Philips SRP4319S-27 Manual de usuario

User manual

v1 05/20

Home power

SRP4319S/27

Introduction ....................................................... 2

Setup .................................................................. 3

Button Functions............................................... 4

Programming Your Remote ..............................6

Direct Code Entry.........................................6

Auto Code Search......................................... 7

Controlling Combo Devices.........................9

Using Your Remote.......................................... 10

Primary Audio Control ............................... 10

Code Identication...................................... 11

Reset to Factory Settings........................... 11

Troubleshooting ...............................................12

Warranty............................................................13

FCC Statement ................................................ 14

Congratulations on your purchase of this

Philips Universal Replacement Remote

Control. Designed primarily for Samsung

devices, this universal remote includes

preprogrammed buttons that allow you

to immediately control your Samsung

equipment. For example, the device buttons

(TV, S-BAR and B-RAY) are preprogrammed to

control a corresponding Samsung TV, sound

bar or Blu-ray™/DVD player. Samsung-specic

function keys (Samsung hub, e-manual,

s.mode, ch.list, etc.) are preprogrammed

for full functionality and navigation of your

Samsung device. Additionally, this remote

is preprogrammed for Roku boxes, using

the STRM button, compatible with all major

brands and capable of operating thousands

of audio/video devices that complete your

home theater setup.

Table of Contents

For remote control help:

byjasco.com/50231i

Your universal remote requires two (2) AAA

batteries (not included). Alkaline batteries

are recommended.

Battery Installation

1. On the back of the remote, pull down on

the textured surface and slide battery

cover downward to remove.

2. Match the (+) and (-) marks on the

batteries to the (+) and (-) marks inside

the battery compartment, then insert two

(2) AAA batteries. Be sure to use fresh

batteries.

3. Position battery cover slightly below

opening and push upward to lock into

place.

NOTE:If your remote stops operating properly,

replace the batteries with new ones.

Battery Precautions

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-

zinc), or rechargeable (Ni-Cd, Ni-MH, etc.)

batteries.

• Always remove old, weak or worn-out

batteries promptly and recycle or dispose

of them in accordance with local and

national regulations.

Battery Saver

Your remote automatically turns o if the

buttons are held down for more than 8

seconds. This will save your batteries should

your remote get stuck in a place where the

buttons remain depressed (e.g., between

sofa cushions).

Code Saver

You have up to 10 minutes to change the

batteries in your remote without losing the

codes you have programmed.

Setup

Button Functions

816

812

814

9 1

9 22

9 24

9 28

9 26

Button Functions

1. Power - Turns devices ON/OFF

2. Input - Select video inputs

3. TV, B-RAY, S-BAR, STRM - Selects the

device to control

4. Numbers - Enter numbers for direct channel

selection

5. Dash (-) - Use to select digital channels, e.g., 4-1

6. Enter - Some devices require enter to be

pressed after channel selection

7. Mute - Mutes sound

8. Channel up/down

9. Volume up/down

10. Previous channel - Returns to the

previously selected channel

11. Menu - Displays the on-screen menu

12. Home - Access features on streaming devices

Guide - For cable/satellite receivers

13. Samsung hub - Activates Samsung menu

14. Info - Displays on-screen show/content information

15. Tools - Displays frequently used functions on the TV

16. Ok - Selects menu items for the controlled device

17. Up/down/left/right menu navigation

18. Exit -Exit on-screen menus

19. Back - Returns to previous screen

20. ABCD - Access additional features for

DVRs, cable and satellite receivers

21. P.mode - Selects picture mode

22. MTS - Selects stereo, mono or

separate audio program (SAP)

23. S.mode - Selects sound eect options

24. Channel list - Displays list on the screen

25. e-manual - Displays e-manual guide

26. Picture size -Selects picture size

27. Setup - Used to program the remote

28. DVD/Blu-ray™open/close - Open/close a player, or

List features on cable/satellite receivers

29. Closed caption - Selects closed caption options

30. Record, play, stop, rewind, fast forward, pause

Programming Your Remote

Your remote is designed to control multiple

audio/video devices. To use, you will need to

program the remote for your devices. There

are two dierent methods you can use to

program the remote, Direct Code Entry or

Auto Code Search.

• The Direct Code Entry method is the

recommended method, as it is the simplest

and quickest method in most cases.

• The Auto Code Search method searches

through all the codes in the remote to nd

a code for your device.

NOTE:This remote comes preprogrammed for

Roku®boxes and Samsung devices. Press TV,

S-BAR and B-RAY for corresponding Samsung

devices, and STRM for Roku boxes.

Direct Code Entry (Recommended)

1. Locate the Code List included

with your remote. Find the

section for the type of device you

wish to control, (e.g., TV, STRM,

DVD, AUD, CBL, AUX). Locate the

brand of your device and circle all

the remote codes for the brand.

2. Press and hold down the SETUP

button on the remote until the

red light on the remote control

turns on. Release the SETUP

button. The red light will

remain on.

NOTE:The red light will either be a

small light at the top of the remote

or the power ON/OFF button.

3. Press and release the device

button on the remote for the type

of device you wish to control,

(e.g., TV, S-BAR, B-RAY, STRM).

The red light will blink once and

remain on.

NOTE:Any of the device buttons

on the remote can be programmed

to control any of your devices. For

example, you can use the AUD

device button on the remote to

Programming Your Remote

control a satellite receiver, digital

converter box, streaming media

player or any device category in

the Code List.

4. Use the number buttons on the

remote to enter the rst 4-digit

remote code you circled in the

Code List in Step 1. The red light

will turn o after entering the

fourth digit.

