Philips 69050-48-16 Manual de usuario

Philips Ledino

Suspension light

69050/48/16

Essence of purity

giving light a new experience

Pure forms of eye-catching beauty and elegant simplicity crafted from premium blocks of

high-grade glass and brushed aluminium. An invisible disc or plane of light that's both

gloriously luxurious and minimalist in its essence.

Elegant design meets innovative technology

• High Power LED

• High light quality with strong light output

• Adjustable light intensity with dimmer switch

• Light colour selection possible at installation

• Adjustable height

Sustainable light solutions

• Extremely long operating life

• Saves up to 80% energy

690504816

Highlights

Suspension light

Adjustable height

Dimmable

Most Philips LED luminaires are dimmable,

which means that their light level can be

adjusted with a dimmer switch. The dimming

indication is always mentioned on the product

packaging and in the manual that is delivered in

the box. Most Philips LED luminaires can be

dimmed by means of an external trailing edge

wall dimmer (not included in the product box).

These dimmers are compatible with electronic

(capacitive) transformers and LED drivers.

Philips tested a number of wall dimmers that

have proved to be compliant. A list of

compatible dimmers is available in the

downloads and support section.

Extremely long operating life

A light source you can trust. Philips LED

luminaires offer an extremely long-life of at

least 20,000 hours (which equals 20 years on a

basis of an average use of 3 hours/day with an

amount of at least of 13,000 on/off switching

cycles). It feels so comfortable to think that

you won’t have to worry about maintenance

or lamp replacement while having the perfect

light ambiance in your home.

High light quality

A module of 7.5 W produces the equivalent

light output as a 40 W incandescent lamp (350

Lumen) with strong light output.

High Power LED

The LED module is a unique solution

developed by Philips, which combines 3 LEDs

in a synthetic and aluminium housing. This

technique enables an optimal light output and a

100% uniform light colour.

Saves up to 80% energy

The LED lighting technology used in Philips

luminaires is highly energy-efficient (7.5 W

module produces 350 Lumen). As a result,

every luminaire conserves energy, helping

consumers to save money on their electricity

bills and contribute to preserving the

environment. For home lighting that's energy-

efficient and provides great light in a range of

contemporary designs, look for Philips LED

products.

Tunable white

Who said that choosing your LED light colour

was not possible? Ledino introduces tunable

white in a selection of luminaires. You can

choose your preferred light colour from warm

white to cool white when installing your

luminaire. There are 4 light colour options

offered: 2500, 2700, 3100, 3450 Kelvin. Once

the light colour is installed, most luminaires can

be dimmed normally with a wall dimmer

(excluded).

Issue date 2011-06-29

Version: 4.1.1

12 NC: 9150 025 28401

EAN: 87 17943 74586 9

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

690504816

Specifications

Suspension light

Power

• Power supply: 220-240 V, 50/60 Hz

• Output: SELV

• Energy consumption: 1 x 7.5 W

• Class of protection: I

Design and finishing

• Material: glass

• Colour(s): aluminium

Technical specifications

• Light source: 1 LED module

• Light colour: 2500 k - 3450 k

• Life span: 20 years

• Style: modern

• Price range: mid

• Room: bedroom and living room

• Type: suspension light

•IPcode:IP20

Extra features

• Adjustable height

• Dimmable

• Guaranteed: 2 year(s)

Packaging

•Height:35cm

• Length: 34.5 cm

• Width: 9.5 cm

•Grossweight:4kg

Product dimensions and weight

• Length: 30 cm

• Net weight: 3.3 kg

• Width: 30 cm

•Heightmax:150cm

•
