Philips TAT4205 Manual de usuario

User manual

www.philips.com/support

Headphones

TAT4205

1 Important safety instructions 2

Hearing Safety 2

General information 2

2 Your Bluetooth wireless

headset 3

What's in the box 3

Other devices 3

Overview of your Bluetooth

wireless headset 4

3 Get started 5

Charge the battery 5

Pair the headset with your

time 6

Pair the headset with another

Bluetooth device 6

4 Use your headphones 7

Connect the headset to your

Bluetooth device 7

Manage your calls and music 7

LED indicator status 8

How to wear 9

5 Factory reset the headset 9

6 Technical data 10

7 Notice 10

Declaration of conformity 10

Disposal of your old product

and battery 10

Compliance with EMF 11

Environmental information 11

8 Frequently asked questions 12

Contents

1 Important

safety

instructions

Hearing Safety

Danger

 To avoid hearing damage, limit the time you

use headphones at high volume and set the

volume to a safe level. The louder the

volume, the shorter the safe listening time is.

Be sure to observe the following guide-

lines when using your headset.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your

hearing adapts.

• Do not turn up the volume so high

that you can't hear what's around

you.

• You should use caution or tempo-

rarily discontinue use in potentially

hazardous situations.

• Excessive sound pressure from

earphones and headphones can

cause hearing loss.

• Using headphones with both ears

covered while driving is not recom-

mended and may be illegal in some

areas while driving.

• For your safety, avoid distractions

from music or phone calls while in

environments.

General information

To avoid damage or malfunction:

Caution

 Do not remove or ret earphones for any

reason, otherwise it may cause headphones

malfunction and burnout.

Do not expose headphones to excessive heat



Do not drop your headphones.

 Headphones shall not be exposed to dripping

or splashing.

 Do not allow your headphones to be

submerged in water.

 Do not use any cleaning agents containing

alcohol, ammonia, benzene, or abrasives.

 If cleaning is required use a soft doth, if

necessary dampened with a minimum amount

of water or diluted mild soap, to clean the

product.

 The integrated battery shall not be exposed to

like.

 Danger of explosion if battery is incorrectly

replaced. Replace only with the same or

equivalent type.

About operating and storage

temperatures and humidity

• Operate or store in a place where

temperature is between -15°C (5°F)

and 55°C (131 °F) (up to 90%

relative humidity.

• Battery life may be shorter in high

or low temperature conditions.

2 Your

Bluetooth

wireless

headset

What's in the box

Philips True Wireless headset

Philips TAT4205

Replaceable rubber ear cap x 2 pairs

Charging case

Other devices

A mobile phone or device (e.g. note-

book, PDA, Bluetooth adapters, MP3

players etc) which supports Bluetooth

and is compatible to the headset (see

'Technical data' on page 10).

Congratulations on your purchase, and

www.philips.com/welcome.

With this Philips wireless headset, you

can:

• enjoy convenient wireless

handsfree calls;

• enjoy and control wireless music;

• switch between calls and music.

USB Type-C charging cable

(for charging only)

Quick start guide

Overview of your

Bluetooth wireless

headset

Eartip

Multi-function button

LED indicator and microphone

Charging spring pin

USB Type-C charging port

3 Get started

Charge the battery

Charging case

Headset

Note



place the headsets in the charging case and

charge the battery for 3 hours for optimum

battery capacity and lifetime.

 Use only the original USB Type-C charging

cable to avoid any damage.

 Finish your call before charging the headset,

as connecting the headset for charging will

Connect one end of the USB Type-C

cable into the charging case, and

another end into the power source.

blue LED light on the charging case,

• When the charging case is fully

charged, the blue light goes on.

LED light on the earpieces.

• When the headset is fully charged,

Tip

 The charging case serves as a portable backup

battery for charging the headset. When the

charging case is fully charged, it supports 3 full

recharge cycles for the headset.

 Normally, a full charge takes 2 hours (for the

headset or charging case).

Pair the headset with

your Bluetooth device at

the rst time

Place the headset in the charging case.

