Philips AZ1080/00 Manual de usuario

AZ 1080

AZ 1081

CD Soundmachine Audio

Audio

AZ1080/00A 03/13/02 10:06 Page 1

English

Mains plug

This apparatus is ﬁtted with an approved

moulded 13 Amp plug.To change a fuse in this

type of plug proceed as follows:

1Remove fuse cover and fuse.

2Fix new fuse which should be a BS1362 5 Amp,

A.S.T.A. or BSI approved type.

3Reﬁt the fuse cover.

If the ﬁtted plug is not suitable for your socket

outlets, it should be cut off and an appropriate

plug ﬁtted in its place. If the mains plug contains

a fuse, this should have a value of 5 Amp. If a

plug without a fuse is used, the fuse at the

distribution board should not be greater than 5

Amp.

Note:The severed plug must be disposed to avoid

a possible shock hazard should it be inserted into

a 13 Amp socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured with

the following code: blue = neutral (N), brown =

live (L).

• As these colours may not correspond with the

colour markings identifying the terminals in your

plug, proceed as follows:

• Connect the blue wire to the terminal

marked N or coloured black.

• Connect the brown wire to the terminal

marked L or coloured red.

• Do not connect either wire to the earth

terminal in the plug, marked E (or e) or

coloured green (or green and yellow).

Before replacing the plug cover, make certain

that the cord grip is clamped over the sheath of

the lead - not simply over the two wires.

Recording and playback of material may require

consent. See Copyright Act 1956 and The

Performer’s Protection Acts 1958 to 1972.

Important notes for users in the U.K. Norge

Typeskilt ﬁnnes på apparatens underside.

Observer: Nettbryteren er sekundert

innkoplet. Den innebygde netdelen er

derfor ikke frakoplet nettet så lenge

apparatet er tilsluttet nettkontakten.

For å redusere faren for brann eller elektrisk

støt; skal apparatet ikke utsettes for regn eller

fuktighet.

Italia

DICHIARAZIONE DI CONFORMITA’

Si dichiara che l’apparecchio AZ 1080, AZ 1081

Philips risponde alle prescrizioni dell’art. 2

comma 1 del D. M. 28 Agosto 1995 n. 548.

Fatto a Eindhoven

Philips Consumer Electronics

Philips, Glaslaan 2,

5616 JB Eindhoven,The Netherlands

AZ1080/00A 03/13/02 10:06 Page 2

REPEAT

TAP

OFF

•

IC BASS

DBB

TUNING

CDTRACK

12 341 5

67 8 90! @

AZ1080/00A 03/13/02 10:06 Page 3

English

CAUTION: Use of controls or adjustments or performance of procedures other than

herein may result in hazardous radiation exposure or other unsafe operation.

This product complies with the radio interference requirements of the European Union.

ATTENTION: L’utilisation des commandes ou réglages ou le non-respect des procédures

ci-incluses peuvent se traduire par une exposition dangereuse à l’irradiation.

Ce matériel satisfait aux impératifs de brouillage radio de la Communauté Européenne.

ATENCIÓN: El uso de mandos o ajustes o la ejecucción de métodos que no sean los

aquí descritos puede ocasionar peligro de exposición a radiación.

Este aparato satisface las normas relativas a la interferencia radioeléctrica de la

Comunidad Europea.

ACHTUNG: Der Gebrauch von Bedienelemente oder Einstellungen bzw.

Verfahrensausführungen die hier nicht ausdrücklich erwähnt worden sind, kann eine

gefährliche Strahlendosierung oder andere unsichere Operationen zur Folge haben.

Dieses Produkt entspricht den Funkentstörvorschriften der Europäischen Union.

LET OP: Het gebruik van de toetsen en regelingen of het toepassen van de

aanwijzingen anders dan hier beschreven, kan leiden tot blootstelling aan gevaarlijke

straling of tot onveilige werking.

Dit apparaat voldoet aan de radio-ontstoringseisen van de Europese Unie.

ATTENZIONE: L'uso dei comandi o regolazioni o prestazioni delle procedure oltre a

quelle descritte nel presente potrebbero causare esposizione a radiazioni pericolose

o altre operazioni rischiose.

Questo prodotto è conforme ai requisiti delle interferenze radio della Unione Europea.

AVISO:A utilização de comandos ou ajustes ou a execução de procedimentos de

forma diferente daquela aqui indicada poderá resultar numa exposição perigosa a

radiações ou noutra operação arriscada.

Este produto obedece aos requisitos referentes a interferência de rádio estabelecidos

pela União Europeia.

ADVARSEL:Anvendelse af andre betjeningsanordninger eller justeringer eller

udførelse af andre procedurer end de heri angivne, kan medføre udsættelse for farlig

stråling eller andre risici.

Dette apparat overholder EU's krav vedrørende radiostøj.

VARNING: Om du använder knapparna på annat än här angivet sätt eller utför

andra justeringar eller förfaranden än de här angivna kan du utsättas för skadlig

strålning eller andra risker.

Denna apparat uppfyller EU:s krav beträffande radiostörningar.

