Philips 170B1A Manual de usuario

Philips 170B Electronic User's Manual

file:///F|/180P/170B/index.htm [2000/7/17 12:52:19 PM]

Safety and Troubleshooting Information

Safety Precautions and Maintenance • Installation Locations • Correct Handling of the LCD

Monitor • FAQs • Troubleshooting • Regulatory Information • Other Related Information

Safety precautions and maintenance

WARNING: Use of controls, adjustments, or procedures other than those

specified in this documentation may result in exposure to shock, electrical

hazards, and/or mechanical hazards.

Read and follow these instructions when connecting and using your computer monitor:

Unplug the monitor, if you are not going to use it for an extensive period of time.● Unplug the monitor, if you need to clean it with a slightly damp cloth. Wiping the screen with a dry

cloth is possible when the power is off. However, never use alcohol, solvents, or ammonia-based

liquids.

●

Consult a service technician if the monitor does not operate normally when following the instructions

in this manual.

●

The casing cover should be opened only by qualified service personnel.● Keep the monitor out of direct sunlight and away from stoves or any other heat source.● Remove any object that could fall into the vents or prevent proper cooling of the monitor’s electronics.● Do not block the ventilation holes on the cabinet.● Keep the monitor dry. To avoid electric shock, do not expose it to rain or excessive moisture.● When positioning the monitor, make sure the power plug and outlet are easily accessible.● If turning off the monitor by detaching power cable or DC power cord, wait for 6 seconds, then attach

the power cable or DC power cord for normal operation.

●

To avoid the risk of shock or permanent damage to the set, do not expose the monitor to rain or

excessive moisture.

●

Consult a service technician if the monitor does not operate normally when operating instructions of this

manual are followed.

RETURN TO TOP OF THE PAGE

Installation Locations

Avoid Heat and Extreme Cold● Do not store or use the LCD monitor in locations exposed to heat, direct sunlight, or extreme cold.● Avoid moving the LCD monitor between locations with large temperature differences. Choose a site

falling within the following temperature and humidity ranges.

●

Safety & Troubleshooting

file:///F|/180P/170B/safety/safety.htm (1 of 3) [2000/7/17 12:52:36 PM]

Temperature: 5-35°C 41-95°F❍ Humidity: 20-80% RH❍

Do not subject the LCD monitor to severe vibration or high impact conditions. Do not place the LCD

monitor inside a car trunk.

●

Take care not to mishandle this product by either knocking or dropping during operation or

transportation.

●

Do not store or use the LCD monitor in locations exposed to high humidity or a dusty environment.

Also do not allow water or other liquids to spill on or into the LCD monitor.

●

RETURN TO TOP OF THE PAGE

Correct handling of the monitor

Safety & Troubleshooting

file:///F|/180P/170B/safety/safety.htm (2 of 3) [2000/7/17 12:52:36 PM]

When handling the monitor, grip the bottom firmly with both hands and ensure that the front panel

faces outward before lifting. Please refer to the diagram on the right.

Handling the monitor with care prevents scratching and damage. If the monitor becomes damaged,

immediately disconnect the power from the unit and have it checked by a qualified service person

before using it again.

To prevent fire or electrical shock, do not drop the monitor.3. When moving the monitor, be sure to unplug all power cords in order to avoid injury or damage to the

equipment.

RETURN TO TOP OF THE PAGE

Safety & Troubleshooting

file:///F|/180P/170B/safety/safety.htm (3 of 3) [2000/7/17 12:52:36 PM]

FAQs (Frequently Asked Questions)

Safety and Troubleshooting • General FAQ • Screen Adjustments • Compatibility with Other

Peripherals • LCD Panel Technology • Ergonomics, Ecology, and Safety Standards •

Troubleshooting • Regulatory Information • Other Related Information

General FAQs

Q: When I install my monitor how do I do if the screen shows "Cannot display this video mode"?

A: Recommended video mode for Philips 150P/150B/140S: 1024x768 @60Hz for Philips 17"/18"

1280x1024@60Hz.

Unplug all cables, then connect your PC to the monitor that you used previously and which displayed

correctly.

