Philips MMS8085B Manual de usuario

2.1

MMS8085B

General information

Safety instructions

Please read carefully the safety mark on the back side

This mark is intended to alert the user from

the non isolated dangerous voltage within the

constitute a risk of electric shock to persons.

This mark is intented to alert the user for

important operating andservicinginstruction.

Warnings

•

Avoid sustained periods on high-volume use, and

do not turn the volume to maximum level while using

high output signal, such as Mobile Phone or DVD,

etc., as this will cause distortion and may damage the

loudspeaker cones.

•

when not in use.

•

Do not open the cover or back panel to avoid

electrical shock or any other accidents. No user-

serviceable parts are inside.

•

Only for indoor use.

•

Plug the system to the AC outlet with the right voltage

marked on the back panel of the Subwoofer.

•

The MAINS plug is used as the disconnect device, the

disconnect device shall remain readily operable.

Accessories

•

The product shall not be exposed to dripping or splashing

and that no objects filled with liquids, such as vases, shall

be placed on the product.

•

Batteries shall not be exposed to excessive heat such as

sunshine, fire or the like.

•

Attention should be drawn to the environmental

aspects of battery disposal.

Care and safety information

Avoid high temperatures, moisture, water and dust

•

Apparatus should not be exposed to dripping or

splashing of liquid.

•

Do not place any source of danger on the Subwoofer,

•

Do not install near heat sources.

Do not block any ventilation opening

•

Place the apparatus in a location with adequate

ventilation to prevent internal heat build up. Allow at

least 100cm (4 inches) of free space all around the

apparatus for adequateventilation.

•

At high volume the back cover of Subwoofer becomes

hot. Do nottouch it.

Care of the cabinet

•

Use a soft cloth slightly moistened to clean the cabinet.

Do not use a solution containing alcohol, spirits,

ammonia or abrasives.

Item

3.5mm stereo cable to 2RCA

Remote control

User manual

FM Antenna cable

Speaker Stand

Quantity

Connections

Subwoofer back panel

FM Antenna Connection

SD Card Slot USB Slot

Power Cord

Power On/Off Switch

Top & Back panel operation

(1)

(2)

(6) (7)

(3)

(4)

(5)

SOURCE

SD* and Bluetooth.

Audio, CD, FM, USB*,

5. VOLUME+/-

SOURCE

SD Slot

USB Slot

Rotate the knob clockwise to increase volume

anti-clockwise todecrease volume.

SD* Slot:

Press the SOURCE key to go to SD* MODE.

USB* Slot:

* AVAILABLE IF CONNECTED Press the SOURCE key to go to USB* MODE.

Remote controls

(1)

(3)

(4)

(6)

(8)

BT AUD/CD

FM USB/SD

(2)

(5)

(7)

(9)

-----

Turn on/Stand-by the speaker.

MUTE

------

Press “MUTE ”to activate or deactivate mute.

0~9

-----

Numeric keys, with the help of these keys you select

song or track in USB, and in FM, you can key in station frequency,

i.e. for 927 key in 92.7.

BT------

Press “BT” to enter Bluetooth mode.

AUD/ CD

-----

Press “AUD/ CD” to enter Audio in mode,

press again to enter CD mode.

-----

Press “FM” to enter FM mode.

USB/SD

-----

Press “USB/SD” to enter USB*/SD* mode, insert

(10) (11)

(12)

(13) (13) USB* to go for USB mode, while insert SD* card to go for SD* mode.

VOL+

-----

Volume up.

-----

Plays/pauses songs alternately in FM mode,

long press“ ”, it will enter into automatic search channel and

automatic save channel.

10.

-----

Play the previous song by pressing “”in USB* mode.

Choose previous channel by pressing “”in FM mode.

11.

-----

Play the next song by pressing “”in USB* mode.

Choose next channel by pressing “”in FM mode.

12.

VOL-

-----

Volume down.

2.MUTE

3.0~9

4.BT

5.AUD/ CD

6.FM

USB/ SD

VOL+

10.

