Philips SPH8628/12 Manual de usuario

SPH8608

SPH8628

www.philips.com/welcome

EN User manual

3EN

8 Settings 24

Select an on-screen language 24

Adjust brightness 24

Set time/date 25

Set SmartPower timer 26

Hibernate the PhotoAlbum 26

Set auto orientation 27

Slideshow setting 27

Unlock the touch panel 30

View information of the PhotoAlbum 31

Reset all settings to factory default 31

Reset all settings to factory default 32

9 Upgrade the PhotoAlbum 33

10 Product information 34

11 Frequently asked questions 36

12 Glossary 37

Contents

1 Important 4

Safety 4

Notice 4

Class II statement 5

Need help? 5

2 Your PhotoAlbum 6

Introduction 6

What’s in the box 6

Overview of your PhotoAlbum 7

3 Get started 8

Charge the built-in battery 8

Turn on the PhotoAlbum 9

Transfer your media 10

Quick menu 12

Know these keypad icons 12

4 Play 13

Display photos 13

5 Browse 15

Browse and manage albums and media 15

6 Clock 18

Display the clock 18

Clock menu 18

7 Event reminder 19

Create an event reminder 19

Edit an event reminder 20

View an event reminder 22

Contents

Notice

This product is in compliance with the essential

requirements and other relevant provisions

of Directives 2006/95/EC (Low Voltage),

2004/108/EC (EMC).

Respect copyrights

The making of unauthorized copies of copy-

protected material, including computer

programs, les, broadcasts and sound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

Recycling

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When you see the crossed-out wheel bin

symbol attached to a product, it means the

product is covered by the European Directive

2002/96/EC:

Never dispose of your product with other

household waste. Please inform yourself about

the local rules on the separate collection of

electrical and electronic products.The correct

disposal of your old product helps prevent

potentially negative consequences on the

environment and human health.

1 Important

Safety

Safety precautions and maintenance

• Never touch, push, rub or strike the screen

with hard objects as this may damage the

screen permanently.

• When the product is not used for long

periods, unplug it.

• Before you clean the screen, turn off

and unplug the power cord. Only clean

the screen with a soft, water-damp cloth.

Never use substances such as alcohol,

chemicals or household cleaners to clean

the product.

• Never place the product near naked

ames or other heat sources, including

direct sunlight.

• Never expose the product to rain or

water. Never place liquid containers, such

as vases, near the product.

• Never drop the product.When you drop

the product, it will be damaged.

• Ensure that you install and use services or

software only from trustworthy sources

free of virus or harmful software.

• This product is designed for indoor use

only.

• Only use the supplied power adaptor for

the product.

• The socket-outlet shall be installed

near the equipment and shall be easily

accessible.

North Europe Information (Nordic

Countries)

VARNING:

FÖRSÄKRA DIG OM ATT HUVUDBRYTARE

OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU

STÄLLER DIN UTRUSTNING PÅPLATS.

Placering/Ventilation

ADVARSEL:

SØRGVED PLACERINGEN FOR, AT

NETLEDNINGENS STIK OG STIKKONTAKT

ER NEMTTILGÆNGELIGE.

Paikka/Ilmankierto

VAROITUS:

SIJOITA LAITE SITEN, ETTÄVERKKOJOHTO

VOIDAAN TARVITTAESSA HELPOSTI

IRROTTAA PISTORASIASTA.

Plassering/Ventilasjon

ADVARSEL:

NÅR DETTE UTSTYRET PLASSERES, MÅ

DU PASSE PÅ AT KONTAKTENE FOR

STØMTILFØRSEL ER LETTE Å NÅ.

Class II statement

Class II equipment symbol:

This symbol indicates that this product has a

double insulation system.

Need help?

Please visit www.philips.com/welcome where

you can access a full set of supporting materials

such as user manual, the latest software updates

and answers to frequently asked questions.

