Philips AX5003 Manual de usuario

Portable CD Player AX5002

AX5003

AX5004

PROGRAM

RESUME

ESP

PROGRAM

RESUME

ESP

DBB

PROGRAM

MODE

CD REWRITABLE COMPATIBLE

DIGITAL DYNAMIC BASS BOOST

BASS

ESP

45 SECOND ELECTRONIC SKIP PROTECTION

DIGITAL AUDIO

COMPACT

Ultra Quality /01 eng 22/11/00 9:43 Page 1

Es necesario que lea cuidadosamente su instructivo de manejo.

Descripción: Tocadiscos de CD portatil

Modelo: AX 5002/01, /11, /16, AX 5003/01, /11, /16,

AX 5004/01, /11, /16

Alimentación: 110–127/220–240 V~ 50–60 Hz

Consumo: 4 W (AY 3170)

Importador: Philips Mexicana, S.A. de C.V.

Domicilio: Norte 45, # 669, Col. Industrial Vallejo

Localidad y Telefono: C.P. 02300 México D.F., Tel. 5728 4200

Exportador: Philips Electronics Hong Kong, Ltd.

País de Origen: China

Nº de Serie: ______________________________

LEA CUIDADOSAMENTE ESTE INSTRUCTIVO

ANTES DE USAR SU APARATO.

No abrir, riesgo de choque eléctrico

Verifique que el voltaje de alimentación

sea el requerido para su aparato

ATENCIÓN

Para evitar el riesgo de choque eléctrico, no quite la tapa.

En caso de requerir servicio, dirijase al personal calificado.

PRECAUCIÓN - ADVERTENCIA

México

Ultra Quality /01 eng 22/11/00 9:43 Page 2

English

Ultra Quality /01 eng 22/11/00 9:43 Page 3

Ultra Quality /01 eng 22/11/00 9:43 Page 4

English

Controls .................................................6

Quick start .............................................7

Power supply...................................8–10

General information......................10–11

CD play..........................................12–13

Features.........................................14–18

In-car connection.................................19

Troubleshooting.............................20–21

Français

Commandes.........................................22

Mise en service rapide........................23

Alimentation électrique ................24–26

Informations générales.................26–27

Lecture CD.....................................28–29

Caractéristiques ............................30–34

Raccordement en voiture ....................35

Pannes et remèdes .......................36–37

Español

Controles .............................................38

Encendido rápido.................................39

Alimentación eléctrica..................40–42

Información general......................42–43

Reproducción de un CD.................44–45

Características ..............................46–50

Conexión al automóvil.........................51

Localización de averías.................52–53

Français

Español

∑

Guarantees

Polizia de garantía

Mexico.........................................70–71

Philips product warranty for

Australia......................................72–73

Guarantee and service for

New Zealand ....................................74

∑

Controls ...............................................54

Quick start ...........................................55

Power supply.................................56–58

General information......................58–59

CD play..........................................60–61

Features.........................................62–66

In-car connection.................................67

Troubleshooting.............................68–69

Ultra Quality /01 eng 22/11/00 9:43 Page 5

CONTROLS, refer to the illustration on page 3

1OPEN 2...........opens the CD lid

22;...................switches the player on, starts or pauses CD play

39.....................stops CD play, clears a program or switches the player off

4§....................skips and searches CD tracks forwards

5ESP..................ELECTRONIC SKIP PROTECTION ensures continuous CD playback

regardless of vibrations and shocks

6MODE..............selects the different playing possibilities: SHUFFLE,

SHUFFLE REPEAT ALL, REPEAT, REPEAT ALL and SCAN

7........................display

8PROGRAM.......programs tracks and reviews the program

9BASS...............switches the bass enhancement on and off. This button also

switches acoustic feedback (the beep) on/off when it is pressed for

more than 2 seconds

0∞....................skips and searches CD tracks backwards

!RESUME..........stores the last position of a CD track played

HOLD...............locks all buttons

OFF ..................switches RESUME and HOLD off

@LINE OUT/p....3.5 mm headphone socket, socket to connect the player to another

audio input of an additional appliance, remote control socket (not

on all versions)

#VOL E.........adjusts the volume

$4.5V DC...........socket for external power supply

%........................typeplate

^........................belt clip holder

Use only the Philips AY 3767 cord remote control with your CD-player. The buttons

on the remote control have the same functions as the corresponding buttons on

the CD-player.