●

In the Windows Start Menu, select Settings/Control Panel. In the Control Panel Window, select the

Display icon. Inside the Display Control Panel, select the " Settings " tab. Under the setting tab, in

box labeled " desktop area ", move the slidebar to 1024x768 pixels .

●

Open " Advanced Properties " and set the Refresh Rate to 60Hz, then click OK.● Restart your computer and repeat step 2 and 3 to verify that your PC is set at 1024x768, 60Hz.● Shut down your computer, disconnect your old monitor and reconnect your Philips LCD monitor.● Turn on your monitor and then turn on your PC●

Q: What does "refresh rate" mean to me in an LCD monitor?

A: For LCD monitors, the refresh rate is much less relevant. LCD monitors display a stable,

flicker-free image at 60Hz. There is no visible differences between 85Hz and 60Hz.

Q: What are the .inf and .icm files on the setup disk & CD-ROM? How do I install the drivers (.inf and

.icm)?

A: These are the driver files for your monitor. Follow the instructions in your user manual to install

the drivers. Your computer may ask you for monitor drivers (.inf and .icm files) or a driver disk when

you first install your monitor. Follow the instructions to insert the driver disk (either floppy or

CD-ROM) included in this package. Monitor drivers (.inf and .icm files) will be installed

automatically.

Q: How do I adjust resolution?

FAQs (Frequently Asked Questions)

file:///F|/180P/170B/safety/saf_faq.htm (1 of 9) [2000/7/17 12:53:10 PM]

A: Your video card/graphic driver and monitor together determine the available resolutions. You

can select desired resolution under Window 95/98 with the "Display properties/Settings" control

panel

Q: What if I get lost when making monitor adjustments?

A: Simply press the OSD button, then select "Reset" to recall all original settings.

Q: What is the Auto function?

A: The AUTO adjustment key restores optimal screen position, phase and clock settings with the

press of a single button – without navigation through OSD menus and control keys.

Q: My Monitor has no power (Power LED does not light) ? What should I do?

A: Make sure the DC Jack in the pedestal is connected to the Monitor.

Q: Will the LCD monitor accept an Interlaced signal?

A: No If an Interlace signal is used, the screen displays both odd and even horizontal scanning lines

at the same time, distorting the picture.

Q: Does Refresh Rate mean to LCD?

A: Unlike CRT display technology in which the speed the electron beam is swept from the top to the

bottom of the screen determines flicker, an active matrix display uses an active element (TFT) to

control each individual pixel and thus refresh rate is not really applicable to LCD technology.

Q: Will the LCD screen resistant scratches?

A: A protective coating is applied onto the surface of the LCD, which is durable up to a certain

extent of hardness (approximately up to the hardness of a 2H pencil). In general, it is recommended

not to expose the panel surface to any excessive shocks or scratches. An optional protective cover

with greater scratch resistance is also available.

FAQs (Frequently Asked Questions)

file:///F|/180P/170B/safety/saf_faq.htm (2 of 9) [2000/7/17 12:53:10 PM]

Q: How should I clean the LCD surface?

A: For normal cleaning, use the clean, soft and fine. For extensive cleaning, please use Isopropyl

alcohol. Do not use other solvents such as ethyl alcohol, ethanol, acetone, hexane, etc.

Q: What accessories are available for my 150P / 180P/ 170B LCD monitor?

A: Currently there are 3 accessories available for the 150P. There are:

User installable Protective Cover

● Optional integrated USB Hub● VESA Wall Mount Kit●

Q: What accessories are available for my 150B LCD monitor?

A: Currently there are 2 accessories available for the 150B. There are:

User installable Protective Cover

● VESA Wall Mount Kit●

Q: What accessories are available for my 140S LCD monitor?

A: Currently there are 1 accessories available for the 140S. There are:

VESA Wall Mount Kit

●

Q: How many signal inputs do Philips 150P LCD monitor provide?

A: Standard 15-pin D-Sub and DVI-D connectors and a Macintosh adapter (optional outside of North

America) open the 150P up to most PC and workstation users. Handy hot keys on the chin of the

150P make switching between two different video sources a breeze.

Q: Can the Philips LCD Monitor be hung on the wall or used as touch panel?

