Philips HD9225/50 Manual de usuario

ServiceManual

Philips Consumer Lifestyle

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification

Air Fryer

HD9225/50

HD9225/51

HD9225/52

HD9225/53

HD9220/50

11/10

PRODUCT INFORMATION

Safety info

-This product meets the requirements regarding

interference suppression on radio and TV.

-After the product has been repaired, it should function

properly and has to meet the safety requirements as

officially laid down at this moment.

-SAP coding : HD9225/50

HD9225/51

HD9225/52

HD9225/53

HD9220/50

OPTIONAL (accessories)

-Baking dish 4222 459 52761

TECHNICAL INFORMATION

-Voltage : 220 - 240V

-Frequency : 50 - 60 Hz

-Power consumption : 1425 W

-Product dimensions (W x H x D) : 287 x 315 x 384 mm

-Cord length : 1 meter

-Materials : Outer skin : Plastic (PP)

: Pan : Aluminized steel

: Basket : Aluminized steel

: Basket mesh : Stainless steel

: Coating : PTFE coating

-Capacity : 2.2 liter

(till max indicator)

-Weight : 7.0 kg

-Coloursetting : Star white /

Cashmere grey

-Temperature : 80 till 200 °C

-Fuse cut-off temp. Motor : 145 °C

TCO : 190 °C

IMPORTANT:

When you replace the pan (basketholder) or basket, rst check production week on the bottom of the appliance

to nd out which part(s) you need to order:

HD9225/5x

HD9220/5x

Pan Basket

1111 4222 459 54161 and 4222 459 54151 Due to compatibility issues, make sure you order both components

1111 1136 4222 459 54161 or 4222 459 52711 Components are compatible no need to be ordered both at once

1136 4222 459 54161 or 4222 459 54151 Components are compatible no need to be ordered both at once

HD9225/50 /51 /52 /53/ HD9220/50

2-9

TROUBLE SHOOTING

Part/

System Test Possible deviation Analyses

Replace

(depending of

the analyses

outcome)

Timer Check if the green light is lit,

and if you can hear the timer

ticking

The green light is not lit

but the timer is ticking

Check the timer-switch and the

fuse with a multimeter

Timer/Fuse

The green light is lit but

the timer is not ticking

Timer is defective Timer

Thermostat Set the temperature at 80°C

and check if the heating

element is getting warm

(Check input power approx.

1425W)

The green light should be lit

and the orange light should

switch off after it reaches

80°C

Both green and orange

light are lit but there is no

heating

Check the heating element with

a multimeter

Heating element

If the green light is lit and

the orange light is off

Check the thermostat with a

multimeter

Thermostat

If both the green and

orange light are off

Check the timer and fuse with a

multimeter

Timer/Fuse

The orange light does not

switch off after reaching

approx. 80°C

Thermostat is defective Thermostat

Motor fan

assy

Set the timer and listen if the

motor is running

Motor is not running The fan is scraping the housing

turning it by hand (Switch off the

power when you do this test!)

Motor fan assy

The fan is not scraping the

housing turning it by hand

(Switch off the power when you

do this test!):

Check the motor fan assy, timer

and fuse with a multi meter

Motor fan assy /

Timer/Fuse

Heating

element

Check if the heating element

is getting warm

(Check input power approx.

1425W)

If the Orange light is on

and the heating element

does not heat

Check the heating element with

a multimeter

Heating element

If the heating element

does not heat and the

orange light is off

Check the timer, fuse and

thermostat with a multimeter

Timer/Fuse/

Thermostat

Thermal fuse Set the timer and check if

the green light is lit

Green light is not lit Check the timer and fuse with a

multimeter

Timer/Fuse

HD9225/50 /51 /52 /53/ HD9220/50

3-9

REPAIR INSTRUCTIONS

General remark;

When you need to disconnect a wire from the crimp housing, please cut the wire half way (See in the picture below) and

always connect the wires with a new 2 wire crimp housing 4222 459 51851. To crimp the housing use the Lobster AK25 No2 or

Muromoto Tekko MR30A Nr 2 with Air pressure = 6 kg/cm².

Crimp instruction CE2

1) Strip wires: 16mm (0.63 in) Max. 13mm (0.51) Min.

2) Twist the wires together along the entire length of the strip and insert them into crimp housing .

3) Center the crimp tool on the sleeve.

4) Crimp the housing with 6 kg/cm².

