Philips HTS3531/12 Manual de usuario

TABLE OF CONTENTS

Page

Service Manual

. Mechanical and Dismantling Instructions…………........................3-1

. Software Upgrades ........................................................................4-1

. Trouble Shooting Chart……………………………………………….5-1

. Wiring Diagram………………………………………..………..….….6-1

. Electrical Diagrams and Print-layouts..….…………………....….…7-1

. Set Mechanical Exploded view & Part list.…………………..….….8-1

transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise

without the prior permission of Philips.

CLASS 1

LASER PRODUCT

PHILIPS

. DFU Instruction..............................................................................2-1

. Revision List..................................................................................9-1

. Technical Specifications…………....………………………..............1-

. Safety Instruction, Warning & Notes….……………………....….....1-

. Location of PCB Boards&Version Variation&Repair Scenario Matrix..........1-2

Published by RY&LLL - 1147 BU AVM Printed in The Netherlands Subject to modification

3139 785 35843

Version 1.3

Service

. Change settings.......................................…………........................4-2

HTS3531/12/51/94/98/F7/55/78/93

Home Theater DVD Player

Version Variation

/12 /51 /94 /98 /F7 /55 /78 /93

Output Power- 300W X X X X X X X X

Voltage(220~240V~) X X X X

Voltage(110~240V~) X X X X

MP3 LINK X X X X X X X X

Repair Scenario Matrix

/12 /51 /94 /98 /F7 /55 /78 /93

Main Board B B C C C C C C

Front Control Board B B C C C C C C

Amplifier Board B B C C C C C C

Power Board B B C C C C C C

*Bd:Board Level Replacement

*C:Component Level Repair

Type/Versions

Features

Type/Versions

Board in used

HTS3531

Note

•Speciﬁcations and design are subject to change

without notice.

Region codes

The type plate on the back or bottom of the

home theater shows which regions it supports.

Media formats

•DVD-Video, DVD+R/+RW, DVD-R/-RW,

DVD+R/-R DL, CD-R/CD-RW, Audio CD,

Video CD/SVCD, Picture ﬁles, MP3 media,

WMA media, DivX media, USB storage

device

File formats

•Audio: .mp3, .wma

•Video: .avi, .divx, .mpg, .mpeg,

•Picture: .jpg, .jpeg

Country DVD

Europe, United Kingdom

Latin America

Australia, New Zealand

Russia, India

China

Asia Pacific, Taiwan, Korea

HTS3531/12/55/78:

Product Specifications:

1-3

Ampliﬁer

•Total output power: 300W RMS (30%

THD)

•Frequency response: 20 Hz-20 kHz / ±3 dB

•Signal-to-noise ratio: > 65 dB (CCIR) /

(A-weighted)

•Input sensitivity:

•AUX: 2 V

•Music iLink: 1 V

Video

•Signal system: PAL / NTSC

•HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p

Audio

•S/PDIF Digital audio input:

•Optical: TOSLINK

•Sampling frequency:

•MP3: 32 kHz, 44.1 kHz, 48 kHz

•WMA: 44.1 kHz, 48 kHz

•Constant bit rate:

•MP3: 32 kbps - 320 kbps

•WMA: 64 kbps - 192 kbps

Radio

•Tuning range:

•Europe/Russia/China: FM 87.5-108

MHz (50 kHz)

•Asia Paciﬁc/Latin America: FM 87.5-108

MHz (50/100 kHz)

•Signal-to-noise ratio: FM 50 dB

•Frequency response: FM 200 Hz-12.5 kHz

/ ±6 dB

USB

•Compatibility: Hi-Speed USB (2.0)

•Class support: USB Mass Storage Class

(MSC)

•File system: FAT16, FAT32

•Maximum memory support: < 160 GB

Main unit

•Power supply:

