English

Contents

1 Important 2

Hearing Safety 2

2 Your Micro System 3

Introduction 3

What's in the box 3

Overview of the main unit 4

Overview of the remote control 5

3 Get started 7

Placement 7

Prepare FM antenna 7

Prepare the remote control 7

Connect power 7

Set clock 8

Turn on 8

Store FM radio stations automatically 8

4 Play 9

Play disc 9

Play from a USB storage device 9

Play from iPod/iPhone 9

Play options 10

Adjust sound 11

Display different information 11

5 Listen to FM radio 11

Tune to FM radio stations 11

Program FM radio stations automatically 11

Program FM radio stations manually 12

Select a preset radio station 12

Show RDS information 12

Select stereo/mono broadcast 12

6 Other features 13

Set the alarm timer 13

Set the sleep timer 13

Play from an external device 13

Listen through the headphone 14

7 Product information 14

Specications 14

USB playability information 15

Supported MP3 disc formats 15

RDS program types 15

8 Troubleshooting 16

9 Notice 17

2EN

1 Important

• Read these instructions.

• Follow all instructions.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

otherapparatus(includingampliers)that

produce heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the unit.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Unplug this unit during lightning storms or

when unused for long periods of time.

• Referallservicingtoqualiedservice

personnel. Servicing is required when the

unit has been damaged in any way, such

as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the apparatus, the unit has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

• Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbonandalkaline,etc.).

• Remove batteries when the unit is not

used for a long time.

• Batteries (battery pack or batteries

installed)shallnotbeexposedtoexcessive

heatsuchassunshine,reorthelike.

• The unit shall not be exposed to dripping

or splashing.

• Do not place any sources of danger on

theunit(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this apparatus.

•Never place this apparatus on other electrical

equipment.

•Never look into the laser beam inside this apparatus.

Hearing Safety

Danger

•To avoid hearing damage, limit the time you use the

headphones at high volume and set the volume to a

safe level.The louder the volume, the shorter is the safe

listening time.

Be sure to observe the following guidelines

when using your headphones.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your hearing

adapts.

• Do not turn up the volume so high that

you can’t hear what’s around you.

• You should use caution or temporarily

discontinue use in potentially hazardous

situations.

• Excessive sound pressure from earphones

and headphones can cause hearing loss.

Modication of the product could result in

hazardous radiation of EMC or other unsafe

operation.

English

2 Your Micro

System

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this unit, you can:

• enjoy audio from discs, iPod/iPhone, USB

devices, and other external devices;

• listen to FM radio

You can enrich sound output with these sound

effects:

• DigitalSoundControl(DSC)

• DynamicBassBoost(DBB)

What's in the box

Check and identify the contents of your

package:

• Main unit

• Remote control

• Power adapter

• 2 X AAA batteries

• Mountingkit(2dowelsand2screws)

• User manual

• Quick start guide

• Wall mounting instructions

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

4EN

Overview of the main unit

ab cdefg

hij

klm

• Turn the unit on.

• Switch to standby mode.

b SOURCE

• Select a source: CD, FM, USB, Dock, ,

or MP3 LINK.

English

c /

• Skip to the previous or next track.

• Search within a track or disc.

• Tune to radio stations.

• Adjust time.

d OK/

• Conrmselection.

• Select mono or stereo broadcast.

• Start or pause play.

e MENU/

• Access iPod/iPhone menu.

• Stop play or erase a program.

f VOLUME + / -

• Adjust volume.

• Open or close the disk tray.

h Disc tray

i DOCK for iPod/iPhone

j Display panel

• Show play information.

k MP3-LINK

• Connect an external audio device.

• Connect USB device.

• Headphone socket.

n FM ANT

• Improve FM reception.

o DC IN

• Connect power.

Overview of the remote

control

• Turn the unit on.

• Switch to standby mode.

• Mute or restore sound.

PRESET/ALBUM

PROG/

CLOCK SET

SLEEP/

TIMER

DSC DBB

VOL

REPEAT/

SHUFFLE

456

789

DOCK

DISPLAY

RDS

USB

LINK

6EN

c CD

• Select CD source.

d /

• Skip to the previous or next track.

• Search within a track or disc.

• Tune to radio stations.

• Adjust time.

e USB/MP3 LINK

• Select USB or MP3 link source.

f RDS/DISPLAY

• Show time and play information.

• For selected FM radio stations: display

RDS information.

• Start or pause play.

h VOL +/-

• Adjust volume.

i Numeric Keypad 0 - 9

• Select a track from a disc or USB

device directly.

• Select a preset radio station.

j PROG/CLOCK SET

• Program tracks.

• Program radio stations.

• Set time.

k SLEEP/TIMER

• Set sleep or alarm timer.

l DSC

• Select a preset sound setting.

m DBB

• Turn dynamic bass enhancement on

or off.

n REPEAT/SHUFFLE

• Play a track or all tracks repeatedly.

• Play tracks in current album repeatedly.

• Play tracks randomly.

o MENU/

• Access iPod/iPhone menu.

• Stop play or erase a program.

p DOCK

• Select iPod/iPhone source.

q OK

• Conrmselection.

• Select mono or stereo broadcast.

r /

• Select a preset radio station.

• Skip to the previous or next album.

s FM

• Select FM tuner source.

English

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Placement

Youcanplacetheunitonaatsurfaceor

mount the unit on a wall.

Mount on a wall

See the wall mounting instructions included in

the package.

Prepare FM antenna

For better reception, fully extend and adjust the

position of the FM antenna.

Note

•To prevent interference, position the antenna as far as

possible fromTV,VCR, or other radiation source.