MUISTUTUS: Muiden kuin tässä kuvattujen säätimien tai säätöjen tai

toimenpiteiden käyttö voi aiheuttaa vaarallisen altistuksen säteilylle tai muun

turvallisuutta vaarantavan seurauksen.

Tämä tuote on Euroopan unionin radiohäiriöitä koskevien vaatimusten mukainen.

OO: O ,      

          ,    

         .

T            

.

Caution

AZ1080/00A 03/13/02 10:06 Page 4

SvenskaSuomi

English_________________6

Français_______________14

Español _______________22

Deutsch_______________30

Nederlands____________38

Italiano _______________46

Português _____________54

Dansk ________________62

Svenska_______________70

Suomi ________________78

 _____________86

Index

English Français Español Deutsch Nederlands Italiano Português Dansk

AZ1080/00A 03/13/02 10:06 Page 5

Meet Philips at the Internet

http://www.philips.com

Printed in China

CLASS 1

LASER PRODUCT

AZ 1080

AZ 1081

English Français Español Deutsch Nederlands Italiano PortuguêsDansk

SvenskaSuomi

3140 115 2936.1

AZ1080/00B 03/13/02 10:09 Page 95

English

Top and front panels

1 LIFTTO OPEN – opens/ closes the CD

door

2 Source selector: CD,MW,FM,

TAPE/OFF

– selects CD source of sound, tuner

waveband or tape source of sound

– power on/ off switch

3 CASSETTE RECORDER:

PAUSE ;– pauses recording or playback

STOP•OPEN 9/ – stops the tape; opens

the cassette door

SEARCH 5or 6– fast rewinds / winds

the tape

PLAY 1– starts playback

RECORD 0– starts recording

4 CD display – shows the CD functions

5 TUNING

6 PLAY•PAUSE 2; – starts or pauses CD

playback

7STOP9– stops CD playback

8 SEARCH ∞,§

CD: skips or searches a passage/track

backwards or forward

9 DBB (Dynamic Bass Boost) –

enhances bass response

10 REPEAT – repeats a track/CD

11 SHUFFLE – plays all CD tracks in

random order

12 VOLUME – adjusts volume level

Back Panel

13 Telescopic aerial – to improve FM

reception

14 Battery door – open to insert 6 x 1.5V

R14/UM2/ C-cell batteries

15 AC MAINS – inlet for mains lead

Power Supply

Whenever convenient, use the power

supply if you want to conserve battery life.

Make sure you remove the plug from the

set and wall socket before inserting

batteries.

For users in the U.K.: please follow the

instructions on page 2.

Batteries (not included)

1Open the battery compartment and insert

six batteries, type R-14,UM-2 or C-cells,

(preferably alkaline) with the correct

polarity as indicated by the "+" and "–"

symbols inside the compartment.

2Close the compartment door, and make

sure the batteries are ﬁrmly and correctly in

place.The set is now ready to operate.

Batteries contain chemical substances,

so they should be disposed of properly.

Controls Power Supply

6 x 1.5V R14/ UM2/ C CELL

AZ1080/00A 03/13/02 10:06 Page 6

English

Incorrect use of batteries can cause

electrolyte leakage and will corrode the

compartment or cause the batteries to

burst.Therefore:

• Do not mix battery types: e.g. alkaline with

carbon zinc. Only use batteries of the same

type for the set.

• When inserting new batteries, do not try to

mix old batteries with the new ones.

• Remove the batteries if the set is not to be

used for a long time.

Using AC Mains

1 Check if the mains voltage, as shown on

the type plate located on the bottom

of the set, corresponds to your local

mains supply. If it does not, consult your

dealer or service centre.

2 Connect the mains lead to the AC MAINS

inlet and the wall socket.The mains supply is

now connected and ready for use.

3 To switch off completely, unplug the mains

lead from the wall socket.

• Unplug the mains lead from the wall socket

to protect your set during heavy

thunderstorms.

The type plate is located on the

bottom of the set.

Switching power on/off:

Save energy

Whether you are using mains or battery

supply, to avoid unnecessary energy

consumption always adjust the source

selector to TAPE/OFF and check if the

cassette keys are released.

General operation

1 To select your sound source adjust the

source selector to CD,MW,FM or

TAPE/OFF.

2 Adjust the sound with the VOLUME and

DBB (Dynamic Bass Boost) controls.

3To switch off the set, adjust the source

selector to TAPE/OFF position and check

the cassette keys are released.

Power Supply

REPEAT

TAP

OFF

•

IC BASS

DBB

TUNING

CDTRACK

AZ1080/00A 03/13/02 10:06 Page 7

English

Radio reception

1 Adjust the source selector to MW or FM

to select your desired waveband.

2 Tu r n TUNING to tune to a radio station.

To improve reception

– For FM, pull out the telescopic aerial. Incline

and turn the aerial. Reduce its length if the

signal is too strong (very close to a

transmitter).

– For MW the set is provided with a built-in

aerial so the telescopic aerial is not needed.

Direct the aerial by turning the whole set.