The headset start charging.

Make sure that the headset is fully

charged.

Take both headsets out from the

charging case, the headset will

power on automatically, entering

pairing model and Right & Left

headset connected.

There will be a voice “Power on”

and a voice “Pairing”. Then,LED

ashes in white and blue.

The charging case starts charging.

Philips TAT4205

Note



any previously connected Bluetooth device, it

will automatically switch to pairing mode.

 The headset stores 8 devices in the memory. If

you try to pair more than 8 devices, the earliest

paired device is replaced by the new one.

Single headset pairing

(Mono mode)

Pair the headset with

another Bluetooth device

The headset is now in pairing

mode and is ready to pair with a

Bluetooth device (e.g. a mobile

phone).

There will be a voice

“Connected” and LED stays on

for 5 seconds on both headsets.

You can use your device to play

music or make a call.

Turn on the Bluetooth function

of your Bluetooth device, select

Philips TAT4205.

Enter the headset password

“0000” (4 zeros) if prompted.

For those Bluetooth devices

featuring Bluetooth 3.0 or higher,

no need to enter a password.

Turn on the Bluetooth function of

your Bluetooth device.

Take the right/left headset from the

charging case, the earpiece will

power on automatically.

There will be a voice “Power on” from

headset.

Turn on the Bluetooth function on

your device, search for “Philips

TAT4205 ” tap to connect. (Please

refer to P.6)

Once the pairing succeed, you will

hear a voice “Connected” and the

Pair the headset with your

Bluetooth device. Refer to the user

manual of your Bluetooth device.

The following example shows you

how to pair the headset with your

Bluetooth device. If you have another Bluetooth device

that you want to pair with the headset,

make sure the Bluetooth function in any

other previously paired or coonected

steps in ‘Pair the headset with your

Tip

Note

 The headset cannot connect to more than 1

device at the same time. If you have two paired

Bluetooth devices, only turn on the Bluetooth

function of the device that you want to connect.

 If you turn on the Bluetooth function of your

Bluetooth device after turning on the headset,

you have to go to the Bluetooth menu of the

device and connect the headset to the device

manully.

 If the headset fails to connect to any Bluetooth

automatically to save the battery life.

 In some Bluetooth devices, connection may not

be automatic. In this case, you have to go to the

Bluetooth menu of your device and connect the

headset to the Bluetooth device manually.

If no device is connected, the

headset will automatically turn

Both headsets are now

powered on and are paired

with each other automatically.

The headset will search the last

connected Bluetooth device and

reconnect to it automatically. If

the last connected one is not

available, the headset will

search and reconnect to the

second last connected device.

4 Use your

headset

Turn on the Bluetooth function of

your Bluetooth device.

Task

Music control

Turn the

headset on.

Headsets

Right/Left

headset

Take both

headsets

out from the

charging

case.

Place both

headsets in

charging

case.

Press and

hold for 5

seconds.

The

white

LED

3 times.

Turn the

Play or

pause music

Skip forward Right

headset

Press and

hold for 2

seconds

Skip

backward

Left

headset

Press and

hold for 2

seconds

Right/Left

headset

Press twice

Take both headsets from the

charging case, the headset will power

on and reconnect automatically.

Connect the headset to

your Bluetooth device

Manage your calls and

music

Multi-

function

button

Operation

Task Multi-

function

button

Operation

headset o.

LED indicator status

Battery LED indicator on

headset status

Call control

Pick up/hang

up call

Reject an

incomging

call

Right/Left

headset

Press and

hold for 2

seconds

Switch caller

during a call

Right/Left

headset

Right/Left

headset

Press

3 times

Siri/Google

The headset is

connected to a

Bluetooth device.

The headset is

powered on.

The headset is

pairing mode.

The headset is on

but not connected

to a Bluetooth

device.

The blue and

white LED will

connection can be

made, the headset

within 3 minutes.

The white LED

The blue and

Low battery level

(headset).

Battery is fully

charged.

You will hear

‘battery low’ on

the headset.

