Philips SRU5110/87 Manual de usuario
SRU 5110/87
EN Remote control 3
IT Telecomando 9
ES Mando a distancia 16
PT Telecomando 23
GR
∆ËϯÂÈÚÈÛÙ‹ÚÈÔ
30
TR Uzaktan kumanda 37
RU Пульта ДУ 44
PL Pilota 51
CS Dálkového ovládání 58
Register your product
and get support at
www.philips.com/welcome
Universal remote control
2
Table of contents
1 Your universal remote control 3
2 Installing the remote control 3-6
2.1 Inserting the batteries 3
2.2 Testing the remote control 4
2.3 Setting the remote control 4-6
3 Keys and functions 6
4 Extra possibilities 7
Restoring the original remote control settings 7
5 Frequently asked questions 8
6 Need help? 8
Code list of all brands / equipment 65-67
Information to the Consumer 69
1 Your universal remote control
Congratulations on your purchase and welcome to Philips.
To fully benefit from the support that Philips offers, register your product
at www:philips.com/welcome. For quick, clean and easy setup go to:
www.philips.com/urc
After installing the remote control it can operate the most-used functions
of almost any brand of TV.
2 Installing the remote control
2.1 Inserting the batteries
Press the cover inwards and slide it in the direction of the arrow.
Place two AAA type batteries into the battery compartment, as
shown.
Replace the cover and click it firmly into place.
3
2
1
1
1
3Installing the remote control
ENGLISH
2.2 Testing the remote control
The remote control has been programmed to operate the most-used
functions of almost any brand of TV. Because the SRU 5110 may use
different signals for each brand and even for different models of the same
brand, it is advisable to test whether your device responds to the
SRU 5110.The example below instructs you how to do this.
Turn your TV on manually or use the original remote control.
Tune to channel 1.
Check whether all the keys are working.
For an overview of the keys and their functions see
‘3. Keys and functions’.
• If the TV responds as it should to all of the key commands the SRU 5110
is ready for use.
Tip
If the TV does not respond at all or not to all of the key commands, follow
the instructions under ‘2.3 Setting the remote control’, or for online setup go
to: www.philips.com/urc.
2.3 Setting the remote control
This is only necessary if your TV does not respond to the SRU 5110.
If that is the case, the SRU 5110 does not recognize the brand and/or
model of your TV and you need to program the remote control to do so.
Turn on the TV manually or use the original remote control.Tune in
to channel 1.
Look up the brand of your TV in the code list at the back of this
manual.A four-figure code is shown for each brand.
Note the code for your brand.
3
3
2
1
2
2
2
1
4Installing the remote control
ENGLISH
ENGLISH
5Installing the remote control
Press the SET UP key
until the LED flashes twice and then remains
lit.
Then enter the code noted in step 2 using the numeric keys.
• The LED now flashes twice.
•If the LED flashes once for an extended period, the code has not
been entered properly or the wrong code has been entered.
Start again from step 2.
Press and hold the Standby key of the SRU 5110 until your TV
switches off (standby).
Then release the key immediately.
• The SRU 5110 is now set to operate your TV.
Check if you can operate all functions on your TV with the SRU 5110.
• If a key does not function properly, keep it pressed until it works.
Then release the key immediately.
Repeat this for every key that does not work.
• If the TV responds to all of the key commands, the SRU 5110 is
ready for use.
Do not forget to note your code.
Keep the SET UP key pressed for 5 seconds to exit setup mode.
• When no key is pressed for 2 minutes or more the remote control will
exit setup mode automatically.
7
7
7
6
6
6
5
5
5
4
4
4
3
Full search setup
If your code does not work or if the brand of your device is not
mentioned in the code list, you can try setting the remote control with
full search setup.
Press the SET UP key u
ntil the LED flashes twice and then remains
lit.
Press and hold the Standby key of the SRU 5110 until your TV
switches off (standby).
Then release the key immediately.
• The SRU 5110 is now set to operate your TV.
Full search setup takes about 5 minutes.
3 Keys and functions
The illustration on page 2 gives an overview of all keys and their functions.
1 SET UP enters setup mode.
2 Text TV on/off.
Electronic Program Guide.
Wide screen TV.
Text TV off.
3 Text TV color keys. Used in text mode and in
some on-screen menus.
4 MENU turns the menu on and off.
5 Cursor keys cursor up, down, left, right in a menu.
6 INFO displays on-screen channel information.
7smutes the TV sound.
8 - VOL + adjusts the TV volume.
9 Numeric keys direct choice of channels and other functions.
10 A/V switches between external inputs of your
equipment.
9
9
2
8
8
1
Installing the remote control
ENGLISH
6
7
ENGLISH
Keys and functions
11 PICTURE changes picture / screen settings.
AUDIO changes audio settings.
enlarges Text TV picture.
shows subtitle text.
SLEEP activates / deactivates sleep timer.
holds current Text TV page.
12 /selects between one- and two-figure channel
numbers.
13 P1P selects previous programme / channel
14 -PROG + selects a previous or following channel.
15 OK confirms your selection.
16 BACK jumps back one level in the menu or turns off the
menu.
17 yStandby switches TV on or off.
18 LED • blinks in setup mode.
• lights up when a remote control command is
sent.
Note
If the device does not respond at all, or not to all of the key commands,
follow the instructions under ‘2.3 Setting the remote control.
4 Extra possibilities
Restoring the original functions of your remote control
Keep keys 1 and 6 on the SRU 5110 pressed simultaneously for three
seconds, until the LED flashes twice and then remains lit.
Press keys 9, 8 and 1, in that order.
• The LED flashes twice.
All original functions have now been restored and any extra functions
have been deleted.
