KNX Timeclock Installation and Operation Manual
GB
3
GB
Philips LightMaster KNX Timeclock Installation and Operation Manual version 1.1
Specifications subject to change without notice.
Copyright © 2013 Global Systems, Philips Lighting, manufactured by WMGD Pty Ltd (ABN 33 097 246 921). All rights
reserved. Not to be reproduced without permission. LightMaster and associated logos are the registered trademarks
of WMGD Pty Ltd.
The KNX logo is a registered trademark of the KNX Association.
Contents
Connection/Installation 5
Basic safety instructions 5
Connect cable 7
Connections 8
Bus Connection 8
Programming individual address 8
Reset device 8
Operation of Display and keys 9
Menu selection overview 10
Initial start-up 12
Time switch programs and
astronomical programs 13
Program menu 14
Program switching times 14
Request/modify/delete switching times 15
Delete switching times 18
Program pulse time 19
Program cycle time 21
Standard and extra programs 22
Simulation menu 25
Time/Date menu 26
Manual menu 27
Manual and permanent switching 28
Options menu 28
Set astro programs 30
Enter PIN code 35
Memory card 36
4 5
GB
Connection/Installation
Basic safety instructions
WARNING: Danger of death through electric shock or fire!
•Installationshouldonlybecarriedoutbyaqualifiedelectrician
•Disconnectpowersource.
•Coverorshieldanyadjacentlivecomponents
•Ensuredevicecannotbeswitchedon
•Checkpowersupplyisdisconnected
•Earthandbypass
•ObserveSELVondatabus
6 7
GB
Connect cable
Strip cable by 8 mm (max. 9 mm).
Insert cable at 45° in the open terminal
(2 cables per terminal position possible).
Only with flexible wires:To open the
plug-in screwless terminal, press
screwdriver downwards.
Designated use
The time switch can be used for lighting, bell
systems, ventilation etc.
The device is designed for installation on DIN
top hat rails (in accordance with EN 60715)
and corresponds to type 1 STU in accordance
with IEC/EN 60730-2-7 resp. 60730-1.
The professional installation of bus lines and
commissioning of devices requires compliance
with the provisions of EN 50428 for switches
or similar installation equipment for use in
building construction technology.Tampering
with, or making modifications to, the device
invalidates the guarantee.
Disposal
Dispose of device and batteries separately in
an environmentally sound manner.
Plug-in
screwless
terminal
NC
contact
Plug-in terminal
Test tap
45° cable
8 9
GB
Connections
Bus Connection
Programming individual address
1. Press push button on front of device.
2. The programming LED lights up.
3. The device is now in program mode
Start-up, diagnostics, configuration and
application download are handled by ETS
(KNX tool software).
Reset device
1. Press the 4 keys simultaneously.
ENGLISH is displayed.
2. Select KEEP PROGRAM or
DELETE PROGRAM.
Weekday and
Date display
Channel status
ON = On
OFF = Off
Display of the active keys
with the relevant function
Programmed
switching times
Program display
Time display
Weekdays from
1 to 7
Astronomical
program display
Memory Card
Interface
MENU
– Activate screen
– Open menu
– Cancel menu
– ESC (1 step back)
OK
– Store selection
– Confirm selection
Display
options
MENU OK
N
L
Data
RC DCF
RC GPS
KNX
L N
Push button
Programming LED
KNX bus terminal
Program timeclock
1. Read text lines.
2. Make decision.
3. Yes – Confirmation,
Press OK.
4. No – Amend/Change,
Press
Operation of Display and keys
10 11
GB
Menu selection overview
PROGRAM
CHOOSE
CHANNEL C1
STANDARD
PROGRAM P0
EXTRA
PROGRAM
P1–P16
NEW
CHECK–MODIFY–
DELETE
DELETE
P0 ALL
END
SIMULATION TIME/DATE
MENU
CHOOSE
CHANNEL C1
TIME
START YEAR
2013
DATE
27 01 2013
START MONTH
SUMMER-
WINTER RULE
27 01 2013
START DAY
WEEKDAY
NUMBER
27 01 2013
SWITCHING TIME
FORM DATE
NEXT FORM TIME
EASTER RULE
END
OPTIONSMANUAL END
ASTROCHOOSE
CHANNEL C1
OPERATING
HOUR COUNTER
PERMANENT ON
LANGUAGEPERMANENT OFF
PINOVERRIDEON
LCD-
ILLUMINATION
TIMER SHORT
TERM CIRCUIT
FACTORY
SETTINGS
HOLIDAY
INFORANDOM
END
ACTIVATEEXTRA
PROGRAM
END
12 13
GB
Initial start-up
Set date, time and summer/winter time rule
Press required key and follow display on
screen (see figure).
Time switch programs and astronomical programs
With the 8-channel 365-day digital timeclock, time switch or astronomical programs can be
programmed and switched optionally for each channel.