•Europe/China/Russia/India: 220-240V,

~50 Hz

•Latin America/Asia Paciﬁc: 110-240V

~50-60 Hz

•Power consumption: 55 W

•Standby power consumption: 0.9 W

•Dimensions (WxHxD): 360 x 58 x 325 mm

•Weight: 2.3 kg

Subwoofer

•Output power: 50 W RMS (30% THD)

•Impedance: 4 ohm

•Speaker drivers: 133 mm (5.25”) woofer

•Dimensions (WxHxD): 160 x 265 x 265 mm

•Weight: 2.5 kg

•Cable length: 3 m

Speakers

Center speaker:

•Output power: 50 W RMS (30% THD)

•System: 1 x 63.5 mm (2.5”) full range

•Speaker impedance: 4 ohm

•Speaker drivers: 1 x 63.5 mm (2.5”) woofer

•Dimensions (WxHxD): 159 x 84.5 x 80 mm

•Weight: 0.35 kg

•Cable length: 2 m

Front/Rear speaker:

•Output power: 4 x 50 W RMS (30% THD)

•Speaker impedance: 4 ohm

•Speaker drivers: 1 x 63.5 mm (2.5”) full range

•Dimensions (WxHxD): 84.5 x159 x 80mm

•Weight (front): 0.35 kg/each

•Weight (rear): 0.35 kg/each

•Cable length (front): 4 m

•Cable length (rear): 10 m

Remote control batteries

•2 x AAA-R03-1.5 V

Laser

•Type: Semiconductor laser GaAIAs (CD)

•Wave length: 645 - 665 nm (DVD), 770 -

800 nm (CD)

•Output power: 6 mW (DVD), 7 mW

(VCD/CD)

•Beam divergence: 60 degrees.

1-4

Ampliﬁer

•Total output power: 300W RMS (30%

THD)

•Frequency response: 20 Hz-20 kHz / ±3 dB

•Signal-to-noise ratio: > 65 dB (CCIR) /

(A-weighted)

•Input sensitivity:

•AUX: 2 V

•Music iLink: 1 V

Video

•Signal system: PAL / NTSC

•HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p

Audio

•S/PDIF Digital audio input:

•Optical: TOSLINK

•Sampling frequency:

•MP3: 32 kHz, 44.1 kHz, 48 kHz

•WMA: 44.1 kHz, 48 kHz

•Constant bit rate:

•MP3: 32 kbps - 320 kbps

•WMA: 64 kbps - 192 kbps

Radio

•Tuning range:

•Europe/Russia/China: FM 87.5-108

MHz (50 kHz)

•Asia Paciﬁc/Latin America: FM 87.5-108

MHz (50/100 kHz)

•Signal-to-noise ratio: FM 50 dB

•Frequency response: FM 200 Hz-12.5 kHz

/ ±6 dB

USB

•Compatibility: Hi-Speed USB (2.0)

•Class support: USB Mass Storage Class (MSC)

•File system: FAT16, FAT32

•Maximum memory support: < 160 GB

Note

•Speciﬁcations and design are subject to change

without notice.

Region codes

The type plate on the back or bottom of the

home theater shows which regions it supports.

Media formats

•DVD-Video, DVD+R/+RW, DVD-R/-RW,

DVD+R/-R DL, CD-R/CD-RW, Audio CD,

Video CD/SVCD, Picture ﬁles, MP3 media,

WMA media, DivX media, USB storage

device

File formats

•Audio: .mp3, .wma

•Video: .avi, .divx, .mpg, .mpeg,

•Picture: .jpg, .jpeg

Country DVD

Europe, United Kingdom

Latin America

Australia, New Zealand

Russia, India

China

Asia Pacific, Taiwan, Korea

1-5

HTS3531/51

Product Specifications:

Main unit

•Power supply:

•Europe/China/Russia/India: 220-240V,

~50 Hz

•Latin America/Asia Paciﬁc: 110-240V

~50-60 Hz

•Power consumption: 55 W

•Standby power consumption: 0.9 W

•Dimensions (WxHxD): 360 x 58 x 325 mm

•Weight: 2.3 kg

Subwoofer

•Output power: 50 W RMS (30% THD)

