Philips PET1002 Manual de usuario

PET1002

Portable DVD Player

User manual

Manuel d'utilisation

Manual del usuario

Benutzerhandbuch

FRONT VIEW

REAR VIEW

English FUNCTIONAL OVERVIEW

Main unit controls ( see figure 1)

13,4,1,2..........Up / down / left / right cursor

OK .........................Confirm selection

2OSD.......................OnScreen Display on / off

MENU .................Display MENU page

VIDEO OUT .........Selection video format

– COMPONENT OUT(YPBPR)

– COMPONENT OUT(YCBCR)

– A/V or S-VIDEO OUT

– A/V IN (AUX)

MONITOR ...........Selection display

To adjust the brightness with 12

To adjust the color with 12

To adjust the screen of 16:9 or 4:3 with 12

SOUND ...............Turn virtual on/off

3;... .........................Pause playback

2............................Start / resume playback

9............................Press twice to stop playback

J( /§... ...........For previous (J( )or next (§)chapters, tracks or titles

5/6... ..............Search backward (5 )or search forward (6)

40OPEN...............Open disc door to insert or remove disc

FUNCTIONAL OVERVIEW

Front of player ( see figure 1)

5POWER/CHG ......Power and charging indicator

IR ..........................Remote sensor

Left of player ( see figure 1)

6ON . POWER . OFF .....Switche the player on / off

7........... Headphones jack

Right of player ( see figure 1)

8VOLUME F............. Volume control.

9A/V OUT....................... Audio/Video output jack

0A/V IN........................... Audio/Video input jack

!DIGITAL AUDIO OUT Digital audio output jack

@S-VIDEO.......................S-Video output jack

#COMPONENT VIDEO.Component video output jack

$DC IN 9V....................Power supply socket

CAUTION

Use of controls or adjustments or performance of procedures

other than herein may result in hazardous radiation exposure

or other unsafe operation.

REMOTE CONTROL

Remote controls ( see figure 2)

13,4,1,2..........Up / down / left / right cursor

OK .........................Confirms selection

2VOL+ / -................Volume control

3J( /§... ...........For previous (J( )or next (§)chapters, tracks or titles

;... .........................Pauses playback

2...........................Starts / resumes playback

9............................Press twice to stop playback

5/6... ..............Search backward (5 )or search forward (6)

4OSD.......................OnScreen Display on / off

...........................Slow motion

5AUDIO ..................Audio langauge selector

ZOOM...................Enlarges video image

6A > B.....................To repeat or loop a sequence in a title

PLAY-MODE ........Selects play order options

70 - 9.......................Numeric keypad

8MUTE....................Muting player volume

REPEAT ................Repeats chapter / title / disc

9RETURN ...............For VCD menu page

ANGLE..................Selects DVD camera angle

0SUBTITLE ............Subtitle language selector

LANGUAGE .........Language selector

!MENU...................Displays MENU page

@SETUP ..................Enters SETUP menu

#Infra Red port

$BATTERY COMPARTMENT

INTRODUCTION

Your portable DVD player

Your portable DVD player plays digital video discs conforming to the universal

DVD Video standard. With it, you will be able to enjoy full-length movies with

true cinema picture quality, and stereo or multichannel sound (depending on the

disc and on your playback set-up).

The unique features of DVD-Video, such as selection of soundtrack and subtitle

languages, and of different camera angles (again depending on the disc), are all

included.

What’s more, parental lock lets you decide which discs your children will be able

to see. You will find your player remarkably easy to use with the On-Screen

Display and player display in combination with the remote control.

Unpacking

First check and identify the contents of your package, as listed below:

• Portable DVD player • Remote Control

• Car adaptor (12V) • AC power adaptor

• Rechargeable battery pack • User Manual

• Warranty • Audio / Video cable

• S-Video cable • Component Video cable

• Travel bag (subject to region)

Placement

• Place the player on a firm, flat surface.

• Keep away from domestic heating equipment and direct sunlight.

• If the player cannot read CDs/DVDs correctly, try using a commonly

available cleaning CD/DVD to clean the lens before taking the player to be

repaired. Other cleaning methods may destroy the lens.

• Always keep the disc door closed to avoid dust on the lens.

• The lens may cloud over when the player is suddenly moved from cold to warm

surroundings. It is then not possible to play a CD/DVD. Leave the player in a warm

environment until the moisture evaporates.

INTRODUCTION

Playable disc formats

In addition to DVD-Video disc, you will also be able to play all Video CDs and

audio CDs (including CDR, CDRW, DVD±R and DVR±RW).

