Philips HX6992/03 Manual de usuario

FlexCare+

900+ series

Rechargeable

sonic toothbrush

www.philips.com/support

registered trademarks of KPENV. Quadpacer, Sonicare,

and the Sonicare logo are trademarks of

Philips Oral Healthcare, Inc. and/or KPENV.

Printed in the U.S.A.

Printed on 100% recycled paper.

Protected by U.S. and international patents.

Other patents pending. Reg. U.S. Pat. & Tm. Off.

603930_FlexCarePLUS_DFU-02AW.indd 1 12/19/2008 11:07:47 AM

HX6996,HX6995,HX6992,HX6972,HX6962,HX6942

ENGLISH 4

DEUTSCH 15

FRANÇAIS 27

ITALIANO 39

NEDERLANDS 51

Introduction

Congratulations on your purchase and welcome to Philips! To fully benet

from the support that Philips offers, register your product at www.philips.

com/welcome.

Important

Read this user manual carefully before you use the appliance and save it for

future reference.

Danger

- Keep the charger and/or sanitiser away from water. Do not place or

store it over or near water contained in a bathtub, washbasin, sink

etc. Do not immerse the charger and/or sanitiser in water or any

other liquid.After cleaning, make sure the charger and/or sanitiser is

completely dry before you connect it to the mains.

Warning

- The mains cord cannot be replaced. If the mains cord is damaged,

discard the charger and/or sanitiser.

- Always have the charger and/or sanitiser replaced with one of the

original type in order to avoid a hazard.

- Do not use the charger and/or sanitiser outdoors or near heated

surfaces.

- If the appliance is damaged in any way (brush head, toothbrush handle,

charger and/or sanitiser), stop using it.This appliance contains no user-

serviceable parts. If the appliance is damaged, contact the Consumer

Care Centre in your country (see chapter ‘Guarantee & service’).

- This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for

their safety.

- Children should be supervised to ensure that they do not play with the

appliance.

- Discontinue use of the sanitiser if the UV light bulb remains on when

the door is open. UV light can be harmful to the human eye and skin.

Keep the sanitiser out of the reach of children at all times.

Caution

- Do not clean the brush head, the handle, the charger, the charger cover

and/or the sanitiser in the dishwasher.

- If you have had oral or gum surgery in the previous 2 months, consult

your dentist before you use the toothbrush.

- Consult your dentist if excessive bleeding occurs after using this

toothbrush or if bleeding continues to occur after 1 week of use.

- The Sonicare toothbrush complies with the safety standards for

electromagnetic devices. If you have a pacemaker or other implanted

device, contact your physician or the manufacturer of the implanted

device prior to use.

- If you have medical concerns, consult your doctor before you use the

Sonicare.

ENGLISH

- This appliance has only been designed for cleaning teeth, gums and

tongue. Do not use it for any other purpose. Stop using the appliance

and contact your doctor if you experience any discomfort or pain.

- Do not use other brush heads than the ones recommended by the

manufacturer.

- If your toothpaste contains peroxide, baking soda or bicarbonate

(common in whitening toothpastes), thoroughly clean the brush head

with soap and water after each use.This prevents possible cracking of

the plastic.

- The UV light bulb is hot during and immediately after the sanitising

cycle. Do not touch the UV light bulb when it is hot.

- Do not operate the sanitiser without the protective screen in place to

avoid contact with a hot bulb.

Electromagnetic elds (EMF)

This Philips appliance complies with all standards regarding electromagnetic

elds (EMF). If handled properly and according to the instructions in this

user manual, the appliance is safe to use based on scientic evidence

available today.

General description (Fig. 1)

AHygienic travel cap

BBrush head

CInterchangeable colour code ring

DHandle with soft grip

EPower on/off button

F Mode button

GBrushing modes

HDeluxe recharge gauge

I UV sanitiser base with integrated charger and cord wrap (specic types

only)

J UV sanitiser (specic types only)

K Deluxe charger (specic types only)

LCharger cover with brush head holder

MTravel charger

NCharger base with cord wrap

- Not shown: UV light bulb

- Not shown: Sanitiser drip tray

- Not shown: Protective screen for UV light bulb

Preparing for use

Changing the colour code ring

Sonicare brush heads come with interchangeable colour code rings to

identify your brush head.

To change the colour code ring:

ENGLISH 5

1 Pull the colour code ring from the bottom of the brush head.

2 Install a new ring by slipping one edge of the new ring over the

bottom of the brush head.

Attaching the brush head

1 Align the brush head so the bristles face the front of the handle.

2 Firmly press the brush head down on the metal shaft until it stops.

Note:There is a small gap between the colour code ring and the handle.

Charging your Sonicare

1 Put the mains plug of the charger or sanitiser in the wall socket.

2 Place the handle on the charger or sanitiser.

,The ashing light of the battery gauge indicates that the toothbrush

is charging.

- 1 solid green LED indicates that the toothbrush is 34-66% charged.

- 2 solid green LEDs indicate that the toothbrush is 67-94% charged.