•Impedance: 4 ohm

•Speaker drivers: 133 mm (5.25”) woofer

•Dimensions (WxHxD): 160 x 265 x 265 mm

•Weight: 2.5 kg

•Cable length: 3 m

Speakers

Center speaker:

•Output power: 50 W RMS (30% THD)

•System: 1 x 63.5 mm (2.5”) full range

•Speaker impedance: 4 ohm

•Speaker drivers: 1 x 63.5 mm (2.5”) woofer

•Dimensions (WxHxD): 159 x 84.5 x 80 mm

•Weight: 0.35 kg

•Cable length: 2 m

Front/Rear speaker:

•Output power: 4 x 50 W RMS (30% THD)

•Speaker impedance: 4 ohm

•Speaker drivers: 1 x 63.5 mm (2.5”) full range

•Dimensions (WxHxD): 84.5 x159 x 80mm

•Weight (front): 0.35 kg/each

•Weight (rear): 0.35 kg/each

•Cable length (front): 4 m

•Cable length (rear): 10 m

Remote control batteries

•2 x AAA-R03-1.5 V

Laser

•Type: Semiconductor laser GaAIAs (CD)

•Wave length: 645 - 665 nm (DVD), 770 -

800 nm (CD)

•Output power: 6 mW (DVD), 7 mW

(VCD/CD)

•Beam divergence: 60 degrees.

1-6

Ampliﬁer

•Total output power: 300W RMS (30%

THD)

•Frequency response: 20 Hz-20 kHz / ±3 dB

•Signal-to-noise ratio: > 65 dB (CCIR) /

(A-weighted)

•Input sensitivity:

•AUX: 2 V

•Music iLink: 1 V

Video

•Signal system: PAL / NTSC

•HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p

Audio

•S/PDIF Digital audio input:

•Optical: TOSLINK

•Sampling frequency:

•MP3: 32 kHz, 44.1 kHz, 48 kHz

•WMA: 44.1 kHz, 48 kHz

•Constant bit rate:

•MP3: 32 kbps - 320 kbps

•WMA: 64 kbps - 192 kbps

Radio

•Tuning range:

•Europe/Russia/China: FM 87.5-108

MHz (50 kHz)

•Asia Paciﬁc/Latin America: FM 87.5-108

MHz (50/100 kHz)

•Signal-to-noise ratio: FM 50 dB

•Frequency response: FM 200 Hz-12.5 kHz

/ ±6 dB

USB

•Compatibility: Hi-Speed USB (2.0)

•Class support: USB Mass Storage Class

(MSC)

•File system: FAT16, FAT32

•Maximum memory support: < 160 GB

Note

•Speciﬁcations and design are subject to change

without notice.

Region codes

The type plate on the back or bottom of the

home theater shows which regions it supports.

Media formats

•DVD-Video, DVD+R/+RW, DVD-R/-RW,

DVD+R/-R DL, CD-R/CD-RW, Audio CD,

Video CD/SVCD, Picture ﬁles, MP3 media,

WMA media, DivX media, USB storage

device

File formats

•Audio: .mp3, .wma

•Video: .avi, .divx, .mpg, .mpeg,

•Picture: .jpg, .jpeg

Country DVD

Europe, United Kingdom

Latin America

Australia, New Zealand

Russia, India

China

Asia Pacific, Taiwan, Korea

1-7

HTS3531/94

Product Specifications:

Main unit

•Power supply:

•Europe/China/Russia/India: 220-240V,

~50 Hz

•Latin America/Asia Paciﬁc: 110-240V

~50-60 Hz

•Power consumption: 55 W

•Standby power consumption: 0.9 W

•Dimensions (WxHxD): 360 x 58 x 325 mm

•Weight: 2.3 kg

Subwoofer

•Output power: 50 W RMS (30% THD)