DVD-Video

Depending on the material on the disc (a movie, video clips,

a drama series, etc.) these discs may have one or more

Titles, and each Title may have one or more Chapters. To

make access easy and convenient, your player lets you move

between Titles, and also between Chapters.

Video CD

Depending on the material on the disc (a movie, video clips, a

drama series, etc.) these discs may have one or more Tracks,

and tracks may have one or more indexes, as indicated on

the disc case.To make access easy and convenient, your

player lets you move between tracks and between indexes.

Audio CD / MP3 / WMA CD

Audio CDs / MP3/WMA CD contain music tracks only. You can

play them in the conventional way through a stereo system

using the keys on the remote control and/or main unit, or via

the TV using the On Screen Display (OSD).

CD with JPEG files

You can also view JPEG still photos on this player.

DivX video discs

You can also view discs containing DivX®video on this player.

• Official DivX®CertifiedTM product

• Plays DivX®5, DivX®4, DivX®3, and DivX®VOD video content.

Zero Bright DotTM

Enjoy highest-quality images that are free from annoying blank spots on

the LCD screen. LCD displays commonly have imperfections, termed as

'bright dots' by the LCD industry. A limited number of bright dots were

once considered an inevitable side effect of LCD mass production. With

Philips' strict quality control procedures used in our Portable DVD Players,

our LCD displays are produced with zero tolerance for bright dots.

Select Portable DVD Players come with Philips Zero

Bright DotTM

Policy to guarantee optimal screen quality.

Warranty service varies from region to region. Contact your local Philips

representative for more detailed information.

GENERAL INFORMATION

Power Sources

This unit operates on a supplied AC adaptor, car adapter, or a rechargeable

battery pack.

• Make sure that the input voltage of the AC adaptor is in line with the local

voltage. Otherwise, the AC adaptor and unit may be damaged.

• Do not touch the AC adaptor with wet hands to prevent electric shock.

• When connecting with car power (cigarette lighter) adaptor, be sure the

input voltage of the adaptor is identical with car voltage.

• Unplug the AC adaptor from the outlet or remove the battery pack when

the unit is not used for long periods of time.

• Hold the plug to disconnect the AC adaptor. Do not pull the power cord.

Safety and maintenance

• Do not disassemble the unit for laser rays are dangerous to eyes.

Any service should be done by qualified service personnel.

• Unplug the AC adaptor to cut the power if liquid or objects get inside the unit.

• Take care not to drop the unit or subject it to strong shocks, which may

cause malfunction.

• Hearing safety: listen at a moderate volume. Using headphones at high

volume can impair your hearing.

• Important (for models with by-packed headphones): Philips guarantees

compliance with the maximum sound power of its audio players as

determined by relevant regulatory bodies only with the original model of

provided headphones. In case this one needs replacement, we recommend that

you contact your retailer to order a model identical to that of the original

provided by Philips.

• Traffic safety: do not use while driving or cycling as you may cause an accident.

• Do not expose to excessive heat caused by heating equipment or

direct sunlight.

• This product is not waterproof: do not allow your player to be submersed

in water. Water entering the player may cause major damage.

• Do not use any cleaning agents containing alcohol, ammonia, benzene,

or abrasives as these may harm the player.

• Apparatus shall not be exposed to dripping or splashing. Do not place any

sources of danger on the appartus (e.g. liquid filled objects,lighted candles)

• Do not touch the lens!

Note: When the player is in use for a long period of time, the surface will be

heated. This is normal.

GENERAL INFORMATION

Handling discs

• Do not attach paper or tape to the disc.

• Keep the disc away from direct sunlight or heat

sources.

• Store the disc in a disc case after playback.

• To clean, wipe the disc outwards from the center

with a soft, lint-free clean cloth.

On handling the LCD screen

The LCD is manufactured using high precision technology. You may, however, see

tiny black points and/or bright points(red,blue,green) that continuously appear on

the LCD. This is a normal result of the manufacturing process and does not

indicate a malfunction.

Environmental information

We have reduced the packaging to its minimum and made it easy to separate into

mono materials: cardboard, PS, PE and PET.

Your set consists of material which can be recycled if disassembled by a

specialized company. Please observe the local regulations to dispose of

packaging, exhausted batteries and old equipment.

“DivX, DivX” Certified, and associated logos are trademarks of DivXNetworks, Inc.

and are used under license.”

All other brand and product names are trademarks of their respective companies

or organizations.

Unauthorized duplication of any recordings downloaded from the internet or made

from CDs / VCDs / DVDs is a violation of copyright laws and international

treaties.