TIME SWITCH PROGRAMS
• 1StandardprogramP0(Weeklyprogram
with switching times, pulse and cycle times)
• 16Extraprogramsconsistingof:
14 Extra programs P1–P14 (Weekly
programs with switching times, pulse and
cycle times with different adjustable date
ranges (fixed date range, date dependent
on Easter etc.), with extra program P15
(Fix ON) and extra program P16 (Fix OFF)
(with adjustable date ranges)
ASTRONOMICAL PROGRAMS
• 1AstrostandardprogramP0(withfixed
ON/OFF times, weekly program)
• 16Extraprogramsconsistingof:
14 Astro extra programs P1–P14 (with
fixed on/ off times, weekly program) with
different adjustable date ranges (fixed date
range etc.), with extra program P15 (Fix
ON) and extra program P16 (Fix Off)
(with adjustable date ranges)
The astro function can be activated instead of
the time switch function for each channel.
A channel can be defined as an astro channel in:
MENU > Options > Astro > Astro settings > choose channel > change to astro program.
ENGLISH
FORM DATE
SUMMER WINTER
EUROPE WEST
SUMMER WINTER
EUROPE EAST
SUMMER WINTER
CANADA
SUMMER WINTER
USA
SUMMER WINTER
NEW ZEALAND
OWN SUMMER-
WINTER RULE
NO SUMMER-
WINTER RULE
YEAR
2013
21 01 2013
MONTH
21 01 2013
DAY
FORM TIME
24 HOURS
SET HOUR
SET MINUTE
SUMMER WINTER
EUROPE
14 15
GB
Program menu
Program switching times
Example: Switch on sports hall lighting from Mon-Fri, 7:30 to 12:00 hrs
Program standard program P0 switching times.
1. Press MENU. PROGRAM is displayed.
2. Confirm by pressing OK.
CHOOSE CHANNEL is displayed.
3. Confirm CHANNEL 1 by pressing OK.
STANDARD PROGRAM P0 is displayed.
4. Confirm by pressing OK.
NEW is displayed.
5. Confirm by pressing OK.
SWITCH TIME is displayed.
6. Confirm by pressing OK.
Select ON (for switch-on times).
7. Confirm by pressing OK.
The display shows SET HOUR.
8. Use the or keys to enter hour,
minute, (07:30) and confirm
by pressing OK.
EVERYDAYisdisplayed.
Press to select MONDAY.
9. Confirm by pressing OK.
COPY is displayed.
10. Confirm by pressing OK.
ADD TUESDAY is displayed.
11. Confirm by pressing OK and also confirm
the days Wednesday,Thursday and Friday
by pressing OK.
12. Continue with toSAVEisdisplayed.
Confirm by pressing OK.
Repeat all steps for the switch-off time however instead of selecting ON with select OFF and
enter 12:00 for hour and minute.
PROGRAM
CHOOSE
CHANNEL
STANDARD
PROGRAM
EXTRA
PROGRAM 1
EXTRA
PROGRAM 2
DELETE
CHANNEL 1
ALL
NEW
SWITCH TIME PULSE CYCLE
MENU
ON
SET HOUR
SET MINUTE
EVERYDAY MONDAY TUESDAY
COPY SAVE
ADD TUESDAY
SAVE
SAVED
SAVED
ON 7.30
16 17
GB
Request/modify/delete switching times Request/change/delete standard program P0 switching times.
1. Press MENU.
PROGRAM is displayed.
2. Confirm by pressing OK.
3. Confirm CHANNEL 1 by pressing OK.
4. Confirm STANDARD PROGRAM P0
by pressing OK.
5. Use to select CHECK-MODIFY-
DELETE.
6. Confirm by pressing OK.
7. Confirm SWITCH TIME by pressing OK.
The first of the entered switching times is
displayed.
8. Confirm by pressing OK.
NEXT is displayed.
9. Press to select MODIFY
(or DELETE) to modify or delete
individual switching times.
10. Confirm by pressing OK.
The display shows CHANGE HOUR.
11. Use the or keys to enter hour and
minute and confirm by pressing OK.
PROGRAM
CHOOSE
CHANNEL
STANDARD
PROGRAM
MENU
MODIFY DELETE
CHANGE
HOUR
CHANGE
MINUTE
CHANGE
BLOCK
BLOCK
DELETE
DELETE
DELETED
DELETE
P0 ALL
CHECK-
MODIFY-
DELETE
NEW
SWITCH TIME
SWITCH TIME
MONDAY
NEXT
SWITCH TIME
TUESDAY
18 19
GB
Delete switching times
Delete all standard program P0 switching times.
1. Press MENU. PROGRAM is displayed.
2. Confirm by pressing OK.
3. Confirm CHANNEL 1 by pressing OK.
STANDARD PROGRAM P0 is displayed.
4. Confirm by pressing OK.
5. Use to select DELETE P0 ALL.
6. Confirm by pressing OK.
The display shows CONFIRM DELETE.
7. Confirm by pressing OK.
The display shows DELETED.
Program pulse time
PROGRAM
CHOOSE
CHANNEL
STANDARD
PROGRAM
DELETE
P0 ALL
CHECK-
MODIFY-
DELETE
MENU
CONFIRM
DELETE
DELETED
NEW
PROGRAM
CHOOSE
CHANNEL
STANDARD
PROGRAM
NEW
PULSESWITCH TIME CYCLE
MENU
ON
SET HOUR
SET MINUTES
SET SECONDS
PULSE LENGTH
IN MINUTES
PULSE LENGTH
IN SECONDS
EVERYDAY MONDAY
COPY
SAVE
ADD TUESDAY
SAVE
SAVE
SAVED
SAVED
SAVED
ON 8.05
Length 5 sec