•Impedance: 4 ohm

•Speaker drivers: 133 mm (5.25”) woofer

•Dimensions (WxHxD): 160 x 265 x 265 mm

•Weight: 2.5 kg

•Cable length: 3 m

Speakers

Center speaker:

•Output power: 50 W RMS (30% THD)

•System: 1 x 63.5 mm (2.5”) full range

•Speaker impedance: 4 ohm

•Speaker drivers: 1 x 63.5 mm (2.5”) woofer

•Dimensions (WxHxD): 159 x 84.5 x 80 mm

•Weight: 0.35 kg

•Cable length: 2 m

Front/Rear speaker:

•Output power: 4 x 50 W RMS (30% THD)

•Speaker impedance: 4 ohm

•Speaker drivers: 1 x 63.5 mm (2.5”) full range

•Dimensions (WxHxD): 84.5 x159 x 80mm

•Weight (front): 0.35 kg/each

•Weight (rear): 0.35 kg/each

•Cable length (front): 4 m

•Cable length (rear): 10 m

Remote control batteries

•2 x AAA-R03-1.5 V

Laser

•Type: Semiconductor laser GaAIAs (CD)

•Wave length: 645 - 665 nm (DVD), 770 -

800 nm (CD)

•Output power: 6 mW (DVD), 7 mW

(VCD/CD)

•Beam divergence: 60 degrees.

1-8

Note

•Speciﬁcations and design are subject to change

without notice.

Region codes

The type plate on the back or bottom of the

home theater shows which regions it supports.

Media formats

•

DVD-Video, DVD+R/+RW, DVD-R/-RW,

DVD+R/-R DL, CD-R/CD-RW, Audio CD,

Video CD/SVCD, Picture ﬁles, MP3 media,

WMA media, DivX media, USB storage

device

File formats

•

Audio: .mp3, .wma

•

Video: .avi, .divx, .mpg, .mpeg,

•

Picture: .jpg, .jpeg

Country DVD

Europe, United Kingdom

Latin America

Australia, New Zealand

Russia, India

China

Asia Pacific, Taiwan, Korea

Ampliﬁer

•Total output power: 300W RMS (30%

THD)

•Frequency response: 20 Hz-20 kHz / ±3 dB

•Signal-to-noise ratio: > 65 dB (CCIR) /

(A-weighted)

•Input sensitivity:

•AUX: 2 V

•Music iLink: 1 V

Video

•Signal system: PAL / NTSC

•HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p

Audio

•S/PDIF Digital audio input:

•Optical: TOSLINK

•Sampling frequency:

•MP3: 32 kHz, 44.1 kHz, 48 kHz

•WMA: 44.1 kHz, 48 kHz

•Constant bit rate:

•MP3: 32 kbps - 320 kbps

•WMA: 64 kbps - 192 kbps

Radio

•Tuning range:

•Europe/Russia/China: FM 87.5-108

MHz (50 kHz)

•Asia Paciﬁc/Latin America: FM 87.5-108

MHz (50/100 kHz)

•Signal-to-noise ratio: FM 50 dB

•Frequency response: FM 200 Hz-12.5 kHz

/ ±6 dB

USB

•Compatibility: Hi-Speed USB (2.0)

•Class support: USB Mass Storage Class

(MSC)

•File system: FAT16, FAT32

•Maximum memory support: < 160 GB

1-9

HTS3531/98

Product Specifications:

Main unit

•

Power supply:

•

Europe/China/Russia/India: 220-240V,

~50 Hz

•

Latin America/Asia Paciﬁc: 110-240V

~50-60 Hz

•

Power consumption: 55 W

•

Standby power consumption: 0.9 W

•

Dimensions (WxHxD): 360 x 58 x 325 mm

•

Weight: 2.3 kg

Subwoofer

•

Output power: 50 W RMS (30% THD)

•

Impedance: 4 ohm

•

Speaker drivers: 133 mm (5.25”) woofer

•

Dimensions (WxHxD): 160 x 265 x 265 mm

•

Weight: 2.5 kg

•

Cable length: 3 m

Speakers

Center speaker:

