Philips TW-RQ1050 Manual de usuario

RQ1090, RQ1062, RQ1060, RQ1052, RQ1050 (no charger)

ENGLISH 6

 18

 31

 43

 54

 66

 78

 91

 103

 114

 126

 138

 151

 163

 174

 186

Introduction

Thank you for buying this Philips shaver. Please read this user manual, as it

contains information about the wonderful features of this shaver as well

as some tips to make shaving easier and more enjoyable.

Important

Read this user manual carefully before you use the shaver and the Power

Pod. Save the user manual for future reference.

Danger

- Make sure the adapter does not get wet (Fig. 1).

Warning

- Be careful with hot water. Always check if the water is not too hot, to

prevent your hands from getting burnt.

- The adapter contains a transformer. Do not cut off the adapter to

replace it with another plug, as this causes a hazardous situation.

- The shaver and the Power Pod are not intended for use by persons

(including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliances by a person responsible for their safety.

- Children should be supervised to ensure that they do not play with

the shaver and the Power Pod.

Caution

- Do not use the shaver, the Power Pod or the adapter if it is damaged.

- Charge and store the shaver at a temperature between 5°C and

35°C.

- Always put the protection cap on the shaver to protect the shaving

heads when you are travelling.

- Never use scouring pads, abrasive cleaning agents or aggressive liquids

such as petrol or acetone to clean the appliance.

- Only use the adapter supplied.

- If the adapter is damaged, always have it replaced with one of the

original type in order to avoid a hazard.

ENGLISH

- Never immerse the Power Pod in water, nor rinse it under the

tap (Fig. 2).

Compliance with standards

- The shaver complies with the internationally approved IEC safety

regulations and can be safely cleaned under the tap (Fig. 3).

- These Philips appliances comply with all standards regarding

electromagnetic elds (EMF). If handled properly and according to the

instructions in this user manual, the appliances are safe to use based

on scientic evidence available today.

General

- The adapter transforms 100-240 volts to a safe low voltage of less

than 24 volts.

- Noise level: Lc = 64 dB [A]

Overview (Fig. 4)

AProtection cap

BShaving unit

CTrimmer

DTrimmer on/off slide

EShaver (RQ1090/RQ1062/RQ1060/RQ1052/RQ1050)

FShaver on/off button

GDisplay

HPower Pod

ICleaning brush

JAdapter

KSmall plug



Before you use the shaver for the rst time, remove the protective foil

from the display.

The ve shaver types (RQ1090, RQ1062, RQ1060, RQ1052 and

RQ1050) have different displays, which are shown in the gures below.

- RQ1090 (Fig. 5)

- RQ1062/RQ1060 (Fig. 6)

- RQ1052/RQ1050 (Fig. 7)

ENGLISH 7

Charging

- Charging takes approx. 1 hour.

- When you place the shaver in the Power Pod, the

display automatically switches off after approx. 5 hours.

RQ1090

- When the shaver is charging, the minutes indication and the plug

symbol ash (Fig. 8).

- The shaving minutes increase until the shaver is fully charged.

RQ1062/RQ1060

- When the shaver is charging, the plug symbol ashes. (Fig. 9)

- First the arrowheads of the bottom charge level ash, then the

arrowheads of the second level ash, and so on until the shaver is

fully charged.

RQ1052/RQ1050

- When the shaver is charging, the battery symbol ashes

blue. (Fig. 10)



RQ1090

- When the battery is fully charged, the minutes indication is visible on

the display and the plug symbol disappears from the display. (Fig. 11)

RQ1062/RQ1060

- When the battery is fully charged, all arrowheads and all charge level

lights light up blue continuously and the plug symbol disappears from

the display (Fig. 12).

- When you remove the shaver from the Power Pod, the arrowheads

of the top charge level light up blue to indicate that the battery is

full (Fig. 13).

RQ1052/RQ1050

- When the battery is fully charged, the battery symbol lights up blue c

ontinuously. (Fig. 14)

ENGLISH8



RQ1090

- When the battery is almost empty (when there are only 5 or fewer

shaving minutes left), the minutes indication and the plug symbol start

to ash (Fig. 8).

- When you switch off the shaver, the shaving minutes and the plug

symbol continue to ash for a few more seconds. You hear a beep

when there are no minutes left.

RQ1062/RQ1060

- When the battery is almost empty (when there are only 5 or fewer

shaving minutes left), the battery symbol ashes red and the

arrowheads of the bottom charge level ash blue. (Fig. 15)

- When you switch off the shaver, the battery symbol and the

arrowheads of the bottom charge level continue to ash for a few

seconds.

RQ1052/RQ1050

- When the battery is almost empty (when there are only 5 or fewer

shaving minutes left), the battery symbol lights up red. (Fig. 10)

- When you switch off the shaver, the battery symbol starts to ash for

a few seconds.



RQ1090

- The remaining battery capacity is indicated by the number of shaving

minutes shown on the display. (Fig. 11)

RQ1062/RQ1060

- The remaining battery capacity is indicated by the ashing

arrowheads of a particular charge level (Fig. 13)

Clean shaver

For optimal shaving performance, we advise you to clean the shaver after

every use.

- The tap symbol ashes to remind you to clean the shaver (Fig. 16).

ENGLISH 9

Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look

different but show the same indication.

Replace shaving unit

For maximum shaving performance, we advise you to replace the shaving

unit every two years.

- To remind you to replace the shaving unit, the shaving unit symbol

ashes (all types) and you hear a beep when you switch off the

shaver (RQ1090 only).This happens at the end of 7 successive shaves

to remind you to replace the shaving unit. (Fig. 17)

Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look

different but show the same indication.



You can lock the shaver when you are going to travel. The travel lock

prevents the shaver from being switched on by accident.



1 Press the on/off button for 3 seconds to enter the travel lock

mode (Fig. 18).

,The lock symbol appears on the display (all types) and you hear a

beep (RQ1090 only) to indicate that the travel lock has been

activated.

Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look

different but show the same indication.



1 Press the on/off button for 3 seconds.

,The motor starts running to indicate that the travel lock has been

deactivated.

The shaver is now ready for use again.

Note:When you place the shaver in the plugged-in Power Pod, the travel lock

is automatically deactivated.

ENGLISH10