Your product contains a built-in rechargeable

battery covered by the European Directive

2006/66/EC, which cannot be disposed of with

normal household waste.

To safeguard the functionality and safety of

your product, take your product to an ofcial

collection point or service center where a

professional can remove or replace the battery.

Please inform yourself about the local rules on

separate collection of batteries.The correct

disposal of batteries helps prevent potentially

negative consequences on the environment and

human health.

Caution

•RISK OF EXPLOSION IF BATTERY IS REPLACED BY

AN INCORRECTTYPE.

•DISPOSE OF USED BATTERIES ACCORDINGTO

THE INSTRUCTIONS.

•Never remove the built-in battery except for disposal

of the product.

Always bring your product to a professional to

remove the built-in battery.

• AC-DC power adaptor

• Quick start guide

Registeryour product and get support at

www.philips.com/welcome

PhotoAlbum

Quick Start Guide

2 Your

PhotoAlbum

Congratulations on your purchase, and

welcome to Philips! To fully benet from the

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

This is a Philips Digital PhotoAlbum with built-in

rechargeable battery.

With Philips Digital PhotoAlbum, you can use

the PhotoAlbum to:

• Display JPEG photos

• Create event reminders for special

cases

What’s in the box

• Philips Digital PhotoAlbum

• Charging dock

fLeft-right slider

•

Tap to skip left

•

Tap to skip right

gMini USB jack

hSD/MMC/MS/MS Pro card slot

• Press to turn on the PhotoAlbum

• Press and hold to turn off the

PhotoAlbum

• Press to switch modes (between

slideshow and clock/calendar; or,

between wave view and album view)

jCharging dock connector

kRESET

lKensington lock

Overview of your

PhotoAlbum

• Hold to go to the home screen

• Tap to return to the upper-level menu

bMENU

• Tap to access/exit the option menu

cZoom buttons

•

Tap to zoom in

Tap to switch modes (wave mode ->

album mode -> slideshow mode ->

zoom in twice -> zoom in 4 times)

•

Tap to zoom out

Tap to switch modes (wave mode

<- album mode <- slideshow mode

<- zoom out twice <- zoom out 4

times)

dUp-down slider

•

Tap to scroll up

•

Tap to scroll down

eOK

• Tap to play/pause slideshow

• Tap to conrm a selection

2Feed the cord through the cord channel.

3Connect the PhotoAlbum to the charging

dock.

4Connect the AC plug of the power cord to

a power supply socket.

»If the PhotoAlbum is powered off, the

LED indicators under the left-right

slider and the OK button blink during

the charging process.When the built-

in battery is fully charged, the LED

indicators stop blinking.

3 Get started

Caution

•Use the controls only as stated in this user manual.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

back of the apparatus.Write the numbers here:

Model No. __________________________

Serial No. ___________________________

Charge the built-in battery

Note

•Charge the built-in battery before using the

PhotoAlbum for the rst time. The fully charged built-in

battery lets you operate the PhotoAlbum for up to 1

hour.

Mode Charging time

On 3.5 hours

Off 6.5 hours

1Connect the DC plug of the supplied

power cord to the DC jack of the supplied

charging dock.

Turn on the PhotoAlbum

1When the PhotoAlbum is turned off and

connected to the power supply, press to

turn on the PhotoAlbum.

For the rst time you turn on the

PhotoAlbum:

• The screen prompts you to select a

language.

• Select a language, and then tap OK to

conrm.

• The screen prompts you to set time

and date.

Tip

•The lifespan of the battery varies with use.

•To maximize the lifespan of the battery, keep the

PhotoAlbum connected to the power supply socket.

Overview of the battery/status display

icons

The display indicates the approximate level of

the built-in battery and the power supply status

of the PhotoAlbum:

Icon Status

Battery level 0%~5%

Battery level 5%~20%

Battery level 20%~40%

Battery level 40%~60%

Battery level 60%~80%

Battery level 80%~100%

PhotoAlbum in charging

PhotoAlbum in dock, AC-

powered, not charging

Transfer your media

Transfer your media with a storage

device

Caution

•Do not disconnect the storage device from the

PhotoAlbum during media transfer.

