi

system has been exposed to rain or

moisture, does not operate normally,

or has been dropped.

This Hi-Fi system shall not be•

exposed to dripping or splashing.

1 Important

Safety

Know these safety symbols

This ‘bolt of lightning’ indicates uninsulated

material within your unit may cause an

electrical shock. For the safety of everyone

in your household, please do not remove

product covering.

The ‘exclamation point’ calls attention to

features for which you should read the

enclosed literature closely to prevent

operating and maintenance problems.

WARNING: To reduce the risk of re or

electric shock, this apparatus should not be

exposed to rain or moisture and objects lled

with liquids, such as vases, should not be

placed on this apparatus.

CAUTION: To prevent electric shock, match

wide blade of plug to wide slot, fully insert.

FWM200D_UM_ENG_05_1.1.indd Sec1:2 2011-3-9 10:08:17

English

Important notes for users in the U.K.

Mains fuse

This information applies only to products with

a UK mains plug.

This product is tted with an approved

molded plug. If you replace the fuse, use one

with:

the ratings shown on the plug,•

a BS 1362 approval, and•

the ASTA approval mark.•

Contact your dealer if you are not sure about

what type of fuse to use.

Caution: To conform with the EMC directive

(2004/108/EC), do not detach the plug from

the power cord.

Do not place any sources of danger•

on the Hi-Fi system (e.g. liquid lled

objects, lighted candles).

Battery usage CAUTION – To•

prevent battery leakage which may

result in bodily injury, property

damage, or damage to the remote

control:

Install all batteries correctly, + and -•

as marked on the remote control.

Remove batteries when the remote•

control is not used for a long time.

Where the MAINS plug or an•

appliance coupler is used as the

disconnect device, the disconnect

device shall remain readily operable.

Warning

Never remove the casing of this apparatus.•

Never lubricate any part of this apparatus.•

Never place this apparatus on other electrical•

equipment.

Keep this apparatus away from direct sunlight,

•

naked ames or heat.

Never look into the laser beam inside this

•

apparatus.

Ensure that you always have easy access to the

•

power cord, plug or adaptor to disconnect this

apparatus from the power.

FWM200D_UM_ENG_05_1.1.indd Sec1:3 2011-3-9 10:08:18

4EN

What’s in the box

Check and identify the contents of your

package:

Main unit•

Remote control (with batteries)•

Speaker box (x 2)•

User manual•

Quick start guide•

2 Your Mini Hi-Fi

System

Congratulations on your purchase, and

welcome to Philips! To fully benet from the

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this Hi-Fi system, you can:

enjoy audio from discs, USB device, iPod/•

iPhone and other external devices; and

listen to radio stations•

To enrich sound, this Hi-Fi system offers you

these sound effects:

Digital Sound Control (DSC)•

Dynamic Bass Boost (DBB)•

Max sound for instant power boost•

The Hi-Fi system supports these media

formats:

FWM200D_UM_ENG_05_1.1.indd Sec1:4 2011-3-9 10:08:18

English

b ALBUM/PRESET +/-

Select a preset radio station.•

Skip to previous/next album.•

Navigate through iPod/iPhone menu.•

Overview of the main unit

Turn on the Hi-Fi system.•

Switch to standby or Eco power•

standby mode.

FWM200D_UM_ENG_05_1.1.indd Sec1:5 2011-3-9 10:08:18

6EN

Overview of the remote

control

Turn on the Hi-Fi system.•

Switch to standby or Eco power•

standby mode.

b OPEN/CLOSE

Open or close the disc tray.•

c /

Stop play or erase a program.•

Start or pause play.•

d DISC

Select disc source.•

e iPod/iPhone

Select iPod/iPhone source.•

f Volume controller

Adjust volume.•

g MP3 LINK

Connect external audio device.•

h Dock for iPod/iPhone

i USB DIRECT

USB socket.•

j MP3 LINK/USB

Select MP3 link/USB source.•

k TUNER

Select tuner source.•

l /

Skip to previous/next track.•

Search within a track/disc.•

Tune to a radio station.•

Adjust time.•

Open or close the disc tray.•

n Display panel

Show current status.•

FWM200D_UM_ENG_05_1.1.indd Sec1:6 2011-3-9 10:08:19

English

r PRESET/ALBUM

Select a preset radio station.•

Skip to previous/next album.•

Navigate through iPod/iPhone menu.•

s TUNER

Select tuner source.•

c CD

Select disk source.•

d MP3 LINK/USB

Select MP3 link/USB source.•

e DISP/MUTE

Mute/unmute sound.•

Show current information.•

f Numeric keypad

Select a track from a disc directly.•

Select a preset radio station directly.•

g PROG/CLOCK SET

Set time.•

Program tracks and radio stations.•

h SLEEP/TIMER

Set alarm/sleep timer.•

i DSC

Select a preset sound setting.•

j DBB

Turn on/off dynamic bass•

enhancement.

k REPEAT/SHUFFLE

Play tracks repeatedly/randomly.•

l VOL +/-

Adjust volume.•

m MAX

Turn on/off instant power boost.•

n /MENU

Stop play.•

Erase a program.•

Navigate through iPod/iPhone menu.•

o iPod/iPhone

Select iPod/iPhone source.•

p /

Search within a track/disc.•

Tune to a radio station.•

Skip to the previous/next track.•

Adjust time.•

Start or pause play.•

FWM200D_UM_ENG_05_1.1.indd Sec1:7 2011-3-9 10:08:20

8EN

Before using the remote control, install two

AAA batteries with correct polarity (+/-) as

indicated.