Route the wire route, using 5 tie-wraps according the picture below;

HD9225/50 /51 /52 /53/ HD9220/50

4-9

A. Top cover removal

1. Open the cover from the top cover by using a athead

screw driver to open the 6 click connections.

2. Use a crosshead screw driver to unscrew the 4 screws A.

Note: When you close the top cover, use a screw

torque off 50 till 80 Nm (5 to 8 kgf.cm)

3. Use a athead screw driver to open the “timer top cover”

and pull the knob from the appliance.

4. Unscrew the screw Bunder the timer top cover.

Note: Replace the timer cover and / or the cover in

case of damage and / or scratches.

Tip: Open the “timer cover” from the bottom side,

to avoid scratches on visible places.

DISASSEMBLY- AND RE-ASSEMBLY ADVICE

HD9225/50 /51 /52 /53/ HD9220/50

5-9

B. Cover housing removal

1. Follow previous step A

2. Open the motor fan assy from the base by unscrewing the

6screws C. Be aware of the 2 screws under the lter.

C. Heating element + Fan Removeval

1. Follow previous step Aand B

2. Undo the heating element from the double heat shield by

unscrewing the 3 screws D.

3. Cut the 2 heating element wires halfway and remove the

heating element.

4. Undo the nut from the left screw thread and remove the

fan.

D. Double heat shield removal

1. Follow previous step A, Band C

2. Remove the double heat shield out of the motor fan assy

by unscrewing the 3 screws E.

E. Timer removal

1. Follow step A

2. Unscrew the 2 screws Fbehind the timer knob.

3. Remove the wires of the timer.

DISASSEMBLY- AND RE-ASSEMBLY ADVICE

HD9225/50 /51 /52 /53/ HD9220/50

6-9

F. Thermostat removal

1. Follow previous step A

2. Remove the 3 screws Gfrom the thermostat assy.

3. Follow previous step B, C, D

By step Cdo not cut the wires.

Note: be careful with the wire/ heating element

connecting, this connection is fragile.

4. Remove the thermostat sensor by undoing the metal band.

metal band

Note: Please make sure while re-assembling the new

thermostat that the routing will be done as

shown in below picture.

DISASSEMBLY- AND RE-ASSEMBLY ADVICE

G. Motor assy removal

1. Follow previous step A, B, C, D

By step Cdo not cut the wires.

2. Remove the thermostat sensor (See instruction F4)

3. Remove the fuse and the earth connection from the

double heat shield.

Earth connection

Double

heat shield

Fuse

4. Cut the motor wires half way and remove the motor fan

assy.

HD9225/50 /51 /52 /53/ HD9220/50

7-9

PARTS LIST

Electrical circuit

When the appliance does not work, check the electrical circuit.

Open de lid panel always on the underside. Always replaces this panel in case of damaged, scratches body or broken click

connection.

LThermostat

Resistor

Orange

Neon lamp

Resistor

Green

Neon lamp

HeaterMotor

Therm.

Fuse

220 - 240 V

50 - 60 Hz

= Red

= Black

= Blue

= White

= Yellow

= Green

YL & GN

BK BK

WT WT

Pos Service code Description

4222 459 52771

4222 459 52691

4222 459 52701

4222 459 51901

4222 459 52711

4222 459 54151

Cover

Timer knob

Timer cover

Food separator

Basket wk1136

wk1136

Cashmere grey

Black

Oyster Metellic

Cashmere grey

4222 459 52721

4222 459 51911

4222 459 54671

4222 459 52731

4222 459 53251

Pan (Basket holder)

Rubber foot wk1116

Rubber foot wk1116

Top cover

Stainless steel timer

Star white

4222 459 49181

4222 459 49141

4222 459 49131

4222 459 53391

4222 459 52741

Fuse incl. wires

Fan

Heating element incl. wires

Base incl. wires

220-240 V, 50 Hz

220-240 V, 60 Hz

Star white

16 *

4222 459 52751

4222 459 49201

4222 459 53401

4222 459 52761

Thermostat assy

Motor, fan assy

Baking dish

220-240 V, 50 Hz

60 Hz

4222 459 51851 10 pieces of 2 wire crimp housing (CE-2)

* Optional for HD9220/50

HD9225/50 /51 /52 /53/ HD9220/50

8-9

EXPLODED VIEW

HD9225/50 /51 /52 /53/ HD9220/50

9-9

EXPLODED VIEW