5. Point the remote at the device.

Test the buttons on the remote

to see if the device responds as

you would expect. If the buttons

do not operate the device,

return to Step 2 above and use

the next code that you circled

for that device.

6. Repeat steps 1 – 5 for each

device you wish to control.

Programming Notes

• Some codes may operate only a few

functions of your device. There may

be another code in the Code List that

controls more functions. Test other codes

in the Code List for more functionality.

• If you do not nd a remote code that

works your device or there are no codes

in the Code List for your device, use the

Auto Code Search method in the next

section to program your remote.

• For combination devices such as a TV/

DVD combo or TV/VCR combo, you may

have to enter a code for each device.

• Write down the remote codes used to

program the remote for future reference.

Auto Code Search

Auto Code Search is a process where you can

search through all the codes stored in the

remote to nd a code for your device. It is

recommended that you read through all the

steps below to familiarize yourself with Auto

Code Search before starting the process.

Programming Your Remote

1. Manually turn on the device you

wish to control.

NOTE:The Auto Code Search

process cannot be used for devices

without power ON/OFF capability.

Use the Direct Code Entry method in

these cases.

2. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns

on. Release the SETUP button.

The red light will remain on.

NOTE:The red light will either be a

small light at the top of the remote

or the power ON/OFF button.

3. Press and release the device

button on the remote for the type

of device you wish to control, (e.g.,

TV, S-BAR, B-RAY, STRM). The red

light will blink once and remain on.

4. With the remote pointed at the

device, press and release the

POWER button on the remote.

The remote will send 10 dierent

codes to the device. The red light

will blink once for each code and

remain on after sending the 10

codes.

Did the device turn o?

• If YES, go to Step 5.

• If NO, repeat Step 4 to test the

next 10 codes.

5. Manually turn the device back on.

6. With the remote pointed at the

device, press and release the

VOL button. The remote will re-

send the rst code of the 10 codes

from Step 4. The red light will blink

once and remain on.

Did the device turn o?

• If YES, you have found a code

for the device. Press and

release the same device button

you pressed in Step 3. This will

Programming Your Remote

store the code in the remote.

Go to Step 7.

• If NO, continue to press and

release the VOL button

until the device turns o

to test the other 9 codes

from Step 4. Be sure to wait

approximately 3 seconds after

each VOL button press

to allow the device time to

respond to the code. When

the device turns o, you have

found a code for your device.

Press and release the same

device button pressed in Step

3. This will store the code in

the remote. Go to Step 7.

NOTE:

• The VOL button can be used

to go backwards through each

batch of 10 codes.

• The red indicator light will ash

2 times after testing the rst or

last code in each batch of 10.

7. Use the remote to turn the

device back on. Test the buttons

on the remote to see if the

device responds as you would

expect. If the buttons do not

operate the device, return to

Step 2 and repeat this process

to search for a better code to

operate the device.

8. Repeat this process for each

device you wish to control.

Controlling Combo Devices

Some combo devices (e.g. TV/VCR, TV/DVD,

DVD/VCR, etc.) will require you to set up

two dierent device buttons to control both

parts of the combo device. For example, if

you have a TV/DVD combo, you may need

to set up one code under the TV button to

control the TV and a separate code under

the DVD button to control the DVD.

Using Your Remote

Primary Audio Control

The Primary Audio Control feature allows

you to select a single device that the volume

buttons always control. For example, the

remote can be in TV mode while the volume

buttons control the volume on your audio

receiver or sound bar instead of your TV.

Enabling Primary Audio Control

1. Press and hold down the SETUP

button on the remote until the

red light on the remote control

turns on. Release the SETUP

button. The red light will

remain on.

2. Press and release the device

button (TV, S-BAR, etc.) on the

remote for the device you wish

to control the volume.

3. Press and release the

MUTE button.

4. Press and release the VOL

button. The red light will blink

twice and turn o.

Disabling Primary Audio Control

1. Press and hold down the SETUP

button on the remote until the

red light on the remote control

turns on. Release the SETUP

button. The red light will

remain on.

2. Press and release the device

button (TV, S-BAR, etc.)

programmed to control the

Primary Audio Control feature.

3. Press and release the

MUTE button.

4. Press and release the VOL

button. The red light will blink

twice and turn o.

Tabla de contenidos

Idiomas:

Otros manuales de Mando a distancia de Philips

Philips

Philips SRP5004/53 Manual de usuario

Philips

Philips SBCRU621/00 Manual de usuario

Philips

Philips SRU3007/27 Manual de usuario

Philips

Philips Prestigo SRU8015 Manual de usuario

Philips

Philips SBCRU125 Manual de usuario

Philips

Philips SRU4002X/10 Manual de usuario

Philips

Philips SRU5130/87 Manual de usuario

Philips

Philips SRU 740/10 Manual de usuario

Philips

Philips SRP5002 Manual de usuario

Philips

Philips US2-PMDVD6T Manual de usuario

Philips

Philips Prestigo SRU6006/10 Manual de usuario

Philips

Philips SRU3003WM - Universal Remote Control Manual de usuario

Philips

Philips SRP4004/27 Manual de usuario

Philips

Philips Perfect replacement SRP5107/27 Manual de usuario

Philips

Philips SBCRU545 Manual de usuario

Philips

Philips RR1 GV Manual de usuario

Philips

Philips Perfect replacement SRU5107WM Manual de usuario

Philips

Philips SRU5040/55 Manual de usuario

Philips

Philips TSU6000 Manual de usuario

Philips

Philips SBCRU510/00U Manual de usuario

Philips

Philips SRU8112/27 Manual de usuario

Philips

Philips Perfect replacement SRP2003 Manual de usuario

Philips

Philips SRP5018 Manual de usuario

Philips

Philips SpaceWise Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
