Philips HQ9170 Manual de usuario

ENGLISH 4

POLSKI 23

РУССКИЙ 43

УКРАЇНСЬКА 64

EESTI 84

LATVIEŠU 101

LIETUVIŠKAI 120

139

ROMÂNĂ 158

ČEŠTINA 177

MAGYAR 196

SLOVENSKY 215

HRVATSKI 234

SLOVENŠČINA 253

БЪЛГАРСКИ 272

SRPSKI 293

HQ9190, HQ9171, HQ9170

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the powerplug supplied.

◗The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts.

◗The powerplug contains a transformer.

Do not cut off the powerplug to replace it

with another plug, as this will cause a

hazardous situation.

◗Do not use a damaged powerplug.

◗If the powerplug is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

C◗Make sure the powerplug does not get wet.

◗Charge and store the appliance at a

temperature between 5cC and 35cC.

C◗Never immerse the charging stand in water

nor rinse it under the tap.

◗Do not recharge the shaver in a closed pouch.

◗Always unplug the shaver before cleaning it

under the tap.

C◗The appliance complies with the

internationally approved IEC safety regulations

and can be safely cleaned under the tap.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

◗Noise level: Lc = 64 dB [A]

ENGLISH4

The display

C◗This appliance offers you the unique

possibility to choose the display layout you

prefer: a number layout or a battery symbol

layout.

1Press the on/off button approx. 3 seconds

to enter the menu.

The menu has three different modes: the travel

lock mode and two display layout modes.

C◗You will enter the menu in the travel lock

mode, indicated by a rotating key symbol.

You can scroll through the three modes (travel

lock, battery symbol layout and number layout) by

pressing the on/off button briefly in quick

succession.

2To select one of the two display layouts,

stop pressing the on/off button when the

layout you prefer appears on the display.

Wait a few seconds without pressing the on/off

button until you hear a beep.This beep indicates

that the display has been set to the selected

layout.

BNote: the first mode you enter after pressing the

on/off button for 3 seconds is the travel lock mode

(indicated by a rotating key symbol). If you do not

press the on/off button again within a few

seconds, the travel lock is activated and the

display will not switch to the first display layout

ENGLISH 5

mode.To deactivate the travel lock, press the

on/off button for 3 seconds again (see chapter

'Storage').

You can change the display layout at any time.

BNote: when you start using the appliance for the

first time or after a long period of disuse, it could

take several minutes before anything appears on

the display.

The display provides the following information:

Charging

C◗Number layout:

When the shaver is being charged, the display

shows the minutes indication and the plug symbol

with a blinking power symbol.

C◗Battery symbol layout:

When the shaver is being charged, the display

shows the battery symbol and the plug symbol

with a blinking power symbol.

Battery fully charged

C◗As soon as the battery has been fully charged,

the word 'FULL' runs across the display.

◗After a few hours the word 'FULL' stops

appearing.The display shows the minutes

indication and the plug symbol.

ENGLISH6

Battery running low

C◗Number layout:

When the battery is running low, the display

shows a blinking minutes indication and blinking

plug symbol when you switch the shaver off.

HQ9190 only: you will also hear a few short

beeps.

C◗Battery symbol layout:

When the battery is running low, the display

shows a blinking battery symbol and blinking plug

symbol when you switch the shaver off. HQ9190

only: you will also hear a few short beeps.

Battery empty

C◗To indicate that the battery voltage is too low

to operate the appliance, "LO" appears on the

display.

◗Recharge the battery. See chapter 'Charging'.

Cleaning shaver

C◗When the shaver is due to be cleaned, the tap

symbol with blinking water drops appears on

the display.

ENGLISH 7

Replacing shaving heads

C◗When the shaving heads need to be replaced

(every two years), the shaving unit symbol

starts blinking when you switch the shaver off.

HQ9190 only: at the same time you will hear

a beep.

- If you do not replace the shaving heads right

away, the shaving unit symbol remains visible

during the next 7 shaves.

- You can reset the appliance by pressing the

on/off button for 3 seconds while the shaving

unit symbol is blinking.The shaving unit symbol

then disappears. HQ9190 only: you will hear a

short confirming beep.

- If you have not reset the system after these

7 shaves, the system will automatically reset

itself.

Demonstration program

The appliance has a unique demonstration

program.

◗Press the on/off button for 6 seconds.

After 3 seconds the lock symbol appears; keep

the on/off button pressed.

The demonstration will start automatically. During

the demonstration the appliance will be

automatically switched on 2 times.You can

interrupt the demonstration by pressing the

on/off button.

ENGLISH8

Charging

Make sure the appliance is switched off before

you start charging it.

Charging normally takes approx. 1 hour.

You can also shave without charging by

connecting the shaver to the mains.

A fully charged shaver has a cordless shaving time

of up to 30 days.

Charging the appliance

C1Put the appliance plug in the shaver.

2Put the powerplug in the wall socket.

3Remove the powerplug from the wall

socket and pull the appliance plug out of

the shaver when the battery has been fully

charged.

Charging stand

◗You can also charge the appliance by placing it

in the charging stand.

C◗Place the shaver properly in the plugged-in

charging stand.

ENGLISH 9

C◗Lift the shaver from the stand without tilting

it.

Removing and inserting the clock

C1Turn the clock anticlockwise (1) ('click')

and pull it out (2).

C2Insert the clock (1) and turn it clockwise

(2) ('click').

Setting the time

C◗Set the time by pressing the small button at

the back of the clock.

The time can only be set forward.

ENGLISH10

Replacing the battery

C1Remove the cap.Then remove the battery

by means of a miniature screwdriver.

C2Insert a new battery and put the cap back

into place.

Using the appliance

Personal Comfort Control

C◗The Personal Comfort Control system allows

you to adapt the shaver to your skin type.

- You can set the shaver to 'Normal' for a fast

and comfortable close shave.

- You can set the shaver to 'Sensitive' for a

comfortable close shave with optimal skin

comfort.

C◗The 'S' position is best suited for sensitive

skin.

ENGLISH 11

C◗The 'N' position is best suited for normal

skin.

◗The in-between positions are suitable for skin

types between normal and sensitive.

C◗HQ9190 only: the display shows the position

selected.

Shaving

1Switch the shaver on by pressing the on/off

button once.

When you switch the shaver on or off, all lights

and symbols go on and then the remaining

battery capacity is shown for a few seconds.

C2Move the shaving heads quickly over your

skin, making both straight and circular

movements.

- Shaving on a dry face gives the best results.

- Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

3Switch the shaver off by pressing the on/off

button once.

C4Put the protection cap on the shaver every

time you have used it, to prevent damage.

ENGLISH12