•

Output power: 50 W RMS (30% THD)

•

System: 1 x 63.5 mm (2.5”) full range

•

Speaker impedance: 4 ohm

•

Speaker drivers: 1 x 63.5 mm (2.5”) woofer

•

Dimensions (WxHxD): 159 x 84.5 x 80 mm

•

Weight: 0.35 kg

•

Cable length: 2 m

Front/Rear speaker:

•

Output power: 4 x 50 W RMS (30% THD)

•

Speaker impedance: 4 ohm

•

Speaker drivers: 1 x 63.5 mm (2.5”) full range

•

Dimensions (WxHxD): 84.5 x159 x 80mm

•

Weight (front): 0.35 kg/each

•

Weight (rear): 0.35 kg/each

•

Cable length (front): 4 m

•

Cable length (rear): 10 m

Remote control batteries

•

2 x AAA-R03-1.5 V

Laser

•

Type: Semiconductor laser GaAIAs (CD)

•

Wave length: 645 - 665 nm (DVD), 770 -

800 nm (CD)

•

Output power: 6 mW (DVD), 7 mW

(VCD/CD)

•

Beam divergence: 60 degrees.

1-10

Otros manuales para HTS3531/12

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Reproductor de DVD de Philips

Philips

Philips DVP4050/78 Manual de usuario

Philips

Philips PD7030 Manual de usuario

Philips

Philips Karaoke DVP642K Manual de usuario

Philips

Philips DVP3826 Manual de usuario

Philips

Philips DVDR3440H/05 Manual de usuario

Philips

Philips DVD 960 Manual de usuario

Philips

Philips DVP3360/12 Manual de usuario

Philips

Philips DVP3015K/98 Manual de usuario

Philips

Philips DVP3140 Manual de usuario

Philips

Philips PD9016 Manual de usuario

Philips

Philips DVP3386K Manual de usuario

Philips

Philips DVP3388K/75 Manual de usuario

Philips

Philips DVP642/17X Manual de usuario

Philips

Philips DVP3015K/03 Manual de usuario

Philips

Philips DVD621AT Manual de usuario

Philips

Philips DVP3550KMX/78 Manual de usuario

Philips

Philips DVP3015K/55 Manual de usuario

Philips

Philips BDP2180K Manual de usuario

Philips

Philips DCP850 Manual de usuario

Philips

Philips SACD1000/001 Manual de usuario

Philips

Philips DVP3680/93 Manual de usuario

Philips

Philips DVDR3400 Manual de usuario

Philips

Philips DVP3258X Manual de usuario

Philips

Philips DVDR3355/02B Manual de usuario

Manuales populares de Reproductor de DVD de otras marcas

Sony

Sony DVP-F11 Manual de usuario

LENCO

LENCO DVP-740 X2 Manual de usuario

JVC

JVC XV-N650BEU Manual de usuario

Aiwa

Aiwa XD-DV370 Manual de usuario

MedeaWiz

MedeaWiz Sprite 4K DV-S4 Manual de usuario

Denon

Denon DVM-1805 - DVD Changer Manual de usuario

Toshiba

Toshiba SD-3815 Manual de usuario

Tevion

Tevion 44330 Manual de usuario

Samsung

Samsung DVD-HD860 Manual de usuario

Sylvania

Sylvania DP170SL8 Manual de usuario

Toshiba

Toshiba SD-P1200 Manual de usuario

JVC

JVC XV-D9000E Manual de usuario

Dolby Laboratories

Dolby Laboratories CP650 Manual de usuario

Denon

Denon DVD-5900 Manual de usuario

Sony

Sony DVP-SR201P Manual de usuario

Toshiba

Toshiba SD-V394SU Manual de usuario

Toshiba

Toshiba SD5300KC Manual de usuario

Impecca

Impecca DVHP-9109 Manual de usuario
