Philips AZ5140 Manual de usuario

User manual

Manual del usuario

Manual do usuário

VCD MP3 CD Soundmachine AZ5140

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 1

AZ 5140/98 page 2

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 2

AZ 5140/98 page 3

VIDEO

OUT

AUDIO

OUT

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 3

AZ 5140/98 page 4

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 4

INDEX

English

AZ 5140/98 page 5

中文 Español

Português

English

MP3 General Information..............6

Controls .........................................7

Remote Controls.........................7-8

Power Supply ...........................9-10

General Operation / Radio ..........10

CD/VCD/MP3-CD

...............................................11–17

Cassette recorder..................18–19

Maintenance ..........................19-20

Troubleshooting ...........................21

Español

Información General sobre MP3 .22

Controles .....................................23

Controles Remotos.................23-24

Suministro de Corriente.........25-25

Operación General / Radio..........26

CD / VCD / CD - MP3.............27-33

Grabadora de Cassettes.........34-35

Mantenimiento............................36

Detección y Corrección de Fallas....

.....................................................37

Portugu

MP3 Informação Geral ................38

Controlos .....................................39

Comando à Distância.............39-40

Abastecimento de Energia.....41-42

Funcionamento Geral/radiofónica 42

CD/VCD/MP3-CD ...................43-49

Gravador de Cassetes............50-51

Manutenção ................................52

Resolução de problemas.............53

中文

MP3 一般說明 ...........................54

控制鍵 ........................................55

遙控器 ...................................55-56

電源供給...............................57-58

一般操作 / 收音機....................58

CD/VCD/MP3-CD

...............................................59–65

磁帶錄音機..........................66–67

維護保養...............................67-68

故障排除 ....................................69

English

AZ 5140/98 page 6

MP3 General Information

Dear Customer,

Thank you for buying the Philips MP3-CD Soundmachine. Your great new acquisition will allow you to

listen to up to 10 hours of CD-like quality music, using the revolutionary new music compression

technology MP3.

MP3 technology

MP3 is short for MPEG1 Layer-3 encoding and decoding technology, a very powerful encoding

algorithm with which you can shrink down the orginal digital audio sound data with a factor of up to

10 without losing significant sound quality.

Recording and Playback

It is recommended to set your recording bit rate to 128kbps, sampling frequency at 44.1kHz

to achieve CD-like music playback quality.

Since downloading MP3 files from the Internet, ripping songs from your own legal CD’s and burning

MP3 songs onto a CD-R, are a delicate process, the quality of a MP3 song may vary by these process.

Subsequently, making a MP3-CD may not be entirely perfect.

As a result of the above imperfection, you may experience an occasional “skip” while

listening, or an occasional delay in accessing “previous/next” title to MP3-CD’s. This is

considered to be normal.

A comparison chart is enclosed as below:

Sound Bit Rate Approximate Approximate total Comment

Quality Reduction Ratio MP3-CD time

MW radio 32 kbps 40 : 1 40 hrs Sound quality significantly

FM radio 64 kbps 20 : 1 20 hrs affected-not recommended.

Near-CD 96 kbps 15 : 1 15 hrs Balanced sound quality

CD-like 128 kbps 10 : 1 10 hrs compression rate.

CD 256 kbps 5 : 1 5 hrs Compression rate low

CD 320 kbps 3 : 1 3 hrs suggest to play CDs instead.

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 6

English

AZ 5140/98 page 7

CONTROLS

1Source selector - power on/off switch and to

select source of sound source:

CD•VCD/MW/FM/TAPE.

2VOLUME - to adjust volume level.

3LIFT - OPEN - to open the CD door.

Cassette keys:

;- to interrupt recording or playback.

9/- to stop the tape and to open the cassette

holder.

5/ 6- to fast wind/rewind the tape.

1- to start playback.

0- to start recording.

52; - to start or interrupt CD playback.

