Philips SimplyFLO Manual de usuario

1076809

1076808 R03

LZ 04/10/2013 simplyFLO

Table of Contents

Introduction ��1

Intended Use��1

Contraindications��1

Device and Accessories Description��1

simplyFLO System ��1

Warnings and Cautions��2

Symbol Key��5

How to Contact Philips Respironics��5

System Overview��6

Operating the simplyFLO Device��8

Alarm Indicators and Screen Symbols��11

Troubleshooting��14

Connecting the Optional Humidier ��15

Caring for your simplyFLO System��16

Cleaning the Device ��16

Cleaning the Accessories��16

Device Storage ��17

Preventive Maintenance�� 17

Device Disposal��17

Traveling With Your System��17

Specications��18

Standards Compliance ��19

Classication ��19

EMC Information��20

Limited Warranty��22

English

simplyFLO User Manual

Introduction

Your health care professional has determined that supplemental oxygen is

of benet to you and has prescribed a portable oxygen concentrator set at

a specic ow setting to meet your needs� DO NOT change the ow settings

without consulting with your health care professional� Please read and

understand this entire manual before using the device�

Intended Use

The Philips Respironics simplyFLO transportable oxygen concentrator is for

prescription use by patients requiring high concentrations of oxygen on a

supplemental basis�

Contraindications

• Thisdeviceisnotintendedtobelife-sustainingorlife-supporting.

• Thisdeviceisnotintendedfornewbornandinfantuse.

Device and Accessories Description

The simplyFLO transportable oxygen concentrator, its features, and its

accessories are described in detail in this manual� Read and understand it

completely before operating the device�

This manual applies to the AC Power Supply and AC Power Cord accessories�

This manual does not apply to the following accessory items sold separately:

• StandardSingleLumenNasalCannula

• Humidier

• DCPowerSupply

• TravelCase

simplyFLO System

The device comes with the following items� If any are missing, contact your

equipment provider�

• ThisUserManual

• ACPowerSupplyandCord

simplyFLO User Manual

Warnings and Cautions

Caution: U�S� federal law restricts this device to sale by or on the order of a

physician�

Warnings

A warning represents the possibility of harm to the operator or patient�

• Theoperatorshouldreadandunderstandthisentiremanualbefore

using the device�

• Thedeviceisnotintendedforlifesupport.Wheretheprescribing

health care professional has determined that an interruption in the

supply of oxygen, for any reason, may have serious consequences

to the user, an alternate source of oxygen should be available for

immediate use�

• Geriatricoranyotherpatientunabletocommunicatediscomfort,or

hear or see the alarms while using this device, may require additional

monitoring�

• Oxygensupportscombustion.Oxygenshouldnotbeusedwhile

smoking or in the presence of an open ame�

• Donotusethedeviceinthepresenceofaammableanaesthetic

mixture in combination with oxygen or air, or in the presence of

nitrous oxide�

• Donotuseoilorgreaseontheconcentratororitscomponentsas

these substances, when combined with oxygen, can greatly increase

the potential for a re hazard and personal injury�

• Ifyounoticeanyofthefollowing,discontinueuseandcontactyour

home care provider:

- unexplainedchangesintheperformanceofthisdevice

- unusualorharshsounds

- droppedormishandleddeviceorthepowersupply

- waterspilledintotheenclosure

- brokenenclosure

• UseonlywithPhilipsRespironicssimplyFLO AC power supply�

• UseonlyapprovedsimplyFLO accessories�

simplyFLO User Manual

• RepairsandadjustmentsmustbeperformedbyPhilipsRespironics

authorized service personnel only� Unauthorized service could cause

injury, invalidate the warranty, or result in costly damage�

• Periodicallyinspectelectricalcords,cables,andthepowersupplyfor

damage or signs of wear� Discontinue use and replace if damaged�

• Toavoidelectricshock,unplugthedevicebeforecleaning.DONOT

immerse the device in any uids�

• Yourhomecareproviderisresponsibleforperformingappropriate

preventive maintenance at the intervals recommended by Philips

Respironics�

• Forproperoperation,yourdevicerequiresunobstructedventilation.

Always make sure any openings in the case are not obstructed by

items which may impede ventilation� Do not place the device in a

small closed space (such as a closet)� The device should not be used

adjacenttoorstackedwithotherequipment.Formoreinformation,

contact your home care provider�

• Donotuseanextensioncord.

• Deviceoperationaboveoroutsideofthevoltage,temperature,

humidity and/or altitude values specied may decrease oxygen

concentration levels�

• Neverdroporinsertanyobjectintoanyopening.

• Beawarethattheelectricalcordand/ortubingcouldpresenta

tripping or strangulation hazard�

• UseonlypowercordssuppliedbyPhilipsRespironicsforthisdevice.

Use of power cords not supplied by Philips Respironics may cause

overheating or damage to the device and may result in increased

emissions or decreased immunity of the equipment or system�

• Theusershouldbeawarethatthereisnobackuppower.

• MedicalElectricalEquipmentneedsspecialprecautionsregarding

EMC and needs to be installed and put into service according to the

EMC information provided in this manual�

• Placethedeviceinalocationsoastoavoidpollutantsandfumes.

• PortableandMobileRFCommunicationsEquipmentcanaect

Medical Electrical Equipment� See the EMC section of this manual

fordistancestoobservebetweenRFGeneratorsandthesimplyFLO

device to avoid interference�

Warnings (continued)

simplyFLO User Manual

Cautions

A caution represents the possibility of damage to the equipment�

• Donotimmersethedeviceorallowanyliquidtoentertheenclosure.

Note: Additional warnings, cautions, and notes are located throughout the

manual�

simplyFLO User Manual

Symbol Key

Consult

accompanying

instructions

for use

REF Model number

No smoking SN Serial number

No oil or grease TypeBFAppliedPart

Keep away from open

ames

Drip proof equipment

Do not disassemble ~AC Power

DC power Class II (Double

Insulated)

Caution: U�S� federal

law restricts this

device to sale by or

on the order of a

physician�

Note: Also see the section on alarm indicators and screen symbols�

How to Contact Philips Respironics

To have your device serviced, contact your home care provider� If you need

to contact Philips Respironics directly, call the Customer Service department

at1-724-387-4000or1-800-345-6443(USorCanada).Youcanalsousethe

following address:

simplyFLO User Manual

System Overview

BeginbybecomingfamiliarwithyoursimplyFLO device�

Item Description Function

1 Control Panel Control switches and LCD display

2 Carrying Handle Hand grip area for lifting and transporting

the device

3 Patient Cannula

Connector

Oxygen output and connection point for

patient cannula

4 Power Input

Connector

ConnectionpointforPhilipsRespironics-

provided external power supplies: AC line

voltage

5Air Exhaust Vent Air outlet for enclosure ventilation fan

6Air Intake Vent Air inlet for enclosure ventilation fan

7 Data Port Input-Outputdatacommunicationwiththe

device�

Caution: For use by authorized service

personnel only.

simplyFLO User Manual

Control Panel

Item Description Function

1Power TurnsthedeviceOnandO

2 Alarm Silence Turnsaudiblealarmso

3 Display Screen Shows information about the operating

status of the device

4 Plus (+)/Minus (–) + Increases the displayed setting; – Decreases

the displayed setting

5 Patient Cannula

Connector

Oxygen output and connection point for

patient cannula

Run Time Screen Description

Item Symbol Description Function

1 Operating Mode Fordetaileddescriptions,referto

the“Alarm Indicator and Screen

Symbols”section�

2 Setting

3 Audible Alarm Status

4Alarm Type
