Philips FW M575 Manual de usuario

CD1/2/3 MUTE

REPEAT PROGRAM SHUFFLE

DSC DBB

DISPLAY DIM SLEEP

TITLE

ALBUM

AUX

TUNER

VOL

TIMER

ON/OFF

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

FM antenna AM antenna Remote Control

Quick Start Guide

Quick start guide

User manual

FWM575

FWM575 QUG_Eng 2006.2.8, 10:351

SetupSetup

Setting the clock

In standby or view clock mode, press CLOCK•TIMER once. In other

source mode, press CLOCK•TIMER twice.

Press àor árepeatedly to set the hour.

Press íor ërepeatedly to set the minute.

Press CLOCK•TIMER again to store the setting.

Connect the speaker cables.

Connect the AM and FM antennas.

Connect the power cable of the system.

Tip

See the User Manual for how to

connect other equipment to this

system.

IMPORTANT!

– To set clock in the Eco Power mode, press and hold STANDBY-ON/ECO

POWER

on the set for 3 seconds or more to switch to normal standby mode

first before proceeding with the procedures below.

FWM575 QUG_Eng 2006.2.8, 10:352

Enjoy

Playing a disc

Press OPEN•CLOSE to open the disc tray and load up to two

discs on the individual disc trays.To load the third disc, press DISC

CHANGE.

➜Make sure the label side of each loaded disc is facing up.

Press OPEN•CLOSE again to close the disc tray.

Use DSC 1/2/3 (or CD 1/2/3 on the remote control) to select a

disc for playback and then press ÉÅ to start playback.

To stop playback, press STOP9.

Programming and tuning to

radio stations

Press TUNER to select the tuner source.

Press PROGRAM for more than two seconds to program all

available stations in order of waveband.

Press íor ëuntil the desired preset station is displayed.

FWM575 QUG_Eng 2006.2.8, 10:353

PDCC-JS/JW-0606

Enjoy

Insert the USB device’s USB plug into the socket on the set ‘s foldable control panel

Press CD/USB once or more to select USB (or USB DIRECT on the remote control)

Play the USB’s audio files as you do with the albums/tracks on a CD

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

PHILIPS CONSUMER ELECTRONICS NORTH AMERICA

P.O. Box 671539, Marietta, GA. 30006-0026

http://www.philips.com

FWM575 QUG_Eng 2006.2.8, 10:354
