Philips HX 2585 Manual de usuario

ServiceManual

Philips Domestic Appliances and Personal Care

Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification

Tooth brush

HX 2585

PRODUCT INFORMATION

- Gum Protection System : The brush automatically ﬂexes back

when too much pressure is applied.

Because of this signal, the user will

develop a safe and efﬁcient brushing

technique.

- Active tip : Removes plaque between the teeth

- Number of brush heads

included in fancy box : 3

- Colours : White/ grey

- Timer / charging light : The pilot light blinks green during

charging.

When the brush time of two

minutes has passed, the pilot light

blinks red.

- Waterproof : Yes

- Anti rolling strip : To prevent the appliance from

rolling away

TECHNICAL DATA

Voltage : 110-127 V; 200-240 V, 50-60 Hz

Power consumption : 2.8 Watts

Speed (top) : up to 15.000 brush strokes

per minute

Gum Protection System click at : 270 gr.

Charging time (empty to full) : 16 hours

Operating time (full to empty) : ± 25 minutes

Battery type : NiCd

4322 277 00936

02/06

SERVICE INFORMATION

Product meets the requirements regarding

interference suppression on radio andTV.

Hand unit tooth brush (1)

Never open the hand unit of the toothbrush because the

unit is no longer watertight after it has been opened.

Replace the entire unit in case of a defect.

When discarding the hand unit, remove the built-in

rechargeable battery.

The battery should be completely empty.

For instructions p.t.o.

Charging unit (2)

In case of a defective charging unit or damaged cord the

complete charging unit must be replaced.

Charging tips

· The appliance will only charge if the appliance is

switched off.

·Please note that the electricity supply to sockets in mirror

cabinets over washbasins or shaver sockets in bathrooms

may be cut off when the light is switched off.

·The toothbrush can be put back in the stand after use and

left to charge continuously. However, to extend the lifetime

of the battery proceed as follows:

When the appliance is used for the ﬁrst time, continue to

use it until the battery is empty.

Use the appliance in the normal way without recharging it

between the brushing sessions.

Recharge the appliance when the motor almost stops

running.

Repeat this procedure 3 times in a row every 6 months.

DISASSEMBLY ADVICE + EXPLODED VIEW + PARTS LIST HX 2585

INSTRUCTIONS

TO REMOVE

THE BATTERY

Pick up the charging unit and

place the toothbrush on the pin.

Turn the toothbrush anti-

clockwise to unscrew the

bottom of the toothbrush.

Turn the toothbrush upside

down and press it down on

a hard surface to remove the

battery holder.

Open the lid of the battery

holder by means of a

screwdriver.

Lift the battery out of the

battery holder by means of a

screwdriver.

After the bottom has been

unscrewed, the appliance

may not be watertight

anymore and the guarantee

will become invalid.

Pos Description

Hand unit (NiCd)

Stand 220 - 240 V, EURO plug

Stand 220 - 240 V, UK plug

Stand 220 V, Argentina

Stand 220 - 240 V, Australia

Stand 220 V, Korea

Stand 110 - 127 V, Taiwan

Cover

Storage container

Brush head (2-pack)

Travel box

Service code

4203 035 75460

4203 035 75490

4203 035 75500

4203 035 75510

4203 035 75520

4203 035 75530

4203 035 75540

4203 035 75560

4203 035 75570

8812 012 40020

4203 035 78630

2 + 3