Prepare the remote control

Caution

•Risk of explosion! Keep batteries away from heat,

sunshineorre.Neverdiscardbatteriesinre.

1 Open the battery compartment.

2 Insert the supplied batteries with correct

polarity(+/-)asindicated.

3 Close the battery compartment.

Connect power

Caution

•Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on

the back or the underside of the unit.

•Risk of electric shock! When you unplug the AC power

adapter, always pull the plug from the socket. Never

pull the cord.

•Before connecting the AC adapter, make sure that you

have completed all other connections.

Note

•The type plate is located at the back of the main unit.

8EN

Connect the power adapter to:

• the DC IN socket on the main unit.

• the wall outlet.

Set clock

1 In standby mode, press and hold CLOCK

SET on the remote control for two

seconds.

» [SET CLOCK] (setclock)scrollson

the display, then the 12/24 hour format

blinks.

2 Press / repeatedly to select an hour

format.

3 Press CLOCK SETtoconrm.

» The hour digits blink.

4 Repeat steps 2-3 to set the hour.

5 Repeat steps 2-3 to set the minute.

6 Repeat steps 2-3 to select whether to

synchronize time with RDS stations.

• [RDS TIME SYNC [Y]]: synchronize

time with RDS stations automatically.

• [RDS TIME SYNC [N]]: deactivate

time synchronization.

Note

•The accuracy of the transmitted time depends on the

RDS station that transmits the time signal.

•If the system is idle for 90 seconds, it exits clock setting

mode automatically.

Turn on

Press .

» The unit switches to the last selected

source.

Note

•To select a source, press SOURCE repeatedly or the

source selection buttons on the remote control.

Switch to standby mode

Press again to switch the unit to standby

mode.

» Theclock(ifset)appearsonthe

display panel.

Store FM radio stations

automatically

When you connect AC power and no FM

stations are stored, the unit prompts you to

search and store all the available FM stations.

1 Connect the unit to the power supply.

» [AUTO INSTALL - PRESS PLAY, STOP

CANCEL] (to auto install, press ;

to cancel, press )isdisplayed.

2 Press and hold for 3 seconds to start

full scan.

» The unit automatically stores FM radio

stationswithsufcientsignalstrength

andthenbroadcaststherstpreset

station.

Tip

•To exit storing mode, press or .

English

4 Play

Play disc

1 Press to open the disc tray.

2 Insert a disc with the printed side facing up.

3 Press to close the disc tray.

4 Press CD on the remote control to select

the disc source.

» [Reading](reading)blinksfora

moment, then CD starts playing

automatically. If not, press .

Play from a USB storage

device

Note

•Make sure that the USB device contains playable audio

content.

1 Insert the USB storage device into the

socket.

2 Press USB on the remote control to select

the USB source.

» Play starts automatically. If not, press

Play from iPod/iPhone

You can enjoy audio from iPod/iPhone through

this unit.

Compatible iPod/iPhone

The unit supports the following iPod and

iPhone models:

Made for.

• iPod touch (1st, 2nd, 3rd, and 4th

generation)

• iPod nano (2nd, 3rd, 4th, 5th, and 6th

generation)

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

Load the iPod/iPhone

1 Push to open the dock compartment.

2 Place the iPod/iPhone in the dock.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Micro sistema de música de Philips

Philips

Philips DCM3060/93 Manual de usuario

Philips

Philips DCM105/61 Manual de usuario

Philips

Philips MCM204 Manual de usuario

Philips

Philips MCM205/12 Manual de usuario

Philips

Philips MCM239/55 Manual de usuario

Philips

Philips MC135/25 Manual de usuario

Philips

Philips MCM103B/12 Manual de usuario

Philips

Philips MCM2300 Manual de usuario

Philips

Philips MCM305/55 Manual de usuario

Philips

Philips DCM278/12 Manual de usuario

Philips

Philips DCM2068 Hoja de información del producto

Philips

Philips BTB4800 Manual de usuario

Philips

Philips BTD2180 Manual de usuario

Philips

Philips MC127/12 Manual de usuario

Philips

Philips MCM233/12 Manual de usuario

Philips

Philips MCD712/93 Manual de usuario

Philips

Philips MC155/22 Manual de usuario

Philips

Philips MCM103/96 Manual de usuario

Philips

Philips MCD139B/98 Manual de usuario

Philips

Philips DCM2170/12 Manual de usuario

Philips

Philips MCM2320/12 Manual de usuario

Philips

Philips MCB2305 Manual de usuario

Philips

Philips DCD322/12 Manual de usuario

Philips

Philips MCM119/05B Manual de usuario

Manuales populares de Micro sistema de música de otras marcas

Rautz

Rautz MC-5100DU Manual de usuario

Sanyo

Sanyo DC-D9 Manual de usuario

Curtis

Curtis RCD744 Manual de usuario

Samsung

Samsung MM-UC8 Manual de usuario

Akai

Akai AMP300UCI Manual de usuario

Hyundai

Hyundai MS 132 DU3BL Manual de usuario

JVC

JVC UX-GP5 Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manual de usuario

Optimus

Optimus SYSTEM 731 Manual de usuario

Hitachi

Hitachi AXM209UK Manual de usuario

Sharp

Sharp XL-MP110DVD Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manual de usuario

ProAudio

ProAudio MC 9010 iP Manual de usuario

Samsung

Samsung MM-ZJ9 Manual de usuario

Sharp

Sharp MD-X7 Manual de usuario

Sharp

Sharp DK-KP95P Manual de usuario

Akura

Akura APTCDC832PR Manual de usuario

iLive

iLive IHB248B Manual de usuario
