Philips Azur Cordless HI575 Manual de usuario

Azur Cordless

HI575, HI571, HI570

ENGLISH 6

DEUTSCH 17

FRANÇAIS 29

NEDERLANDS 41

ITALIANO 53

 64

TÜRKÇE 77

HI575, HI571, HI570

General description (fig. 1)

ATurbo steam button 0(HI575 only)

BSpray button T

CShot-of-steam button 9

DSteam control

0 = no steam

1 = minimum steam

6 = maximum steam

EAuto shut-off light (HI575 only)

FTemperature light

GCarry case (HI575/571 only)

HSoft-touch handgrip (HI575 only)

ICord clip

JPower unit

KMode switch

∫= cordless ironing

π= storage position

ª= corded ironing

LStand

MStand clamp

NFilling cup

OTypeplate

PSoleplate

QWater level window

RTemperature dial

SCalc-Clean button for cleaning/descaling

TFilling opening with cap

USpray nozzle

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the type plate corresponds to

the local mains voltage before you connect the appliance.

◗Only connect the appliance to an earthed wall socket.

◗Do not use the appliance if the plug, the cord or the appliance

itself shows visible damage, or if the appliance has been dropped

or is leaking.

◗Check the cord regularly for possible damage.

◗If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualified persons

in order to avoid a hazard.

◗Never leave the appliance unattended when it is connected to the

mains.

◗Never immerse the iron and the stand, if provided, in water.

◗Keep the appliance out of the reach of children.

◗The soleplate of the iron can become extremely hot and may

cause burns if touched.

ENGLISH6

◗Do not allow the cord to come into contact with the soleplate

when it is hot.

◗When you have finished ironing, when you clean the appliance,

when you fill or empty the water tank and also when you leave

the iron even for a short while: set the steam control to position

O, put the iron on its heel and remove the mains plug from the

wall socket.

◗Only use this iron with the stand supplied.

◗Always place and use the iron and the stand, if provided, on a

stable, level and horizontal surface.

◗Do not put perfume, vinegar, starch, descaling agents, ironing aids

or other chemicals in the water tank.

◗This appliance is intended for household use only.

Before first use

C1Release the carry case (HI575/571 only).

C2Remove the carry case (HI575/571 only).

3Remove any sticker or protective foil from the soleplate and

clean the soleplate with a soft cloth.

C4Fully unwind the mains cord.

ENGLISH 7

LINEN

HILO

SILK

SEDA

NYLON

NILON

WOOL

LANA

COTTON

ALGODON

MAX

MIN

LINEN

HILO

SILK

SEDA

NYLON

NILON

WOOL

LANA

COTTON

ALGODON

MAX

MIN

LINEN

HILO

SILK

SEDA

NYLON

NILON

WOOL

LANA

COTTON

ALGODON

MAX

MIN

Preparing for use

Fastening the stand clamp

C1Fold out the clamp on the bottom of the stand and fix the

stand clamp to the ironing board or to another stable surface,

such as a tabletop.

The rubber feet on the bottom prevent the stand from slipping.

◗You can also place the stand on the ironing board without using

the clamp.The clamp can then remain folded in.

Do not place the stand close to the table edge, as the stand could

accidentally be knocked over.

Filling the water tank

1Remove the mains plug from the wall socket.

2Set the steam control to 0 (no steam).

C3Set the mode switch to ∫(cordless ironing).

C4Take the iron from the stand.

5Place the iron on its heel and open the cap of the filling

opening.

C6Use the filling cup to pour water into the water tank and close

the cap of the filling opening afterwards.

If the tap water in your area is very hard, we advise you to mix it with

an equal amount of distilled water or to use distilled water only.

Do not fill the water tank beyond the MAX indication.

Do not put perfume, vinegar, starch, descaling agents, ironing aids or

other chemicals in the water tank.

ENGLISH8

LINEN

HILO

SILK

SEDA

NYLON

NILON

WOOL

LANA

COTTON

ALGODON

MAX

Setting the temperature

C1Put the iron on the iron stand.

C2Set the required ironing temperature by turning the

temperature dial to the appropriate position (see section 'Tips'

for extra information).

Check the laundry care label for the required ironing temperature:

C3Put the mains plug in an earthed wall socket.The temperature

light goes on to indicate that the iron is heating up.

◗The iron is hot enough when the temperature light goes out.

◗During ironing the temperature light goes on from time to time.

This indicates that the iron is heating up to the right temperature.

◗If you have been ironing at a high temperature and subsequently

set the temperature dial to a lower setting, wait until the

temperature light goes on again before you continue ironing.This

will prevent damage to your fabrics.

◗Some parts of the iron have been lightly greased.This may cause

the iron to give off some smoke when you switch it on for the

first time.After a short while, however, this will cease.

Tips

- If the fabric consists of various kinds of fibres, always select the

temperature required by the most delicate fibre, i.e. the lowest

temperature. For example: if an article consists of 60% polyester and

ENGLISH 9

LINEN

HILO

SILK

SEDA

NYLON

NILON

WOOL

LANA

COTTON

ALGODON

MAX

Steam setting

0 (see 'Ironing

without steam')

1-2

3-6

Temperature

setting

3to MAX

Type of fabric

Synthetic fabrics (e.g.

acetate, acrylic,

viscose, polyamide,

polyester) and silk

Wool

Cotton, linen

Please note that Z

on the label means

that the article cannot

be ironed.

Symbol on

laundry care label

40% cotton, it should be ironed at the temperature indicated for

polyester (2) and without steam.

- If you do not know what kind or kinds of fabric an article is made of,

determine the right ironing temperature by ironing a part that will

not be visible when you wear or use the article.

- Silk, woollen and synthetic materials: iron the reverse side of the

fabric to prevent shiny patches.

- Velvet and other fabrics that tend to acquire shiny patches should be

ironed in one direction only (along with the nap) while applying very

little pressure.

- Start ironing the articles that require the lowest ironing temperature,

such as those made of synthetic fibres.

Using the appliance

Corded ironing

C1Set the mode switch to position ª(corded ironing).

C2Take the iron from the stand.

◗When you stop ironing for a while, you can put the iron on the

stand or on its heel.

Cordless ironing

C1Set the mode switch to position ∫(cordless ironing).

ENGLISH10