11
11
2
10
10
1
5 Frequently asked questions
In this chapter you find answers to the most frequently asked questions
about your universal remote control.
The TV does not respond and the LED key does not flash when I
press a key.
Replace the old batteries with two new AAA batteries.
The TV does not respond but the SET UP key does flash when a
key is pressed.
Point the SRU 5110 at the TV and make sure that there are no
obstructions between the SRU 5110 and the TV.
The SRU 5110 does not respond properly to commands.
Try programming the SRU 5110 again.
If the TV still does not respond, call our helpline.
The Text TV keys do not work.
• Find out whether your TV is equipped with Text TV.
• Maybe the SRU 5110 has to be adapted to the model of the device.
Call our helpline for details.
6 Need help?
If you have any questions about the SRU 5110, you can always contact us.
You will find our contact details after the code list at the back of this
manual.
Read this manual carefully before you make a call.
You can solve most of the problems yourself. If you cannot find any
answers to your problems, write down the details of your device in the
code list at the back of this manual.
This will help our operators to assist you better and more quickly. Look
up the numbers of the models in the instructions accompanying the
device or on the back of your device.When you call our helpline, make
sure the device is to hand so that our operators can help you determine
whether your remote control is working properly.
The model number of your Philips universal remote control is
SRU 5110/87.
Date of purchase: ......../......../........
(day/month/year)
8Need help?
ENGLISH
9
ITALIANO
Installazione del telecomando
Sommario
1 Telecomando universale 9
2 Installazione del telecomando universale 9-12
2.1 Inserimento delle batterie 9
2.2 Test del telecomando 10
2.3 Impostazione del telecomando universale 10-12
3 Tasti e relative funzioni 13-14
4 Possibilità aggiuntive 14
Ripristino delle impostazioni originali del telecomando 14
5 Domande frequenti 14-15
6 Assistenza 15
Elenco dei codici di tutte le marche/apparecchi 65-67
Informazioni per il consumatore 70
1 Telecomando universale
Congratulazioni per l’acquisto e benvenuto in Philips!
Per trarre il massimo vantaggio dall’assistenza fornita da Philips, registrare
il proprio prodotto sul sito: www.philips.com/welcome
Per un’installazione diretta, facile e veloce andare sul sito Internet:
www.philips.com/urc
Una volta installato, il telecomando può gestire le funzioni più utilizzate
della maggior parte delle marche di televisori.
2 Installazione del telecomando
2.1 Inserimento delle batterie
Premere il coperchio verso l’interno e farlo scorrere nella direzione
indicata dalla freccia.
Inserire due batterie AAA nel vano batterie come mostrato.
Riposizionare il coperchio fino a che non scatta in posizione.
3
2
1
1
1
10 Installazione del telecomando
2.2 Test del telecomando
Il telecomando è stato programmato per gestire le funzioni più utilizzate
della maggior parte delle marche di televisori. Poiché il modello SRU
5110 può utilizzare segnali differenti per ciascuna marca o per vari
modelli della stessa marca, è consigliabile verificare se il dispositivo
risponde all’SRU 5110. L’esempio riportato di seguito fornisce le
informazioni necessarie a riguardo.
Accendere il televisore manualmente o tramite il telecomando
originale.Andare sul canale 1.
Controllare che tutti i tasti funzionino.
Per una panoramica dei tasti e delle relative funzioni, vedere il
capitolo ’3.Tasti e relative funzioni’.
• Se il televisore risponde correttamente a tutte le funzioni dei tasti, il
modello SRU 5110 è pronto per l’uso.
Suggerimento
Se il televisore non risponde, o non risponde a tutti i comandi, seguire le
istruzioni del capitolo "2.3 Impostazione del telecomando" o, per
istruzioni online, andare alla pagina: www.philips.com/urc
2.3 Impostazione del telecomando
Le seguenti istruzioni sono necessarie solo in caso di mancata
comunicazione tra il televisore e il modello SRU 5110.
In questo caso, il telecomando SRU 5110 non riconosce la marca e/o il
modello del televisore ed è quindi necessario programmare il teleco
Accendere il televisore manualmente o tramite il telecomando
originale.Andare sul canale 1.
Cercare la marca del proprio televisore nell’elenco dei codici sul
retro del manuale. Ciascuna marca è seguita da un codice a quattro
cifre.
Annotare il codice della marca.
3
3
2
1
2
2
2
1
ITALIANO
Otros manuales para SRU5110/87
1
Tabla de contenidos
Idiomas:
Otros manuales de Mando a distancia de Philips
Philips
Philips SRP2004WM Manual de usuario
Philips
Philips SRU 3040/10 Manual de usuario
Philips
Philips 14PT1686/01P Manual de usuario
Philips
Philips SBCRU641/00 Manual de usuario
Philips
Philips PM525S - Phlips 5 Device Universal Remote... Manual de usuario
Philips
Philips SRP9348D/27 Manual de usuario
Philips
Philips RC9800I/05 Manual de usuario
Philips
Philips SBCRU610/00 Manual de usuario
Philips
Philips SRU 560/87 Manual de usuario
Philips
Philips 22AV1106B Manual de usuario
Philips
Philips ipronto TSi6400 Manual de usuario
Philips
Philips SRU9600/17 Manual de usuario
Philips
Philips City line Manual de usuario
Philips
Philips MC-110 Manual de usuario
Philips
Philips SRU3030/10 Manual de usuario
Philips
Philips Perfect replacement SRC2063WM Manual de usuario
Philips
Philips SRP2024A/27 Manual de usuario
Philips
Philips SBC RU 230/00 Manual de usuario
Philips
Philips Perfect replacement SRP5107/27 Manual de usuario
Philips
Philips SRU 5030/87 Manual de usuario