9- to stop playback

∞/ §- to skip or search a passage or a track

6REPEAT - to repeat a track/programme/entire

CD playback

7TUNING - to tune to radio stations

iR - infrared sensor for remote control

9DBB (Dynamic Bass Boost) - for a more

vivid bass response.

0SHUFFLE - to play all tracks in random order

!LCD Display - to show the VCD, MP3 functions

and disc status.

Telescopic aerial - to improve FM radio

reception

VIDEO/AUDIO OUT - connect to the TV or

VCR VIDEO/AUDIO IN

$AC MAINS ~- socket for mains lead

%Battery door - to open the battery

compartment

Remote Control

. . . . . . . . . . . . . . . . . . . .1 pc

Mains Cord

. . . . . . . . . . . . . . . . . . . . . . .1 pc

Audio / Video Cable

. . . . . . . . . . . . . . . .1 pc

1OSD - to switch on/off the on screen display on

the TV screen.

2PBC (PLAYBACK CONTROL) - to switch on or

off PBC mode (for VCD version 2.0 only).

3DIGITS 0 - 9

for CD/VCD/MP3-CD - to select a

track number.

(numbers consisting more than 2 figures must

be keyed in within 2 seconds)

4RETURN - to return to the previous MENU level

during playback (for VCD with PBC on).

5RESUME - to resume playback in stop mode.

6STOP 9

- to stop playback or to clear a programme.

7ZOOM

for VCD only . . . . . . . to zoom in or zoom out

picture.

8GOTO - to start playback at any chosen time on

the disc (for CD/VCD operation only and PBC

mode is off).

REMOTE CONTROL

SUPPLIED ACCESSORIES

BACK PANEL

TOP AND FRONT PANEL

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 7

English

AZ 5140/98 page 8

REMOTE CONTROL

92;

- to start or interrupt playback.

∞§

for MP3-CD only . . . . to select previous/next

title.

for CD/VCD . . . . . . . . to search backward/

forward track.

ALBUM+

for MP3-CD only . . . . to select previous / next

album

05/ 6 (for CD/VCD/MP3-CD)

- to search back or forward.

!SHUFFLE - When in CD/VCD mode, press to

start or stop shuffle play mode (for VCD, only

available in PBC off mode)

@REPEAT

for MP3-CD to repeat a track, or

whole disc.

for CD/VCD . . . . . . . .to repeat a disc track or

the whole disc.

#A - B - to playback a certain scene or passage

repeatedly (for CD/VCD operation only).

$R/L/ST - to select channel left / channel right /

stereo sound, or to select a language in a

bilingual VCD.

%SLOW - to watch a VCD at a slower speed (for

VCD operation only).

^PROG

for CD/VCD/MP3-CD to programme disc

tracks.

&VIEW - to scan through a VCD with 9 pictures

display on TV screen.

*NTSC/PAL - to select the video output for

NTSC or PAL system.

(MIX/SEL - to select disc format (CD / MP3-CD)

in a mixed mode disc.

(

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 8

English

AZ 5140/98 page 9

POWER SUPPLY

IMPORTANT!

•For best CD/MP3-CD/VCD playback, please plug in your set to an AC power supply

where convenient.

•If operated in DC mode, see below approximate playtime. (Playtime is also varied from

different brand batteries) :

•The CD part of this system also serves as a Video CD player if you connect it to your

TV set.

•Before viewing the Video CD, ensure that the set is switched to corresponding PAL or

NTSC system of your TV set (exception Multi-system TV).

Whenever convenient, use the mains supply if you want to conserve battery life. The battery supply

will be switched off when the set is connected to the mains.

Make sure you remove the plug from the

set and wall outlet before inserting batteries.

Batteries

1. Open the battery compartment and insert six batteries, type

R14, UM2 or C-cells, (preferably alkaline) with the correct

polarity as indicated by the "+" and "-" symbols inside the

compartment.

Remote control

1. Open the battery door and insert two batteries,

type AAA, R03 or UM4 (preferably alkaline).

2. Replace the compartment door, making sure the batteries are

firmly and correctly in place.

