Philips CD2503S/05 Manual de usuario

CD250

CD255

SE250

SE255

Quick start guide

1Connect

2Install

3Enjoy

www.philips.com/welcome

What’s in the box

Base station

Handset Battery door

Base station with

answering machine

2 AAA rechargeable

batteries

Power supply Line cord*

User manual Guarantee Quick Start Guide

*You may find in the box the line adaptor delivered separately from the line cord. In this

case, you have to connect the line adaptor to the line cord first before

plugging the line cord to the line socket.

In multihandset packs, you will find one or more additional handsets, battery doors,

chargers with power supply units and additional rechargeable batteries.

WARNING: Always use the line cord, power supply and batteries that came with your

phone.

1Connect

Connect the base station

2Install

Insert rechargeable batteries and charge

1. Place the base station in a central location near the telephone line socket and

electricity socket.

2. Connect the line cord and the power cable to their corresponding connectors at the

back of the base station.

3. Connect the other end of the line cord and power cable to their respective sockets.

Insert batteries Charge handset for 24 hours

Configure your phone (if necessary)

1. Press oto display the current country selection.

2. Scroll nup and down to find your country.

3. Press oto confirm your selection.

(WAITING will be displayed while the default line settings and menu language for

the selected country are automatically configured.)

4. The product now goes to the DATE/TIME selection menu. Enter the current date

(DD/MM) and press oto confirm.

5. Enter the time (HH-MM) and press oto confirm.

3Enjoy

Make a call

Dial the number (maximum 24 digits) and press tor l.

Press tor lto take the line, and dial the number.

Answer a call

When the phone rings, press tor l.

End a call

To end a conversation, press h.

Adjust earpiece or speaker volume

During a call, press nto select from LEVEL 1 to LEVEL 5.

Set the ring melody

There are 10 ring melodies available on your handset.

1. Press min idle mode, scroll nto PERSONAL SET and press o.

2. Scroll nto HANDSET TONE and press o, then scroll nto RING TONES

and press o.

3. Scroll nto your desired melody to play the melody.

4. Press oto set the ring melody.

A validation tone is emitted and the screen returns to the previous menu.

Store a contact in the phonebook

1. Press min idle mode, scroll nto PHONEBOOK and press o, press oto

enter NEW ENTRY.

2. ENTER NAME is displayed on the screen.

3. Enter the name of the contact (maximum 12 characters) and press o.

4. ENTER NUMBER is displayed on the screen.

5. Enter the number (maximum 24 digits) and press o.

A validation tone is emitted.

Access phonebook

1. Press din idle mode and scroll nto browse the phonebook.

2. To view the details, press the o. Press cto display the remaining digits if the

entry is more than 12 digits.

Call from the phonebook

1. Press din idle mode.

2. Scroll nto a phonebook entry.

3. Press t.

• The call is initiated.

Listen to messages recorded on the answering machine (for CD255/SE255 only)

Press eon the base station to turn on the answering machine (the LED is turned on).

The outgoing message is played.

Press pon the base station to play phone messages (the first recorded message will

be played first).

Press fto skip the current message and play the next message.

Press bto go back to the previous message (if pressed within 1 second of current

message playback).

Press bto replay current message (if pressed after 1 second of current message

playback).

Press -+ to adjust speaker volume during message playback.

Press xto delete the current message.

Long press xto delete all old messages.

Press eagain to turn off the answering machine (the LED is turned off).

Refer to your User Manual for details about the answering machine functions.

Welcome to Philips!

www.philips.com/welcome

Need help?

User Manual

Refer to the User Manual that came with your phone.

Online Help

www.philips.com/support

Troubleshooting

For more information, please refer to the User Manual that came with your phone.

Problem

• There’s no dialling tone!

Solution

• No power: Check the connections.

• Batteries are empty: Charge the batteries.

• Move closer to the base station.

• Wrong line cord used: Use the line cord provided.

• Line adaptor may be required: If applicable, connect

the line adaptor to the line cord.

• Caller does not hear me

clearly!

• Move closer to the base station.

• Move the base station at least one metre away from

any electronic appliances.

•SEARCHING is

displayed on handset and

icon is blinking!

• Move closer to the base station.

• Make sure that your base station is on.

• Reset your unit and restart handset registration.

• Caller number is not

displayed!

• Service is not activated: Check your subscription

with your network operator.

3111 285 41351 (GB)

UCZZ69927AZ(1)

Reproduction in whole or in part is prohibited without

the written consent of the copyright owner