- 3 solid green LEDs indicate that the toothbrush is fully charged.

Note: If the battery charge of your Sonicare is low, you hear 3 beeps and 1

LED of the recharge gauge ashes yellow for 30 seconds after completing the

brushing cycle.

Note:To keep the battery fully charged at all times, you may keep your

Sonicare on the charger when not in use. Once the Sonicare is fully charged,

the charger draws minimal energy from the wall socket.

Note: It takes at least 24 hours to fully charge the battery.

ENGLISH6

Using the Sonicare

Brushing instructions

1 Wet the bristles and apply a small amount of toothpaste.

2 Place the toothbrush bristles against the teeth at a slight angle

towards the gumline.

3 Press the power on/off button to switch on the Sonicare.

4 Apply light pressure to maximise Sonicare’s effectiveness and let the

Sonicare toothbrush do the brushing for you. Do not scrub.

5 Gently move the brush head slowly across the teeth in a small back

and forth motion so the longer bristles reach between your teeth.

Continue this motion throughout your brushing cycle.

Note:To make sure you brush evenly throughout the mouth, divide your mouth

into 4 sections using the Quadpacer feature (see chapter ‘Features’).

6 Begin brushing in section 1 (outside top teeth) and brush for 30

seconds before moving to section 2 (inside top teeth). Continue

brushing in section 3 (outside bottom teeth) and brush for 30

seconds before moving to section 4 (inside bottom teeth).

7 After you have completed the brushing cycle, you can

spend additional time brushing the chewing surfaces of your teeth

and areas where staining occurs.You may also brush your tongue,

with the toothbrush switched on or off, as you prefer.

Your Sonicare is safe to use on:

- Braces (brush heads wear out sooner when used on braces)

- Dental restorations (llings, crowns, veneers)

Brushing modes

Sonicare automatically starts in the default Clean mode.

1 Prior to switching on the Sonicare, press the mode button to toggle

between modes.

,The selected brushing mode illuminates.

,Once a brushing mode has been selected, it remains active until

another brushing mode is selected.

Note:When the toothbrush is switched on, you cannot toggle between modes.

The following brushing modes are available:

Clean

Complete whole mouth cleaning (2 minutes).

Gum Care

Complete whole mouth cleaning (2 minutes) plus gentle cleaning for

problem areas and along the gumline (1 minute).

Refresh

Touch-up for a quick clean (1 minute).

ENGLISH 7

Sensitive

Gentle cleaning for sensitive gums and teeth (2 minutes).

Massage

Gentle gum stimulation (2 minutes).

Note:When Sonicare is used in clinical studies, the default 2-minute Clean

mode must be selected.The handle has to be fully charged. Deactivate the

Easy-start feature. For areas where excess staining occurs, an additional 30

seconds of brushing time can be spent to help remove stains.

Features

Easy-start

This Sonicare type comes with the Easy-start feature activated.

The Easy-start feature gently increases power over the rst 14 brushings to

help you get used to brushing with the Sonicare.

Note: Each of the rst 14 brushings must be at least 1 minute in length to

properly move through the Easy-start ramp-up cycle.

Deactivating or activating the Easy-start feature

1 Attach your brush head to the handle.

2 Place the handle on the plugged-in charger.

- To deactivate Easy-start:

Press and hold the power on/off button for 2 seconds.You hear 1 beep to

indicate that the Easy-start feature has been deactivated.

- To activate Easy-start:

Press and hold the power on/off button for 2 seconds.You hear 2 beeps to

indicate that the Easy-start feature has been activated.

Note: Using the Easy-start feature beyond the initial ramp-up period is not

recommended and reduces Sonicare’s effectiveness in removing plaque.

Smartimer

The Smartimer indicates that your brushing cycle is complete when

it automatically switches off the toothbrush at the end of the brushing

cycle.

Dentists recommend brushing at least 2 minutes twice a day.

Quadpacer

- The Quadpacer is an interval timer that has a short beep and pause to

remind you to brush the 4 sections of your mouth. Depending on the

brushing mode you have selected, the Quadpacer beeps at different

intervals during the brushing cycle. See section ‘Brushing modes’

in chapter ‘Using the Sonicare’.

The Quadpacer feature on this type has been activated.To deactivate or

reactivate the Quadpacer feature:

1 Place the handle with a brush head attached on the plugged-in

charger.

2 Press and hold the mode button for 2 seconds.

ENGLISH8

,You hear 1 beep to indicate the Quadpacer has been deactivated or

you hear 2 beeps to indicate the Quadpacer has been activated.

Cord wrap on deluxe charger (specic types only)

If your type includes the deluxe charger cover and base, the travel charger

is pre-installed inside the cover. If you want to shorten the mains cord, you

can store excess cord in the cord wrap feature built into the charger base.

1 To separate the charger cover from the charger base, press the two

grey snap bars on the charger base and pull the white charger cover

upwards.

2 Wrap excess power cord around the grey charger base as shown in

the picture. Be sure to wrap the cord on the inside of the two snap

levers.