3. Remove the batteries if they are exhausted or if they will not be used for a long period.

– The incorrect use of batteries can cause electrolyte leakage and will corrode the compartment

or cause the batteries to burst. Therefore:

–Do not mix battery types, e.g. alkaline with zinc carbonate.

–When inserting new batteries, replace all at the same time.

–Remove the batteries if the set is not to be used for a long time.

Note :

–The battery supply is switched off when the set is connected to the mains.

TV screen is disabled during CD / MP3-CD playing if your AZ5140 is battery

powered.

Batteries contain chemical substances, so they should be disposed of properly.

6 x 1.5V R14/ UM2/ C CELL

BATTERIES (NOT SUPPLIED)

Battery type Playtime

Alkaline approximate 9 hrs

Zinc Cartonate approximate 45 minutes

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 9

English

AZ 5140/98 page 10

GENERAL OPERATION

1. Check if the mains voltage as shown on the type plate (on

the bottom of the set) corresponds to your local mains

voltage. If it does not, consult your dealer or service

organization.

2. Connect the mains lead to the AC MAINS ~socket and the

wall socket.

™The set is now ready for use.

3. To switch off the mains supply completely, pull the mains plug out of the wall socket.

™Disconnect the mains lead when you change over to battery supply, or to protect the set

during heavy thunderstorms.

The type plate is located on the bottom of the set.

1. To switch on the set, adjust the source selector.

2. Adjust the sound using the VOLUME and DBB controls.

3To switch off the set, adjust the source selector to the

TAPE/OFF position, with the cassette keys released.

1Set the source selector to FM or MW.

2. Adjust the sound using the VOLUME controls and the DBB

switch.

3. Tune to a radio station using the TUNING knob.

–For FM, pull out the telescopic aerial. To improve FM-reception,

incline and turn the aerial. Reduce its length if the FM-signal is

too strong (very close to a transmitter).

–For MW, the set is provided with a built-in aerial, so the

telescopic aerial is not needed. Direct the aerial by turning

the whole set.

4. To switch off, set the source selector to the TAPE/OFF

position (with the cassette keys released).

RADIO RECEPTION

GENERAL OPERATION

MAINS

P001-021_AZ5140_98-Eng 3/11/05 9:50 Page 10

Otros manuales para AZ5140

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Reproductor de CD de Philips

Philips

Philips AZ7166 - Cd Portable Manual de usuario

Philips

Philips Jogproof AX5101 Manual de usuario

Philips

Philips Soundmachine AZB500/79 Manual de usuario

Philips

Philips CDC 752 Manual de usuario

Philips

Philips AZ6834 - Portable Radio Cass Rec Manual de usuario

Philips

Philips AZ 6801 Manual de usuario

Philips

Philips MBD3000/12 Manual de usuario

Philips

Philips AZ1027 Manual de usuario

Philips

Philips AZ 1110 Manual de usuario

Philips

Philips RD5050/18 Manual de usuario

Philips

Philips AZ1037/37 Manual de usuario

Philips

Philips AZ 1560 Manual de usuario

Philips

Philips AZ1835/37 Manual de funcionamiento

Philips

Philips AZ1025/00 Manual de usuario

Philips

Philips AZ 8049 Manual de usuario

Philips

Philips AZ7781 Manual de usuario

Philips

Philips CD 824 Manual de usuario

Philips

Philips AZ3830 Manual de usuario

Philips

Philips AX2500 Manual de usuario

Philips

Philips AZ6837/00 Manual de usuario

Philips

Philips CD723/20 Manual de usuario

Philips

Philips AZ5738/98 Manual de usuario

Philips

Philips AZ1826/79 Manual de usuario

Philips

Philips AZ1220 Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Sony

Sony MZ-R3 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Sony

Sony MZ-M10 Manual de usuario

Rotel

Rotel RCD 975 Manual de usuario

Pioneer

Pioneer CLD-D790 Manual de usuario

Optimus

Optimus CD-8250 Manual de usuario

Audiovox

Audiovox CE101A - annexe 1 Manual de usuario
