Philips Norelco CoolSkin 6716X Manual de usuario

6716X

6711X

6701X

Rechargeable

Cordless Razor

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 1 (Black plate)

ENGLISH 4

ESPAÑOL 22

6716X, 6711X, 6701X

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 3 (Black plate)

IMPORTANT SAFETY

INSTRUCTIONS

When using an electric razor, basic safety precautions should

always be followed, including the following:

Read all instructions before using this appliance.

DANGER

To reduce the risk of electric shock:

1. Do not reach for a razor while plugged in that has fallen into

water. Unplug immediately.

2. Do not use a razor while plugged in while bathing or in a

shower.

3. Do not place or store a razor while plugged in where it can fall

or be pulled into a tub or sink. Do not place razor while

plugged in into or drop into water or other liquid.

4. Always unplug this razor from the electrical outlet immediately

after (re)charging.

5. Unplug razor before cleaning.

6 When discarding razor, unplug razor and remove rechargeable

batteries. See Battery Removal instructions.

WARNING

To reduce the risk of burns, fire, electric shock, or injury to

persons:

1. Close supervision is necessary when this razor is used by, on, or

near children or invalids.

2. Use this razor for its intended household use as described in

this manual. Do not use attachments not recommended by

Philips Electronics North America Corporation.

3. Never operate this razor if it has a damaged cord or plug, if it is

not working properly, if it has been dropped or damaged, or

ENGLISH4

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 4 (Black plate)

dropped into water. Return the razor to an Authorized Norelco

Service Location for examination and repair.

4. Keep the razor and cord away from heated surfaces.

5 Never drop or insert any object into any opening.

6. Do not charge razor or plug in outdoors or operate where

aerosol (spray) products are being used or where oxygen is

being administered.

7. Do not use this razor with a damaged or broken comb, as facial

injury may occur.

Always attach plug to razor first, then charging plug into outlet. Be

certain plug is inserted firmly into razor, up to mark indicated on plug.

To disconnect, turn razor off then remove charging plug from outlet.

9. To prevent possible damage to the cord, do not wrap cord

around the razor.

10. Never put razor in direct sunlight or store in a pouch at a

temperature above 140ºF.

11.

Razor is water-safe and can be rinsed under running tap water or used

in shower. Do not submerge razor in water.

SAVE THESE

INSTRUCTIONS

IMPORTANT: The power plug contains a transformer. Do not

cut off the power plug to replace it with another plug, as this will

cause a hazardous condition.

IMPORTANT

YOUR RAZOR CONTAINS A NICKEL-CADMIUM

RECHARGEABLE BATTERIES. See Battery Removal instruction

sheet

for battery disposal information

ENGLISH 5

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 5 (Black plate)

ENGLISH6

60 - DAY MONEY-BACK GUARANTEE

To enjoy the closest and most comfortable shave from your new Norelco Men’s

Razor, the razor should be used exclusivelyfor 3 weeks.This allows your hair

and skin enough time to adapt to the Norelco Shaving System. If, after that

period of time, you are not fully satisfied with your Norelco Men’s Razor, send

the product back and we’ll refund you the full purchase price.

The razor must be shipped prepaid by insured mail, insurance prepaid,

and have the sales slip, indicating purchase price and the date of

purchase, enclosed. The razor must be postmarked no later than 60 days

after the date of purchase. Norelco reserves the right to verify the purchase

price of the razor and limit refunds not to exceed suggested retail price.

Send dated sales slip, your complete name and address as indicated

below, and the razor, prepaid to:

Norelco Consumer Products Company

A Division of Philips Electronics North America Corporation

450 North Medinah Road, Dock 16

Roselle, IL 60172-2329

Please allow 4-6 weeks for delivery of check. (Please Print)

Name_________________________________________________________

Address________________________________________________________

City___________________________________________________________

State_____Zip__________________________________________________

Daytime Telephone No. (____)_____________________________________

Email Address___________________________________________________

REASON FOR RETURNING:______________________________________

______________________________________________________________

AREA CODE

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 6 (Black plate)

Table of Contents

Features.........................................................8-9

Important .......................................................10

Charging..........................................................10

Recharging................................................10-11

Inserting The First Cartridge.....................11

Replacing Cartridges.............................11-12

Put It To The Test & Shaving Tips ........12-13

How To Shave With An

Electric Razor..........................................13-14

Cleaning....................................................15-18

Storing.............................................................18

Tip ....................................................................18

Accessories....................................................19

Assistance.......................................................20

Battery Removal...........................................20

Warranty.........................................................21

Spanish ............................................................22

ENGLISH 7

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 7 (Black plate)

ENGLISH8

How the Unique Norelco Lift and Cut®

Shaving System Makes Close Comfortable:

Groove channels beard

closer to cutting system Lifter raises hair Blade cuts hair which

then drops below skin level

Features

Nivea for Men

Shaving Lotion Applicator

Razor Head

Assembly

Indi

vidually Floating

Heads

Raz

or Head Release

Button

•

Hair

Chamber captures

shaven hair

Green Charging

Indicator Light

On/Off Button

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 8 (Black plate)

Automatic

Worldwide

Voltage 100V to

240V AC

Cleaning Brush

Rechargeable

Cordless - 8 hour

full charge for up

to 40 minutes of

cordless shave

time

Full 2-Year

Warranty

60-Day Money-

Back Guarantee

ENGLISH 9

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 9 (Black plate)

Important

C ◗Only use the power plug provided to charge

the razor.

◗The power plug transforms 100-240V AC to

12V DC.

◗An adaptor plug may be necessary for cord

usage in some foreign countries.Your new razor

will automatically convert internally to work on

100V to 240V AC systems.

Charging

◗Charging or recharging at temperatures below

40ºF or higher than 95ºF adversely affects

lifetime of batteries.

◗Battery performance is best if you recharge

only when batteries are (almost) completely

empty.

C1Connect the cord to razor. Plug the

charging plug into any 100V to 240V AC

outlet. Use only the charging plug

provided.

2First time charging and recharging after

non-use for 1 month or more requires a

full 8 hours.

C3The green LED charging indicator will light

up to indicate razor is (re)charging.

Recharging

◗After initial charge, recharging normally takes 8

hours.

ENGLISH10

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 10 (Black plate)

◗A fully charged razor has cordless shaving time

of up to approx. 40 minutes.

Inserting the First Cartridge

C1Take one lotion or gel cartridge.Take the

connector supplied and remove it from

the little bag. Push it into the plastic cap of

cartridge until it locks into position with a

click.

C2Push the release button on the back of

razor downwards and open the cover of

the cartridge compartment.

C3Slide the cartridge with the connector in

place into the razor. It only fits properly if

the white side of the connector is pointing

upwards. Close the cover.

4Press the applicator button a few times

until the Nivea for Men shaving lotion or

gel appears in the small hole located on

razor head assembly.The razor is now

ready for use.

Replacing Cartridges

C1Open back cover of razor.

2Remove empty cartridge, pull out and save

the connector. DO NOT discard the

connector.

ENGLISH 11

6711X_6701X DFU.rQXD 11/5/03 6:09 PM Page 11 (Black plate)