1If necessary, press 9once or twice until the set is switched off,

2Firmly plug the remote control into the LINE OUT/psocket of the CD-player, and

then connect the headphones to the socket of the remote control.

3Turn the volume down with VOL F on the remote control and set VOL E on

the CD-player to position 8.

Remote control (not on all versions)

English

Ultra Quality /01 eng 22/11/00 9:43 Page 6

English

1OPEN 2

3CD 4 5

HOLD➟OFF

6PLAY 7VOLUME

!!!

LR6

UM3

2. 2.

QUICK START

This set complies with the radio interference requirements of the

European Community.

Ultra Quality /01 eng 22/11/00 9:43 Page 7

English

POWER SUPPLY

You can use the following batteries with this CD-player:

• normal batteries type LR6, UM3 or AA (preferably Philips), or

• alkaline batteries type LR6, UM3 or AA (preferably Philips).

Note: – Old and new or different types of batteries should not be used in

combination. Remove batteries if they are empty or if the player is

not going to be used for a long time.

Inserting batteries

1Push OPEN 2to open the CD lid.

2Open the battery compartment and insert either

2 normal or alkaline batteries, or the rechargeable

NiMH battery AY 3362 (if supplied).

Battery indication

The approximate power level of your batteries is shown in the display.

Battery full

Battery two-thirds full

Battery one-third full

Battery dead or empty. When the batteries are

dead or empty, the symbol A flashes, bAtt is

displayed, and the beep tone sounds repeatedly.

Average playing time of batteries under normal conditions

Battery type ESP on ESP off

Normal 7 hours 6 hours

Alkaline 22 hours 19 hours

Rechargeable ECO-PLUS NiMH battery 10 hours 9 hours

Batteries contain chemical substances, so they should be disposed

of properly.

Batteries (supplied or optionally available)

Ultra Quality /01 eng 22/11/00 9:43 Page 8

POWER SUPPLY

Recharging works only on players supplied with the rechargeable ECO-PLUS NiMH

battery AY 3362.

Recharging the ECO-PLUS NiMH battery on board

1Insert the rechargeable ECO-PLUS NiMH battery AY 3362.

2Connect the mains adapter to the 4.5V DC socket of

the player and then to the wall socket.

yAis shown and ChArGE is displayed for 5

seconds.

• Recharging stops after a maximum of 7 hours, or when you start playback.

3When the battery is fully recharged, and

FULL appear briefly in the display, before the

display switches off.

Notes: – It is normal for the batteries to become warm during recharging.

– If the batteries become too warm, recharging will be interrupted for

approximately 30 minutes and

Hot

is displayed.

– To ensure proper recharging on board, take care that contacts are clean.

– Use only the ECO-PLUS NiMH battery AY 3362.

Handling instructions

• Recharging already charged or half-charged batteries will shorten their lifetime.

We therefore recommend that you let the rechargeable ECO-PLUS NiMH battery

run till it is completely empty before you recharge it.

• To avoid a short circuit, do not let the battery touch any metal object.

• If the battery becomes empty soon after recharging, then either its contacts are

dirty or it has reached the end of its lifetime.

ECO-PLUS NiMH battery information (for versions supplied with

the rechargeable ECO-PLUS NiMH battery AY 3362)

English

Ultra Quality /01 eng 22/11/00 9:43 Page 9

POWER SUPPLY / GENERAL INFORMATION

Use only the AY 3170 adapter (4.5 V/300 mA direct

current, positive pole to the centre pin). Any other

product may damage the player.

1Make sure that the adapter’s voltage corresponds to

the local voltage.

2Connect the adapter to the 4.5V DC socket of the

player and to the wall socket.

Note: Always disconnect the adapter when you are not using it.

1To attach the belt clip to the CD-player, position the

shaped grip (found on the back of the belt clip) so that

it fits into the belt clip hole of the CD-player.

2Turn the clip to LOCK as indicated on the set.

3To detach, gently lift the belt clip and turn

to RELEASE as indicated on the set.

• All redundant packing material has been omitted. We have done our utmost to

make the packaging easily separable into two mono materials: cardboard (box) and

polyethylene (bags, protective foam sheet).

• Your set consists of materials which can be recycled if disassembled by a

specialized company. Please observe the local regulations regarding the disposal of

packing materials, exhausted batteries and old equipment.

Environmental information

LIFT LOCK

RELEASE

BELT CLIP

Belt Clip (not on all versions)

4.5

VDC

Mains adapter (supplied or optionally available)

English

Ultra Quality /01 eng 22/11/00 9:43 Page 10
