Philips HP8183/07 Manual de usuario
HP8183/00, HP8182/00,
HP8181/00, HP8180/00
3
B
C
A
D
E
F
G
H
I
J
K
1
3
4
HP8183/00, HP8182/00, HP8181/00, HP8180/00
ENGLISH 6
DEUTSCH 11
ESPAÑOL 17
FRANÇAIS 23
ITALIANO 29
NEDERLANDS 35
PORTUGUÊS 41
6
Introduction
Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
General description (Fig. 1)
AVolume diffuser (HP8183/HP8182 only)
BAir outlet grille
CConcentrator
DCool shot button
E Turbo button for extra airow
F Airow slide switch
- II = Strong airow for quick drying
- I = Gentle airow specially intended for styling
- 0 = Off
GTemperature slide switch
- 6Hot setting
- 5Warm setting
- 4Cool setting
HIon slide switch (HP8183/HP8182 only)
IHanging loop
JRemovable air inlet grille
KIon indicator light (HP8183/HP8182 only)
Important
Read this user manual carefully before you use the appliance and save it
for future reference.
Warning
- Do not use this appliance near water. Do not use this appliance near
bathtubs, showers, basins or other vessels containing water (Fig. 2).
- When you use the appliance in a bathroom, unplug it after use.The
proximity of water presents a risk, even when the appliance is
switched off.
- Do not insert any objects into the appliance to avoid electric shock.
ENGLISH
- Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.
- Check the condition of the mains cord regularly. Do not use the
appliance if the plug, the mains cord or the appliance itself is damaged.
- If the mains cord is damaged, you must have it replaced by Philips, a
service centre authorised by Philips or similarly qualied persons in
order to avoid a hazard.
- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
Caution
- For additional protection, we advise you to install a residual current
device (RCD) in the electrical circuit that supplies the bathroom.This
RCD must have a rated residual operating current not higher than
30mA. Ask your installer for advice.
- Never block the air grilles.
- The appliance has a safety function. If the appliance overheats, it
switches off automatically. Unplug the appliance and let it cool down
for a few minutes. Before you switch on the appliance again, check the
grilles to make sure they are not blocked by uff, hair, etc.
- Always switch off the appliance before you put it down, even if it is
only for a moment.
- Always unplug the appliance after use.
- Do not wind the mains cord round the appliance.
- HP8183/HP8182/HP8181 only:You may notice a characteristic odour
when you use this hairdryer with the ion function switched on.This is
caused by the ions that are generated and it is not harmful to the
human body.
- Do not use the appliance on articial hair.
- This appliance is only intended for drying scalp hair.
- Do not use the appliance for any other purpose than described in
this manual.
ENGLISH 7
- Keep the hairdryer clean and free of dust, dirt and styling products
such as mousse, spray and gel.
- Never use any accessories or parts from other manufacturers or that
are not specically advised by Philips. If you use such accessories or
parts, your guarantee becomes invalid.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards regarding
electromagnetic elds (EMF). If handled properly and according to the
instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.
Using the appliance
Drying
1 Put the plug in the wall socket.
2 Selectthedesiredairowsettingtoswitchontheappliance(Fig.3).
- Set the slide switch to airow setting II for ultra-quick drying.
- Set the slide switch to airow setting I for drying short hair or styling
your hair.
Tip: You can also use the turbo button for an extra powerful airow (Fig. 4).
3 Set the temperature slide switch to the cool, warm or hot
setting(Fig.5).
- The hot setting 6 allows you to dry shower-wet hair very quickly and
safely until it is damp.
- The warm setting 5is especially suitable for drying damp hair until it is
almost dry.
- The cool setting 4allows you to gently dry hair that is almost dry and
helps to seal in shine.
4 Dry your hair by making brushing movements with the hairdryer at
asmalldistancefromyourhair(Fig.6).
Tip: When you have nished drying each section, press the cool shot button
and direct the cool airow at your hair. This xes your style and adds
shine (Fig. 7).
ENGLISH8
5 HP8183/HP8182 only: Switch the ion function on or off with the
ionslideswitch(Fig.8).
,The ion indicator light goes on to indicate that the ion function has
been activated.
HP8181 only:The ion function is always switched on.
The ion function provides additional shine and reduces frizz and static
electricity. It is particularly suitable for dry and almost-dry hair.
Concentrator
The concentrator enables you to direct the airow straight at the brush
or comb with which you are styling your hair.
1 Snaptheconcentratorontotheappliance(Fig.9).
To disconnect the concentrator, pull it off the appliance.
Volume diffuser (HP8183/HP8182 only)
The volume diffuser has been specially developed to gently dry both
straight and curly or wavy hair.
1 Toconnectthevolumediffuser,snapitontotheappliance(Fig.10).
To disconnect the volume diffuser, pull it off the appliance.
2 To add volume at the roots, insert the pins into your hair in such a
waythattheytouchyourscalp(Fig.11).
3 Make rotating movements with the appliance to distribute the
warmairevenlythroughyourhair(Fig.12).
Cleaning
Do not immerse the appliance in water or any other liquid, nor rinse it
under the tap.
1 Switch off the appliance and unplug it.
2 Removetheconcentratorordiffuser(HP8183/HP8182
only)beforeyoucleantheappliance.
3 Clean the appliance with a dry cloth.
ENGLISH 9
4 Take the air inlet grille off the appliance to remove hairs and
dust(Fig.13).
- To remove the air inlet grille, press the thumbrests on the left and the
right side of the air inlet grille simultaneously and pull the air inlet
grille off the appliance.
- To reattach the air inlet grille, press the thumbrests on the left and
the right side of the air inlet grille simultaneously and press the inlet
grille onto the appliance.
5 Cleantheconcentratorordiffuser(HP8183/HP8182only)witha
moist cloth or rinse it under the tap.
6 Makesuretheconcentratorordiffuser(HP8183/HP8182only)is
dry before you use or store it.
Storage
Do not wind the mains cord round the appliance.
1 Switch off the appliance and unplug it.
2 Put the appliance in a safe place and let it cool down.
3 You can store the appliance by hanging it from its hanging loop.
Environment
- Do not throw away the appliance with the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the
environment (Fig. 14).
Guarantee and service
If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Consumer Care Centre in
your country, go to your local Philips dealer.
ENGLISH10
