Philips SE4301S/69 Manual de usuario

3%?)&5?%.BOOK0AGE&RIDAY$ECEMBER0-

5SERMANUAL

ΣΕ435_ΙΦΥ_ΕΝ.βοοκ Παγε 3 Φριδαψ, ∆εχεµβερ 16, 2005 1:15 ΠΜ

4 Important Information

4 For your safety

4 Installation requirements

4 Need Help?

5 What’s in the box?

6YourSE430

6 Overview of the handset

9 Overview of the base station

9 Main features of your SE430

11 Connect

12 Install

17 Call

21 Phonebook

25 Call log

27 SMS

34 Clock & Alarm

35 Personal Settings

39 Advanced Settings

45 Network Services

48 Troubleshooting

50 Information

51 Index

Contents

SE430_IFU_EN.book Page 3 Wednesday, September 20, 2006 2:14 PM

EN Important Information

For your safety

This equipment is not designed to make emergency calls in the event of a power failure. Alternative

arrangements should be made for access to emergency calls.

To avoid damage or malfunction:

- Do not allow the product to come into contact with liquid.

- Do not open it as you could be exposed to high voltages.

- Never use any battery type other than the one supplied.

- Do not expose the phone to excessive heat caused by heating equipment or direct sunlight.

- Do not drop your phone or allow objects to fall on your phone.

- Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these may harm the set.

- Active mobile phones in the vicinity may cause interference.

About operating and storage temperatures

- Operate in a place where temperature is always between 0 and 35º C (32 to 95º F).

- Store in a place where temperature is always between -20 and 45º C (-4 to 113º F).

- Battery life may be shortened in low temperature conditions.

Installation requirements

This product requires an electrical supply of 220-240 volts, alternating monophased power, excluding IT

installations defined in standard EN 60-950. In case of power failure, the communication can be lost.

The electrical network is classified as hazardous according to criteria in the standard EN 60-950. The only way

to power down this product is to unplug the power supply unit from the electrical outlet. Ensure the electrical

outlet is located close to the apparatus and is always easily accessible.

The voltage on the network is classified as TNV-3 (Telecommunication Network Voltages), as defined in the

standard EN 60-950.

Need Help?

For more information on troubleshooting and FAQs:

Troubleshooting:page 48

Online Help

www.p4c.philips.com

SE430_IFU_EN.book Page 4 Wednesday, September 20, 2006 2:14 PM

What’s in the box?

The following accessories are included with your SE430:

Power supply for

base station

Battery door

Line cord

User Guide Warranty card

The line adaptor may not be attached to the line cord. In this case, you have to connect the line

adaptor to the line cord first before plugging the line cord to the line socket.

In multihandset packs, you will find one or more additional handsets, chargers with power supply units

and additional rechargeable batteries.

Handset Base station

Quick Start

Guide

2 AAA

rechargeable

batteries

SE430_IFU_EN.book Page 5 Wednesday, September 20, 2006 2:14 PM

EN Your SE430

Overview of the handset

LCD Screen

Menu key/Left Soft key

Talk key

Keypad lock key

Up/Down Navigation keys

Earpiece

Right soft key/ Redial list

key/ Mute key

Hang-up key

Alphanumeric keypad

Case key/ Pause key/

Ringer off key

Intercom key

Loudspeaker key

Microphone

Event LED

SE430_IFU_EN.book Page 6 Wednesday, September 20, 2006 2:14 PM

Your SE430

Handset keys

Soft keys

Press To

mEnter the main menu from stand-by mode.

Select the function displayed on the handset screen directly above it.

>Go to redial list from stand-by mode.

Select the function displayed on the handset screen directly above it.

Activate mute function during a call.

rAnswer an incoming external or internal call.

Insert R for operator services when on the line.

Hang up a call.

Long press from menu browsing to return to stand-by mode, short press to return to

previous menu.

Long press in stand-by mode to switch off the handset, short press to switch on the handset

again.

Access call log from stand-by mode.

Scroll up a menu list or go to the previous phonebook or call log record.

Increase earpiece volume during a call.

Go to the previous character in editing mode.

Access phonebook from stand-by mode.

Scroll down a menu list or go to the next phonebook or call log record.

Decrease earpiece volume during a call.

Go to the next character in editing mode.

cInitiate an internal call.

vAnswer an incoming call in handsfree mode.

Activate and deactivate the loudspeaker* during a call.

Dial # in stand-by mode.

Long press to mute the ringer in stand-by mode.

Insert a pause in dialling mode.

Switch between upper and lower case in editing mode.

*Dial * in stand-by mode.

Long press to activate and deactivate keypad lock.

OK Short press to confirm your selection.

BACK Short press from menu browsing to return to the previous menu.

*WARNING Handsfree activation can suddenly increase the volume in the earpiece to a very high

level. Make sure the handset is not too close to your ear.

SE430_IFU_EN.book Page 7 Wednesday, September 20, 2006 2:14 PM

EN Your SE430

Display icons & symbols

In stand-by mode, several icons & symbols may be displayed on the handset.

The handset is registered and within range of the base station. It blinks when the handset is

out of range or is searching for a base.

Battery symbol indicating 3 different battery levels.

The ringer volume is set to zero.

There is an external or internal incoming call, a call is connected or a call is held.

When browsing phonebook list.

The loudspeaker is ON.

There is a missed call or missed call records are being reviewed.

Alarm clock is activated.

Blinks when new SMS or voicemail messages are received and not read yet. Steady when

there are received SMS messages in the SMS box.

SE430_IFU_EN.book Page 8 Wednesday, September 20, 2006 2:14 PM

Your SE430

Overview of the base station

Main features of your SE430

The following is an overview of the menu options that are available in your SE430. For detailed explanation of

the menu options, please refer to the corresponding sections in this User Guide.

Menu To Page

SMS Setup, write/read SMS, etc. 27

CLOCK & ALARM Set Date and time, Alarm and Alarm tone. 34

PHONEBOOK Add, edit and manage phonebook entries. 21

PERSONAL SET Set Handset tone, Handset name, Auto Pick-up/Hang-up,

Languages, Babysit mode and Backlight.

ADVANCED SET Set Recall time, Dial mode, Call barring, Baby call, Register/

Unregister handset, Change PIN, Reset phone, Auto prefix,

Country setting and Conference mode.

NET. SERVICE Set Call forwarding, Voice Mail, Call back and Caller ID. 45

Paging key

SIM card tray

SE430_IFU_EN.book Page 9 Wednesday, September 20, 2006 2:14 PM

EN Your SE430

Menu navigation

The basic steps of navigating through the menus and options are as follows:

Task Action Illustration

• Enter main menu/menu

options

Press mkey

• Go to a specific menu/option

• Confirm your selection

1) Press :key to scroll to your

desired menu/option

2) Select OK by pressing the key

directly below it (left soft key m)

In this example, the alarm is Off.

• To change your selection.

• To confirm your selection.

• Return to previous menu

level or stand-by screen

1) Press :to scroll to your desired

option

2) Select OK by pressing the key

directly below it (left soft key m )

3) Select BACK by pressing the key

directly below it (right soft key >)

PHILIPS



08-08 18:00

Main Menu

Clock & Alarm



Alarm



Off

213

SE430_IFU_EN.book Page 10 Wednesday, September 20, 2006 2:14 PM