A: Yes, Philips Brilliance LCD monitors have this optional feature. The standard VESA mount holes

on inside removable back cover integrate with a VESA FPMPMI standard arm, which include both a

VESA compatible mount bracket and external AC adapter. Touch panels are being developed for

future applications. Check with your Philips sales representative for more information.

RETURN TO TOP OF THE PAGE

FAQs (Frequently Asked Questions)

file:///F|/180P/170B/safety/saf_faq.htm (3 of 9) [2000/7/17 12:53:10 PM]

Screen Adjustments

Q: What is CustoMax® and what models are compatible? (181AS / 150P)

A: CustoMax® is proprietary Philips software that allows users to adjust monitor via software

instead of control keys under Windows base. With the Philips Brilliance 150P, CustoMax® operates

via a USB connection to PC. All Philips 150P models are CustoMax® compatible, but your computer

must support USB in order to use CustoMax®.

Q: What is the FPadjust program on the setup disk and CD-ROM?

A: The FPadjust program generates alignment patterns that help you adjust monitor settings such

as Contrast, Brightness, Horizontal Position, Vertical Position Phase, and Clock for optimal

performance.

Q: When I install my monitor, how do I get the best performance for the monitor?

For best performance, make sure your display settings are set at 1024x768@60Hz for 150P / 150B /

140S, 1280x1024@60Hz for 170B / 180P/181AS. Note: You can check the current display settings

by pressing the OSD OK button once.

The current display mode is shown in product information in OSD main controls, or under OSD main

controls (181AS).

To install the Flat Panel Adjust (FPadjust) program located on the monitor setup disk or CD-ROM,

open the setup disk or CD-ROM and double-click the FPadjust.exe icon. This will install FP Adjust

automatically and place a shortcut on your desktop.

Run FPadjust by double clicking the shortcut. Follow the instructions step by step to optimize image

performance with your system's video controller.

Q: How do LCDs compare to CRTs in terms of radiation?

A: Because LCDs do not use an electron gun, they do not generate the same amount of radiation at

the screen surface.

Q: What is the screen size enlarge function?

A: User want the best possible display quality regardless of the size of the image. However LCD

panel characteristics require some tradeoffs. For example, the 150P highest resolution is 1024x768.

In other words, there are 1024x768 or 786,432 pixels on this 15-inch LCD screen. When the monitor

needs to display at a lower resolution, say 640x480, the image on the screen is smaller because it

requires fewer pixels.

FAQs (Frequently Asked Questions)

file:///F|/180P/170B/safety/saf_faq.htm (4 of 9) [2000/7/17 12:53:10 PM]

Q: How can I adjust the screen?

A: The screen brightness may be adjusted using the Brightness control in the OSD. Scaling an

image in this manner results in slight brightness "fuzziness" or distortion.

RETURN TO TOP OF THE PAGE

Compatibility with other Peripherals

Q: Can I connect my LCD monitor to any PC, workstation or Mac?

A: Yes, all Philips LCD monitors are fully compatible with standard PC, Mac and workstation. You

may need a cable adapter to connect the monitor to your Mac system. Please contact your

dealer/reseller for more information.

Q: Are Philips LCD monitors Plug-and-Play?

A: Yes, the monitors are Plug-and-Play compatible with Windows® 95, 98 and the PC98/99

platforms.

Q: What is USB (Universal Serial Bus)?

A: Think of USB as a smart plug for PC peripherals. USB automatically determines resources (like

driver software and bus bandwidth) required by peripherals. USB makes necessary resources

available without user intervention. There are three main benefits of USB. USB eliminates "case

angst," the fear of removing the computer case to install circuit board cards -- that often require

adjustment of complicated IRQ settings -- for add-on peripherals. USB does away with "port

gridlock." Without USB, PCs are normally limited to one printer, two Com port devices (usually a

mouse and modem), one Enhanced Parallel Port add-on (scanner or video camera, for example), and

a joystick. More and more peripherals for multimedia computers come on the market every day.