1 1.

12.VOL-

13.BASS+/-

13. BASS-/+

-----

To decrease/ increase the bass.

Manual storage: press frequency like 91.1, the system will check if

station is available, suppose it is, then the system will judge whether

it had been stored or not,

if yes, it will start to play automatically,

if no, the system will store the station first, with station number after

* AVAILABLE IF CONNECTED last station number from auto search, and start to play.

Playing the speakers and subwoofer

System positioning:

The subwoofer is recommended to be put

on the floor to get a better acoustic euect.

For best possible surround sound, all the

speakers (except subwoofer) should be

placed at the same distance from the

listening position.

Place the front left and right speakers at

equal distances from the TV and at an angle

of approximately 45 degrees (horizontal)

from the listening position.

Helpful Hint:

Toavoidmagneticinterference, donot position

the speakers, too close to your TV.

Audio source / player

Bluetooth Operating Instruction

Troubleshooting

Warning -

Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty.

below before taking the system for repair. Ifyou are unable to remedy the problem by following hints

mentioned in below table, Consult your dealer or PHILIPS APSC for help.

Problem

Solution

No power.

No sound or distorted sound.

The remote control does not

function properly.

Low hum or buzzsound.

drive cannot be read.

Slow operation of the USB / SD

FM not properly tune d.

FM reception not good.

BT not working.

Check if the AC power cord is properly inserted into the AC mains socket.

Adjust the volume / select the correct source to choose the equipment

that you want to hear through the system.

Reduce the distance between the remote control and the system. Replace

the batteries with new ones / Point the remote control directly towards the

IR sensor (located on front panel of the subwoofer) / Check tha t the batteries

Place the product as far away as possible from electrical devices that may be

causing interference / Check power supply voltage and consult electrician.

Drive is

Big memory size USB / SD flash drive will take longer time to read

and play. / Take out USB / SD drive and insert it again properly.

Match with local frequency.

Reduce the distance or device is not paired.

In case these measures do not work contact the nearest PHILIPS service center or call at customer care numbers.

The Philips trademark and Philips shield emblem are

registeredtrademarksof koninklijkePhilipsN.V.used

under license.

This product has been manufactured by and sold

under the responsibility of Gibson Innovation India

Private Ltd. and Gibson Innovations India private Ltd.

is the warrantor in relation to this product.

Question?

Contact

Philips

www.india.philips.com

Or customercare.india@ philips.com

Satellite speaker

1 Way, 2 Speakers

Driver size

3 inches

Impedance

4 Ohm

Frequency range

120Hz - 20KHz

Dimension (mm) W x H x D

100 x 519 x 110

Weight

1.64 kgs

BT version

V3.0

BT range

Up to 10 meter

USB class support

UMS (USB mass

storage class)

USB capacity

Up to 16GB

USB playability

MP3 format file

Total system power

80W RMS

Satellite speaker power

17.5Wx2 RMS

Subwoofer power

45W RMS

Separation

>40 dB

SNR

>60 dB

Audio input socket

RCA

Audio output socket

RCA

Power consumption

80W

Subwoofer speaker

1 Way

Driver size

6.5 inches

Impedance

8 Ohm

Frequency range

20Hz - 4KHz

Dimension (mm) W x H x D

266 x 515 x 230

Weight

5.47 kgs

Philips

Multimedia Speakers 2.1

Bluetooth

MMS8085B

Music, movies & entertainment

With 80W sound output and bluetooth connectivity , these speakers are perfect for

playing music, games, movies and online videos on mobiles,MAC and PC. You can also

convert it in to a sound bar , on demand!

Listen with pleasure

• Rich bass

• Lifelike stereo sound to enhance your listening experience

Simplicity

• Compatible with any media

• AUX-in for easy connection to almost any electronic device

• I work with MAC and PC

• Convenient speaker-front volume and power control

• Works with any compatible stereo Bluetooth device

• USB Direct for easy MP3 music playback

Enhanced listening experience for different uses

• Total 80W sound output power