The white LED

every 1 minutes.

The white LED

light stays on for 5

seconds.

Mobile

phone

control

Right/Left

headset

Press twice

Task Multi-

function

button

Operation

Voice control

Task

Headset status Indicator

Multi-

function

button

Operation It will show a battery indicator on

Bluetooth device after connected to

headset.

While charge with USB Type-C cable,

blue LED light will light on and ash.

When fully charged, blue LED light

will continue on.

While charging base charging

headset, white LED on headset will

light on. When fully charged, white

LED will turn o.

Battery LED indicator on

Charging case

3 times

5 Factory reset

the headset

How to wear

If you encounter any pairing or connection

issue, you can follow the following

procedure to factory reset your headset.

On your Bluetooth device, go to the

Bluetooth menu and remove

Philips TAT4205 from the device list.

Put both headsets back to charging

case, turn o the headsets.

To pair the headset with a Bluetooth

device, turn on the Bluetooth function

of your Bluetooth device, select

TAT4205.

Bluetooth device.

Take both headsets from the

charging case, the headset will

power on automatically. There will

be a voice “Power on” and a voice

“Pairing”. Then blue and white LED

ash.

Press ve times on both headsets

Multi-function buttons, you will

hear “beep sound”.

Then, the headset LED

for 3 mins.

Tabla de contenidos

Otros manuales de Auriculares de Philips

Philips

Philips SHQ3005 Manual de usuario

Philips

Philips SHB9100 Manual de usuario

Philips

Philips TAA7306BK/00 Manual de usuario

Philips

Philips SBCHP890 Manual de usuario

Philips

Philips Sports 5000 Series Manual de usuario

Philips

Philips Over Ear TAPH805 Manual de usuario

Philips

Philips SHC8565/05 Manual de usuario

Philips

Philips SHC5102/10 Manual de usuario

Philips

Philips Nike Pursue SHJ066 Manual de usuario

Philips

Philips SBCHC8560/05 Manual de usuario

Philips

Philips Signage Solutions BDL5520QL Manual de usuario

Philips

Philips SHB4000WT/00 Manual de usuario

Philips

Philips TAN7808 Manual de usuario

Philips

Philips SHG5000 Manual de usuario

Philips

Philips SHB9250/00 Manual de usuario

Philips

Philips SHB9100 Manual de usuario

Philips

Philips SHD8800 Manual de usuario

Philips

Philips SHJ055 Manual de usuario

Philips

Philips SBCHS430 Manual de usuario

Philips

Philips SHE3623 Manual de usuario

Philips

Philips 3000 series Manual de usuario

Philips

Philips O'Neill THE SPECKED SHO9551 Manual de usuario

Philips

Philips SBCHC8300/05 Manual de usuario

Philips

Philips SHC5100 Manual de usuario

Manuales populares de Auriculares de otras marcas

Sony

Sony MDR-NC8 Manual de usuario

AUSounds

AUSounds AU-Stream Manual de usuario

ENERGY SISTEM

ENERGY SISTEM Style 7 Manual de usuario

Insignia

Insignia NS-CAHBTSPORT Manual de usuario

Movie Vision

Movie Vision HP-400 Manual de usuario

MobiFren

MobiFren SM Pro Manual de usuario

Motorola solutions

Motorola solutions PMLN8120 Manual de usuario

Jaybird

Jaybird freedom Guía de instalación

Sony

Sony MDR-ED12LP Manual de usuario

HiFuture

HiFuture Tidy Buds Pro Manual de usuario

Creative

Creative CB2530 Manual de usuario

Renkforce

Renkforce RF FTVK-100 Manual de usuario

Sennheiser

Sennheiser 500371 Manual de usuario

Califone

Califone 2924AV Manual de usuario

Technics

Technics EAH-AZ80 Manual de usuario

Bose

Bose On-Ear Headphone Manual de uso y mantenimiento

Aluratek

Aluratek ABH02F Manual de usuario

Waterfi

Waterfi swimQ Manual de usuario