The PhotoAlbum supports most types of the

following storage devices:

• Secure Digital (SD)

• Secure Digital High Capacity (SDHC)

• Multimedia Card (MMC)

• Multimedia Card Plus (MMC Plus)

• Memory Stick (MS)

• Memory Stick Pro (MS Pro) (with adaptor)

1Open the cover on the side of the

PhotoAlbum.

2Insert a storage device into the

PhotoAlbum.

»An option menu is displayed.

• Tap / / / to set time and

date, and then tap OK to conrm.

»The home screen is displayed.

Turn off the PhotoAlbum

Note

•You can only turn off the PhotoAlbum after all copy

and save actions are complete.

• To turn off the PhotoAlbum, press and

hold for about 2 seconds.

Otros manuales para SPH8628/12

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Marco de fotos digital de Philips

Philips

Philips SPH8408 Manual de usuario

Philips

Philips 8FF3WMI Guía de inicio rápido

Philips

Philips SPF1307 Manual de usuario

Philips

Philips SPF2307/77 Manual de usuario

Philips

Philips SPF1207/77 Manual de usuario

Philips

Philips 7FF1M4 Manual de usuario

Philips

Philips SPF2017 Manual de usuario

Philips

Philips SPF1027/93, SPF1027 SPF1017 Manual de usuario

Philips

Philips SPF3400C Manual de usuario

Philips

Philips SPF5208 Manual de usuario

Philips

Philips 10FF2CMI Guía de referencia

Philips

Philips Home Essentials SPF4480X/G7 Manual de usuario

Philips

Philips 9FF2M4 - annexe 2 Manual de usuario

Philips

Philips 7FF1WD Manual de usuario

Philips

Philips 7FF2FPAS Manual de usuario

Philips

Philips SPF3010C Manual de usuario

Philips

Philips 9FF2CME - annexe 2 Manual de usuario

Philips

Philips Home Essentials SPF3470X Manual de usuario

Philips

Philips 7FF2FPA Manual de usuario

Philips

Philips 7FF2FPA Manual de usuario

Philips

Philips 8FF2FPB Manual de usuario

Philips

Philips SPF4080P Manual de usuario

Philips

Philips SPF3400 Manual de usuario

Philips

Philips 7FF2FPAS Manual de usuario

Manuales populares de Marco de fotos digital de otras marcas

LENCO

LENCO DF-830 Manual de usuario

NIX

NIX Advance X10G Manual de usuario

Nextar

Nextar N7S-100 Manual de usuario

Sungale

Sungale TD350A Manual de usuario

texet

texet DPF-830 Instrucciones de montaje

Digital Spectrum

Digital Spectrum MemoryVue MV-1500 Manual de usuario

ViewSonic

ViewSonic VFM1042-52 Manual de usuario

YURAKU

YURAKU YUR.PHOTO 7B4C Manual de usuario

Denver

Denver PFF-710WHITE MK2 Manual de usuario

Pandigital

Pandigital PAN8000DWPCF1 Manual de usuario

Rekam

Rekam Deja View HD-850 Manual de usuario

Majestic

Majestic DF 918HD MP3 Manual de usuario

ViewSonic

ViewSonic DPF8-CAM Manual de usuario

Digital Foci

Digital Foci Image Moments IMT-063 Manual de usuario

Nokia

Nokia SU-4 Manual de usuario

Hama

Hama 118564 Manual de usuario

Sungale

Sungale CD352LD Manual de usuario

Kodak

Kodak W1020 - GUIA COMPLETO DO USUÁRIO FOR FIRMWARE VERSIONS EARLIER THAN... Manual de usuario