3 When you have stored the excess cord, guide the mains cord

through the small groove in the rear of the grey charger base.

4 To reattach the charger cover, press it down over the charger base

until it snaps into place.

Tip: For extra convenience during travel, you can remove the travel charger and

use it without the charger cover and charger base.

Cord wrap on sanitiser with integrated charger (specic types

only)

- If your type includes the sanitiser, you can store excess cord in the cord

wrap feature built into the bottom of the sanitiser.

ENGLISH 9

Sanitising (specic types only)

- With the UV sanitiser you can clean your brush head after every use.

Discontinue use of the sanitiser if the UV light bulb remains on when

the door is open or if the blue window is broken or missing from

the sanitiser. UV light can be harmful to the human eye and skin.This

appliance should be kept out of reach of children at all times.

Unplug the sanitiser and call Consumer Care if the sanitiser gives off

smoke or a burning smell while it is operating.

1 After brushing, rinse the brush head and shake off excess water.

Do not place the travel cap on the brush head during sanitisation.

2 Place your nger in the door recess on top of the sanitiser and pull

open the door.

3 Place the brush head on one of the 2 pegs in the sanitiser.

- Make sure the bristles of the brush head directly face the light bulb.

Note: Only clean Sonicare ProResults brush heads in the sanitiser.

4 Make sure the sanitiser is plugged into the wall socket.

5 Close the door and press the green power on/off button once to

select the UV clean cycle.

Note:You can only switch on the sanitiser if the door is properly closed.

Note:The sanitiser stops if you open the door during the sanitising cycle.

Note: The sanitiser cycle runs for 10 minutes and then automatically switches

off.

,The sanitiser is in operation when the blue light glows through the

window.

,When the sanitising cycle is complete, the sanitiser automatically

switches off.

Cleaning

Do not clean the brush head, handle, travel charger, charger cover and

the UV sanitiser in the dishwasher.

ENGLISH10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Cepillo de dientes eléctrico de Philips

Philips

Philips sonicare AirFloss Ultra HX8391/02 Manual de usuario

Philips

Philips HX2740/02 Manual de usuario

Philips

Philips sonicare HX3641 Manual de usuario

Philips

Philips Sonicare DiamondClean Smart HX9924/12 Manual de usuario

Philips

Philips Sonicare FlexCare Platinum Connected... Manual de usuario

Philips

Philips sonicare ProtectiveClean 4500/5100 Manual de usuario

Philips

Philips HX6962/70 Manual de usuario

Philips

Philips Sonicare DiamondClean HX6062/94 Manual de usuario

Philips

Philips Sonicare CleanCare+ Manual de usuario

Philips

Philips sonicare DiamondClean 9000 Series Manual de usuario

Philips

Philips Sonicare FlexCare+ HX6972 Manual de usuario

Philips

Philips DiamondClean Sonicare HX9332 Manual de usuario

Philips

Philips HX6850 Manual de usuario

Philips

Philips Sonicare FlexCare HX6932/36 Manual de usuario

Philips

Philips Sonicare Optimal Clean HX6829/76 Manual de usuario

Philips

Philips Sonicare HX992W Manual de usuario

Philips

Philips HX6856/17 Manual de usuario

Philips

Philips Sonicare DiamondClean Manual de usuario

Philips

Philips Sonicare HX6902/02 Manual de usuario

Philips

Philips Sonicare HX3631/02 Manual de usuario

Philips

Philips ProResults HX6023/82 Manual de usuario

Philips

Philips Sonicare DiamondClean Guía de instalación

Philips

Philips EasyClean HX6511/33 Manual de usuario

Philips

Philips Sonicare DiamondClean HX9302/31 Manual de usuario

Manuales populares de Cepillo de dientes eléctrico de otras marcas

Omron

Omron Colgate ProClinical C600 Manual de usuario

Dentle

Dentle One Plus Manual de usuario

SPORT ELEC

SPORT ELEC Smilyss HC5305C Manual de usuario

Kompernass

Kompernass dentalux DAZ 2.4 A1 Manual de usuario

ONE

ONE PERSONAL OSEB001-W Manual de usuario

Panasonic

Panasonic EW118WC Operating Manual de usuario

Jula

Jula 804-193 Manual de usuario

Panasonic

Panasonic EW-PDA52 Manual de usuario

Braun

Braun OC17525 Manual de usuario

Panasonic

Panasonic ER-CBL1 Manual de usuario

Waterpik

Waterpik Sensonic Professional Plus SR-3000 Manual de usuario

TrueLife

TrueLife SonicBrush T100 Manual de usuario

Braun

Braun Oral-B 450 Manual de usuario

Braun

Braun Oral-B Professional Care 7000 Manual de usuario

Panasonic

Panasonic EW1012 Manual de usuario

Waterpik Technologies

Waterpik Technologies WP-900 Manual de usuario

Waterpik

Waterpik ST-01 Manual de usuario

Kooper

Kooper Sonic Pulse 2192267 Manual de usuario