3 Get started

Caution

Use of controls or adjustments or•

performance of procedures other than herein

may result in hazardous radiation exposure or

other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Connect speaker

Insert speaker wires completely into the

speaker sockets at the back of the Hi-Fi system.

Prepare the remote control

Caution

Risk of explosion! Keep batteries away from•

heat, sunshine or re. Never discard batteries

in re.

Risk of decreased battery life! Never mix

•

different brands or types of batteries.

FWM200D_UM_ENG_05_1.1.indd Sec1:8 2011-3-9 10:08:21

English

Note

To exit clock setting mode, press• .

If clock is not set yet, when iPod/iPhone is

•

connected, the system synchronizes time from

the iPod/iPhone automatically.

Turn on

Press .

The Hi-Fi system switches to the last»

selected source.

Switch to standby mode

Press to switch the Hi-Fi system to standby

mode.

The clock (if set) appears on the»

display panel.

To switch the system to Eco Power Standby

mode:

In standby mode, press and hold for 2

seconds.

»[ECO POWER] (Eco power) scrolls

on the display, then the backlight turns

off.

Connect power

Caution

Risk of product damage! Make sure that the•

power supply voltage corresponds to the

voltage printed on the head of the AC power

cord.

Risk of electric shock! When you unplug the

•

power cord, always pull the plug from the

socket. Never pull the cord.

Note

Before connecting the AC power cord,•

make sure that you have completed all other

connections.

Set clock

1 In standby mode, press and hold CLOCK

SET for 2 seconds.

»[SET CLOCK] (set clock) scrolls on

the display, then [24 HOUR] or [12

HOUR] blinks.

2 Press / to select 12/24 hour format.

3 Press CLOCK SET to conrm.

The hour digits begin to blink.»

4 Repeat Steps 2 to 3 to set the hour and

minute.

FWM200D_UM_ENG_05_1.1.indd Sec1:9 2011-3-9 10:08:22

Otros manuales para FWM200D/05

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema estéreo de Philips

Philips

Philips MCD 906 Manual de usuario

Philips

Philips MCD388 Manual de usuario

Philips

Philips FWM998X/78 Manual de usuario

Philips

Philips FW748P Manual de usuario

Philips

Philips FW 690 Manual de usuario

Philips

Philips FW-C255 Manual de usuario

Philips

Philips DTD3190 Manual de usuario

Philips

Philips Streamium WACS700 Manual de usuario

Philips

Philips FW-C399/25/30/34 Manual de usuario

Philips

Philips Streamium MCi298Streamium MCi298/12 Manual de usuario

Philips

Philips MC-20 Manual de usuario

Philips

Philips FWM206 Manual de usuario

Philips

Philips FW 395C Manual de usuario

Philips

Philips FW545C Manual de usuario

Philips

Philips MCM275/98 Manual de usuario

Philips

Philips MCM394/12 Manual de usuario

Philips

Philips MC-M570/98 Manual de usuario

Philips

Philips FWD17 series Manual de usuario

Philips

Philips MCD263/78 Manual de usuario

Philips

Philips FW-C200 Manual de usuario

Philips

Philips DCD3020/51 Manual de usuario

Philips

Philips FW 330 Manual de usuario

Philips

Philips FWD410/77 Manual de usuario

Philips

Philips FWM397/BK Manual de usuario

Manuales populares de Sistema estéreo de otras marcas

LG CM3330B Manual de usuario

Sony

Sony SS-CEP50 Manual de usuario

Cetacea Sound

Cetacea Sound CVS-II Manual de usuario

Aiwa

Aiwa XR-H66MD Manual de usuario

Denon

Denon UCD-250 Manual de usuario

Sanyo

Sanyo DC-MX41i Manual de usuario

Sharp

Sharp CD-ES600V Manual de usuario

Exibel

Exibel BDX600-UK Manual de usuario

Sanyo

Sanyo DC-F320 Manual de usuario

Sharp

Sharp CD-C462 Manual de usuario

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manual de usuario

Aiwa

Aiwa XR-EM70 Manual de usuario

Cyrus

Cyrus Lyric Manual de usuario

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manual de usuario

RCA

RCA RS3965SB Manual de usuario

Sharp

Sharp XL-UH240 Manual de usuario

LG FB165DAB Manual de usuario

Sanyo

Sanyo DC-UB1475M/XE/UK Manual de usuario
