Philips HP4880/87 Manual de usuario

JetSet Control

HP4881, HP4880

ENGLISH 6

 12

 19

 25

 31

MAGYAR 37

 43

 50

 56

 62

 68

 74

 81

 87

 93

 99

Introduction

The Philips JetSet Control has been specially designed to meet your

personal needs, giving you frizz-free, beautiful and shiny hair.

This hairdryer offers you a variety of heat and speed settings. In addition,

this hairdryer has a Jet position for an ultra-strong airow and a Set

position for a cool shot.This gives you optimal styling freedom and

optimal control over your hairstyle.

You can visit our website at www.philips.com/beauty for more

information about this product or any other Philips beauty product.

General Description (Fig. 1)

AAir inlet grille

B Temperature slide switch

C Airow slide switch

D JetSET switch

EHanging loop

FVolume diffuser (HP4881 only)

GConcentrator

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

Check if the voltage indicated on the appliance corresponds to the

local mains voltage before you connect the appliance.

Check the condition of the mains cord regularly. Do not use the

appliance if the plug, the cord or the appliance itself is damaged.

If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualied persons in

order to avoid a hazard.

Keep this appliance away from water! Do not use this product near

or over water contained in baths, washbasins, sinks etc.When used

in a bathroom, unplug the appliance after use since the proximity of

water presents a risk, even when the hairdryer is switched off.

For additional protection, we advise you to install a residual current

device (RCD) with a rated residual operating current not

ENGLISH

exceeding 30mA in the electrical circuit supplying the bathroom.

Ask your installer for advice.

Keep the appliance out of the reach of children.

Never block the air grilles.

If the appliance overheats, it will switch off automatically. Unplug

the appliance and let it cool down for a few minutes. Before you

switch the appliance on again, check the grilles to make sure they

are not blocked by uff, hair, etc.

Always switch the appliance off before putting it down, even if it is

only for a moment.

Always unplug the appliance after use.

Do not wind the mains cord round the appliance.

You may notice a characteristic odour when using this hairdryer.

This is caused by the ions that are generated and it is not harmful

to the human body.

Do not probe the ion generator with metal objects.

Noiselevel: Lc= 84 dB(A)



Drying

1 Put the plug in the wall socket.

2 Switch the appliance on by selecting the desired airow setting:

Set the slide switch to airow setting II for ultra-quick drying.

Set the slide switch to airow setting I for drying short hair or styling

your hair.

You can also use the Jet position of the JetSet switch for an extra-

powerful airow. (Fig. 2)

3 Set the temperature slide switch to the Quick-Dry, Caring or

Fixation setting.

6

The Quick-Dry setting enables you to dry shower-wet hair very

quickly. (Fig. 3)

ENGLISH 7

It is recommended to use the Quick-Dry setting only on shower-wet hair

and to select the Caring setting when the hair is almost dry in order to

reduce the risk of overdrying.

5

The Caring setting gently dries the hair at a caring temperature.

(Fig. 4)

4

The Fixation setting xes the style you have created. (Fig. 5)

For long-lasting styling results, set the switch to the Fixation setting and

direct the cool airow at your hair to x your style.

You can also use the Set position of the JetSet switch to x your

style. (Fig. 6)

4 Dry your hair by making brushing movements with the hairdryer at

a small distance from the hair. (Fig. 7)



Concentrator

The concentrator enables you to direct the airow straight at the brush

or comb with which you are styling your hair.

1 Connect the concentrator by simply snapping it onto the appliance.

Disconnect it by pulling it off. (Fig. 8)

2 Switch the appliance on by setting the airow slide to position I or

II.

3 While you are drying your hair with the concentrator, you can use

a brush or comb to style your hair. (Fig. 9)

Volume diffuser (HP4881 only)

The volume diffuser has been specially developed to gently dry both

straight and curly or wavy hair.

ENGLISH8

The volume diffuser emits a gentle airow and allows you to give

your style volume and bounce. (Fig. 10)

1 Connect the diffuser by simply snapping it onto the appliance and

align the arrows on the diffuser and the barrel. Disconnect it by

pulling it off. (Fig. 11)

To add volume at the roots, insert the pins into your hair in such a

way that they touch your scalp. (Fig. 12)

2 Make rotating movements with the appliance to distribute the

warm air evenly through your hair. (Fig. 13)



When you are styling curly or wavy hair, hold the diffuser at a

distance of 10-15 cm from your head to let the hair dry gradually.

(Fig. 14)

In the meantime you can style your hair with your free hand or with a

comb.

You can also scrunch locks of hair in your hand to model the curls

and waves while drying. This will prevent the curls from sagging or

becoming frizzy.



To dry long hair, you can spread out locks of hair on top of the

diffuser. (Fig. 15)

Alternatively, you can comb the hair downwards with the pins of

the diffuser while drying. (Fig. 16)

Cleaning

Always unplug the appliance before cleaning it.

Never rinse the appliance with water.

Open the inlet grille to remove hairs and dust.

Clean the appliance with a dry cloth.

Clean the attachments with a moist cloth or by rinsing them under

the tap.

ENGLISH 9

Remove the attachments from the appliance before cleaning them.

Storage

Always unplug the appliance before storing it.

Put the appliance in a safe place and let it cool down.

Do not wind the mains cord round the appliance.

The appliance can be stored by hanging it from its hanging loop.

Environment

Do not throw the appliance away with the normal household waste

at the end of its life, but hand it in at an ofcial collection point for

recycling. By doing this you will help to preserve the environment.

(Fig. 17)

Guarantee & service

If you need information or if you have a problem, please visit the Philips

website at www.philips.com or contact the Philips Customer Care

Centre in your country (you will nd its phone number in the worldwide

guarantee leaet). If there is no Customer Care Centre in your country,

turn to your local Philips dealer or contact the Service Department of

Philips Domestic Appliances and Personal Care BV.

ENGLISH10