3To switch off the radio, adjust the source

selector to TAPE/OFF position and check

the cassette keys are released.

CD Player

Display indication for CD functions:

– --: ﬂashes when CD source just selected

– In stop mode: total track number

– During CD playback: 2and current

track number

REPEAT/ REPEAT ALL: when the

respective repeat mode is activated

– SHUFFLE when shufﬂe active

– Er: no disc/ error in CD operation or

with the CD/ CD-(R) is blank or the disc

is not ﬁnalised (seeTroubleshooting)

Playing a CD

1Adjust the source selector to CD.

2To open the CD door, lift the CD door at

the edge marked LIFTTO OPEN.

3Insert a CD or CD-(R) with the printed

side facing up and press the CD door gently

close.

4Press PLAY•PAUSE 2; on the set to

start playback.

5To pause playback press PLAY•PAUSE

2;.To resume, press PLAY•PAUSE 2;

again.

➜2ﬂashes during pause

6To stop CD play, press STOP 9.

7To switch off the set, adjust the source

selector to TAPE/OFF position and check

the cassette keys are released.

Note: CD play will also stop when:

– you open the CD compartment;

– you select MW,FM or TAPE sound

source;

– the CD has reached to the end.

Radio CD-Player

REPEAT

TAP

OFF

•

IC BASS

DBB

TUNING

CDTRACK

REPEAT

TAP

OFF

•

IC BASS

DBB

TUNING

CDTRACK

AZ1080/00A 03/13/02 10:06 Page 8

English

Selecting a different track

During playback you can use the

SEARCH buttons to select a particular

track.

• If you have selected a track number in the

stop or pause position, press

PLAY•PAUSE 2; to start playback.

• Press SEARCH §once brieﬂy for the

next track, or press repeatedly until the

desired track number appears in the display.

• Press SEARCH ∞once brieﬂy to return

to the beginning of a current track.

• Press SEARCH ∞more than once brieﬂy

for a previous track.

Finding a passage within a track

1During playback, press and hold down

SEARCH ∞or §.

• The CD is played at high speed and low

volume.

2When you recognize the passage you want

release the SEARCH button.

➜Normal playback resumes.

Note:When searching within a ﬁnal track and

you reach the end of the last track, the CD

goes to stop mode.

Play modes

REPEAT can be selected or changed

during playback in the following sequence:

REPEAT – plays the current track

continuously

REPEAT ALL – plays the entire CD

continuously

1During playback, press REPEAT once or

more until the desired REPEAT mode is

shown.

• You can use SEARCH ∞or §to skip

tracks during the repeat modes.

• The REPEAT play options can be

combined and used with shufﬂe: e.g.

REPEAT ALL SHUFFLE– repeats the

entire CD in random order.

2To return to normal playback press

REPEAT until the REPEAT modes are no

longer shown.

• You can also press STOP 9to quit the

play mode.

3During playback, press SHUFFLE once.

• All tracks are played in random order.

CD-Player

REPEAT

TAP

OFF

•

IC BASS

DBB

TUNING

CDTRACK

REPEAT

TAP

OFF

•

IC BASS

DBB

TUNING

CDTRACK

AZ1080/00A 03/13/02 10:06 Page 9

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Reproductor de CD de Philips

Philips

Philips AZ6822 - Portable Radio Cass Rec Instrucciones de montaje

Philips

Philips AZ7383 - Cd Personal Manual de usuario

Philips

Philips C.D.M.-1 Manual de usuario

Philips

Philips CD 502 Manual de usuario

Philips

Philips AZ9001 Manual de usuario

Philips

Philips AZ1307 - Portable Radio Cass Rec Manual de instrucciones

Philips

Philips 3CDC-LC-MP3CD2002 Instrucciones de funcionamiento e instalación

Philips

Philips AZ6060 Manual de instrucciones

Philips

Philips AZ 8240 Manual de usuario

Philips

Philips AZ7383 - Cd Personal Manual de usuario

Philips

Philips AZ 7594 Manual de usuario

Philips

Philips CDC775BK Manual de usuario

Philips

Philips AZ 8051 Guía del usuario

Philips

Philips AZ 7474 Manual de usuario

Philips

Philips AS680C Manual de usuario

Philips

Philips CDR785/00 Manual de usuario

Philips

Philips AZ7383 - Cd Personal Manual de usuario

Philips

Philips AZ8352/05 Manual de usuario

Philips

Philips EXP401/05 Manual de usuario

Philips

Philips AX5311 Manual de usuario

Philips

Philips AZ6830 Manual de usuario

Philips

Philips Expanium EXP 203 Manual de usuario

Philips

Philips AZ2538 Manual de usuario

Philips

Philips AZ7446/17Z Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Sony

Sony MZ-R3 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Sony

Sony MZ-M10 Manual de usuario

Rotel

Rotel RCD 975 Manual de usuario

Pioneer

Pioneer CLD-D790 Manual de usuario

Optimus

Optimus CD-8250 Manual de usuario

Audiovox

Audiovox CE101A - annexe 1 Manual de usuario
