Philips RQ1075 Manual de usuario

RQ1095, RQ1085, RQ1075

ENGLISH 6

FRANÇAIS 28

INDONESIA 52

한국어 76

BAHASA MELAYU 98

ภาษาไทย 124

 142

繁體中文 165

简体中文 185

Introduction

Thank you for buying this Philips shaver. Please read

this user manual, as it contains information about the

wonderful features of this shaver as well as some tips

to make shaving easier and more enjoyable.

Important

Read this user manual carefully before you use the

shaver, the Jet Clean System and the Power Pod.

Save the user manual for future reference.

Danger

Make sure the adapter does not get wet.

Warning

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

The adapter contains a transformer. Do not cut

off the adapter to replace it with another plug, as

this causes a hazardous situation.

These appliances are not intended for use

by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been

given supervision or instruction concerning use of

the appliances by a person responsible for their

safety.

Children should be supervised to ensure that they

do not play with the appliances.

Caution

Do not use the shaver, the Jet Clean System, the

Power Pod or the adapter if it is damaged.

Charge and store the shaver at a temperature

between 5°C and 35°C.

ENGLISH

Always put the protection cap on the shaver

to protect the shaving heads when you are

travelling.

Never use scouring pads, abrasive cleaning agents

or aggressive liquids such as petrol or acetone to

clean the appliance.

Only use the adapter supplied.

If the adapter is damaged, always have it replaced

with one of the original type in order to avoid a

hazard.

Only use the Jet Clean System with the original

HQ200 cleaning uid.

Never immerse the Jet Clean System in water nor

rinse it under the tap.

Use and store the Jet Clean System at a

temperature between 5°C and 35°C.

Always place the Jet Clean System on a stable,

level and horizontal surface to prevent leakage.

Empty the cleaning chamber and clean it

thoroughly by rinsing it with hot tap water every

15 days.

Always place the Jet Clean System on a uid-

resistant surface.

The Jet Clean System thoroughly cleans but does

not disinfect your shaver, therefore do not share

the shaver with others.

The cleaning chamber of the Jet Clean System is

not dishwasher-proof.

When the Jet Clean System is ready for use, do

not move it to prevent leakage of cleaning uid.

Never immerse the Power Pod in water, nor rinse

it under the tap.

ENGLISH 7

Compliance with standards

The shaver complies with the internationally

approved IEC safety regulations and can be safely

cleaned under the tap.

These Philips appliances comply with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliances are safe to use based

on scientic evidence available today.

General

The adapter transforms 100-240 volts to a safe

low voltage of less than 24 volts.

Overview (Fig. 1)

AProtection cap

BShaving unit

CTrimmer

DTrimmer on/off slide

EShaver (RQ1090/RQ1060/RQ1050)

FShaver on/off button

GDisplay

HShaver holder

IJet Clean System (RQ1005/RQ1000)

JJet Clean System on/off button

KCleaning symbol

LDrying symbol

M’Cleaning chamber empty’ symbol

NCleaning chamber

OPower Pod

PCleaning brush

QAdapter

RSmall plug

ENGLISH8

The display

Before you use the shaver for the rst time, remove

the protective foil from the display.

The three shaver types (RQ1090, RQ1060 and

RQ1050) have different displays, which are shown in

the gures below.

RQ1090

RQ1060

RQ1050

Charging

Charging takes approx. 1 hour.

When you place the shaver in the Jet

Clean System or in the Power Pod, the

display automatically switches off after approx. 5

hours.

RQ1090

When the shaver is charging, the minutes

indication and the plug symbol ash.

The shaving minutes increase until the shaver is

fully charged.

ENGLISH 9

RQ1060

When the shaver is charging, the plug

symbol ashes.

First the arrowheads of the bottom charge level

ash, then the arrowheads of the second level

ash, and so on until the shaver is fully charged.

RQ1050

When the shaver is charging, the battery symbol

ashes blue.

Battery fully charged

RQ1090

When the battery is fully charged, the minutes

indication is visible on the display and the plug

symbol disappears from the display.

RQ1060

When the battery is fully charged, all arrowheads

and all charge level lights light up blue continuously

and the plug symbol disappears from the display.

When you remove the shaver from the Jet Clean

System or the Power Pod, the arrowheads of the

top charge level light up blue to indicate that the

battery is full.

ENGLISH10

RQ1050

When the battery is fully charged, the battery

symbol lights up blue continuously.

Battery low

RQ1090

When the battery is almost empty (when there

are only 5 or fewer shaving minutes left), the

minutes indication and the plug symbol start to

ash.

When you switch off the shaver, the shaving

minutes and the plug symbol continue to ash for

a few more seconds.You hear a beep when there

are no minutes left.

RQ1060

When the battery is almost empty (when there

are only 5 or fewer shaving minutes left), the

battery symbol ashes red and the arrowheads of

the bottom charge level ash blue.

When you switch off the shaver, the battery

symbol and the arrowheads of the bottom charge

level continue to ash for a few seconds.

RQ1050

When the battery is almost empty (when there

are only 5 or fewer shaving minutes left), the

battery symbol lights up red.

When you switch off the shaver, the battery

symbol starts to ash for a few seconds.

ENGLISH 11

Remaining battery capacity

RQ1090

The remaining battery capacity is indicated by the

number of shaving minutes shown on the display.

RQ1060

The remaining battery capacity is indicated by the

ashing arrowheads of a particular charge level

Clean shaver

For optimal shaving performance, we advise you to

clean the shaver after every use.

The tap symbol ashes to remind you to clean the

shaver.

Note:The displays of types RQ1060 and RQ1050 look

different but show the same indication.

Replace shaving unit

For maximum shaving performance, we advise you

to replace the shaving unit every two years.

To remind you to replace the shaving unit, the

shaving unit symbol ashes (all types) and you

hear a beep when you switch off the shaver

(RQ1090 only).This happens at the end of 7

successive shaves to remind you to replace the

shaving unit.

Note:The displays of types RQ1060 and RQ1050 look

different but show the same indication.

ENGLISH12
