Philips HQ6423/16 Manual de usuario

ENGLISH 4

DEUTSCH 12

FRANÇAIS 20

NEDERLANDS 28

ESPAÑOL 36

ITALIANO 45

PORTUGUÊS 53

TÜRKÇE 61

HQ6423

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the mains cord supplied.

◗Do not use a damaged mains cord.

◗The appliance is equipped with an automatic

voltage selector and is suitable for mains

voltages ranging from 100 to 240 volts.

◗If the mains cord is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

C◗Keep the appliance and the mains cord dry.

◗Store and use the appliance at a temperature

between 5cC and 35cC.

Using the appliance

Shaving

C1Put the appliance plug in the shaver.

2Put the mains plug in the wall socket.

3Switch the shaver on by pushing the on/off

slide to position I.

C4Move the shaving heads quickly over your

skin, making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips system.

ENGLISH4

5Switch the shaver off by pushing the on/off

slide to position 0.

C6Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

C◗For easy and optimal cleaning, the Philips

Action Clean (shaving head cleaner, type

HQ100) is available.Ask your Philips dealer

for information.

The Philips Action Clean may not be available in

all countries. Contact the Customer Care Centre

in your country about the availability of this

accessory.

You can also clean the shaver in the following

way:

ENGLISH 5

Every week: shaving unit and hair chamber

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the top of the appliance first, using

the brush supplied.

C3Press the release button (1) and remove

the shaving unit (2).

C4Clean the inside of the shaving unit and the

hair chamber with the brush.

C5Put the shaving unit back onto the shaver.

Every two months: shaving heads

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button (1) and remove

the shaving unit (2).

ENGLISH6

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove and clean the shaving heads

(cutters and guards) one by one.

Do not mix up the cutters and the guards.

This is essential since each cutter has been

ground with its corresponding guard for optimal

performance. If you accidentally mix the sets up, it

could take several weeks before optimal shaving

performance is restored.

C5Clean the cutter with the short-bristled

side of the brush.

Brush carefully in the direction of the arrow.

C6Brush the guard.

C7Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit (1) and turn the wheel

clockwise (2).

8Put the shaving unit back onto the shaver.

For extra thorough cleaning, clean the shaving

heads by putting them in a degreasing liquid (e.g.

alcohol) every six months.To remove the shaving

ENGLISH 7

heads, follow steps 1 to 4 described above. After

cleaning, lubricate the central point on the inside

of the guards with a drop of sewing machine oil

to prevent wear of the shaving heads.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Storage

C◗Put the protection cap on the shaver to

prevent damage.

◗The appliance can be stored in the pouch

supplied.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

ENGLISH8

Replace damaged or worn shaving heads with

HQ55 Philips Super Reflex shaving heads only.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button (1) and remove

the shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove the shaving heads and place new

ones in the shaving unit.

C5Put the retaining frame back into the

shaving unit (1) and turn the wheel

clockwise (2).

6Put the shaving unit back onto the shaver.

Environment

C◗Do not throw the appliance away with the

normal household waste at the end of its life,

but hand it in at an official collection point for

recycling. By doing this you will help to

preserve the environment.

ENGLISH 9

Accessories

The following accessories are available:

- HQ55 Philips Super Reflex shaving heads.

- HQ100 Philips Action Clean (shaving head

cleaner).

- HQ101 Philips Action Clean refill (shaving head

cleaning liquid).

- HQ110 Philips shaving head cleaner (shaving

head cleaning spray). Not available in Canada.

Guarantee & service

If you need information or if you have a

problem, please visit the Philips Web site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

Troubleshooting

1Reduced shaving performance.

BCause 1: the shaving heads are dirty.

BThe shaver has not been cleaned well enough or

has not been cleaned for a long time.

◗Clean the shaver thoroughly before you

continue shaving. See chapter 'Cleaning and

maintenance'.

BCause 2: long hairs are obstructing the shaving

heads.

ENGLISH10

◗Clean the cutters and guards with the brush

supplied. See chapter 'Cleaning and

maintenance', section 'Every two months:

shaving heads'.

BCause 3: the shaving heads are damaged or worn.

◗Replace the shaving heads. See chapter

'Replacement'.

2The shaver does not work when the on/off

slide is pushed to position I.

BCause: the shaver is not connected to the mains.

◗Put the mains plug in the wall socket.

ENGLISH 11

Wichtig

Lesen Sie diese Bedienungsanleitung vor dem

ersten Gebrauch des Geräts gründlich durch und

bewahren Sie sie zur späteren Einsichtnahme auf.

◗Verwenden Sie ausschließlich das mitgelieferte

Netzkabel.

◗Verwenden Sie auf keinen Fall ein beschädigtes

Netzkabel.

◗Das Gerät hat eine automatische

Spannungsanpassung und eignet sich für

Netzspannungen von 100 bis 240 Volt.

◗Wenn das Netzkabel defekt oder beschädigt

ist, darf es nur durch ein Original-Ersatzkabel

ausgetauscht werden, um Gefährdungen zu

vermeiden.

C◗Halten Sie das Gerät und das Netzkabel stets

trocken.

◗Verwenden Sie das Gerät nur bei

Temperaturen zwischen 5cC und 35cC.

Bewahren Sie es auch in diesem

Temperaturbereich auf.

Benutzung des Geräts

Rasieren

C1Stecken Sie den Gerätestecker in den

Rasierer.

2Stecken Sie das Netzteil in die Steckdose.

3Schalten Sie den Rasierer ein, indem Sie

den Ein-/Ausschalter auf "1" schieben.

DEUTSCH12