With USB, up to 127 devices can run simultaneously on one computer. USB permits "hot plug-in." No need

to shut down, plug in, reboot and run set up to install peripherals. No need to go through the reverse

process to unplug a device. Bottom line: USB transforms today's "Plug-and-Pray" into true Plug-and-Play!

Q: What is a USB hub ? (150P/180P/181AS)

A: A USB hub provides additional connections to the Universal Serial Bus. A hub's upstream port

connects a hub to the host, usually a PC. Multiple downstream ports in a hub allows connection to

another hub or device, such as a USB keyboard, camera or printer.

FAQs (Frequently Asked Questions)

file:///F|/180P/170B/safety/saf_faq.htm (5 of 9) [2000/7/17 12:53:10 PM]

RETURN TO TOP OF THE PAGE

LCD Panel Technology

Q: What is Liquid Crystal Display?

A: A Liquid Crystal Display (LCD) is an optical device that is commonly used to display ASCII

characters and images on digital items such as watches, calculators, portable game consoles etc.

LCD is the technology used for displays in notebook and other small computers. Like light-emitting

diode and gas-plasma technologies, LCD allows displays to be much thinner than cathode ray tube

(CRT) technology. LCD consumes much less power than LED and gas-display displays because

they work on the principle of blocking light rather than emitting it.

Q: How are LCDs made?

A: LCDs are created from two glass plates separated from each other at a distance of a few

microns. Plates are filled with liquid crystal, then seals together. The top plate is colored with a RGB

pattern to make the color filter. Then polarizers are glued to both plates. This combination is

sometimes called "glass" or "cell." The LCD cell is assembled into a "module" by adding the

backlight, driver electronics and frame.

Q: What is polarization ?

A: Polarization is basically directing light to shine in one direction. Light is electromagnetic wave.

Electric and magnetic fields oscillate in a direction perpendicular to the propagation of the light

beam. The direction of these fields is called "polarization direction." Normal or non-polarized light

has fields in several directions; polarized light has a field in only one direction.

Q: What differentiates passive matrix LCDs from active matrix LCDs?

A: An LCD is made with either a passive matrix or an active matrix display grid. An active matrix has

a transistor located at each pixel intersection, requiring less current to control the luminance of a

pixel. For this reason, the current in an active matrix display can be switched on and off more

frequently, improving the screen refresh time (your mouse pointer will appear to move more

smoothly across the screen, for example). The passive matrix LCD has a grid of conductors with

pixels located at each intersection in the grid.

FAQs (Frequently Asked Questions)

file:///F|/180P/170B/safety/saf_faq.htm (6 of 9) [2000/7/17 12:53:10 PM]

Otros manuales para 170B1A

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Philips

Philips

Philips 107E76 Manual de usuario

Philips

Philips 241E1SW Manual de usuario

Philips

Philips 200BW8 Instrucciones de instalación y funcionamiento

Philips

Philips 190C6F Manual de usuario

Philips

Philips 190BW9 Manual de usuario

Philips

Philips Brilliance 224CL2SB Manual de usuario

Philips

Philips 2.44E+03 Instrucciones de instalación y funcionamiento

Philips

Philips 170V7FB/27 Manual de usuario

Philips

Philips 202EL2SB Manual de usuario

Philips

Philips Brilliance 220S2SB Manual de usuario

Philips

Philips D Line 98BDL4510D Manual de usuario

Philips

Philips 170S7FS Manual de usuario

Philips

Philips 109B50 Manual de usuario

Philips

Philips 242V8 Manual de usuario

Philips

Philips 192EL2SB Manual de usuario

Philips

Philips 240B9/01 Manual de usuario

Philips

Philips Brilliance 220B4L Manual de usuario

Philips

Philips Brilliance 170P6EG Manual de usuario

Philips

Philips 107T20/00H Instrucciones de instalación y funcionamiento

Philips

Philips 190PS Manual de usuario

Philips

Philips 190B8CS/05 Instrucciones de instalación y funcionamiento

Philips

Philips 275S1AE Manual de usuario

Philips

Philips 200BW8ES/00 Manual de usuario

Philips

Philips 7BM749-00H Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

LG M1950D-PZ Manual de usuario

Sceptre

Sceptre D40 Manual de usuario
