Philips AX2000 Manual de usuario
Portable CD player AX2000 AX2011
AX2001 AX5000
AX2002 AX5001
AX2003 AX5011
AX5013
PROGRAM MODE
DIGITAL DYNAMIC BASS BOOST
CD REWRITABLE COMPATIBLE
PROGRAM
RESUME
ESP
DBB
PROGRAM
RESUME
ESP
DBB
45 SECOND ELECTRONIC SKIP PROTECTION
DIGITAL AUDIO
COMPACT
Ultra perf/01 eng 22/11/00 9:41 Page 1
Es necesario que lea cuidadosamente su instructivo de manejo.
Descripción: Tocadiscos de CD portatil
Modelo: AX 2000/01, /11, /16, AX 2001/01, /11, /16,
AX 2002/01, /11, /16, AX 2003/01, /11, /16,
AX 2011/01, /11, /16, AX 5000/01, /11, /16
AX 5001/01, /11, /16, AX 5011/01, /11, /16
AX 5013/01, /11, /16
Alimentación: 110–127/220–240 V~ 50–60 Hz
Consumo: 4 W (AY 3170)
Importador: Philips Mexicana, S.A. de C.V.
Domicilio: Norte 45, # 669, Col. Industrial Vallejo
Localidad y Telefono: C.P. 02300 México D.F., Tel. 5728 4200
Exportador: Philips Electronics Hong Kong, Ltd.
País de Origen: China
Nº de Serie: ______________________________
LEA CUIDADOSAMENTE ESTE INSTRUCTIVO
ANTES DE USAR SU APARATO.
No abrir, riesgo de choque eléctrico
Verifique que el voltaje de alimentación
sea el requerido para su aparato
ATENCIÓN
Para evitar el riesgo de choque eléctrico, no quite la tapa.
En caso de requerir servicio, dirijase al personal calificado.
PRECAUCIÓN - ADVERTENCIA
México
Ultra perf/01 eng 22/11/00 9:41 Page 2
3
English
3
4
5
6
7
8
9
0
!
@
$
%
#
1
2
^
Ultra perf/01 eng 22/11/00 9:41 Page 3
4
Ultra perf/01 eng 22/11/00 9:41 Page 4
5
English
English
Controls .................................................6
Quick start .............................................7
Power supply...................................8–10
General information......................10–11
CD play..........................................12–13
Features.........................................14–18
In-car connection.................................19
Troubleshooting.............................20–21
Français
Commandes.........................................22
Mise en service rapide........................23
Alimentation électrique ................24–26
Informations générales.................26–27
Lecture CD.....................................28–29
Caractéristiques ............................30–34
Raccordement en voiture ....................35
Pannes et remèdes .......................36–37
Español
Controles .............................................38
Encendido rápido.................................39
Alimentación eléctrica..................40–42
Información general......................42–43
Reproducción de un CD.................44–45
Características ..............................46–50
Conexión al automóvil.........................51
Localización de averías.................52–53
Français
Español
∑
Guarantees
Polizia de garantía
Mexico.........................................70–71
Philips product warranty for
Australia......................................72–73
Guarantee and service for
New Zealand ....................................74
∑
Controls ...............................................54
Quick start ...........................................55
Power supply.................................56–58
General information......................58–59
CD play..........................................60–61
Features.........................................62–66
In-car connection.................................67
Troubleshooting.............................68–69
Ultra perf/01 eng 22/11/00 9:41 Page 5
CONTROLS, refer to the illustration on page 3
6
1OPEN 2...........opens the CD lid
22;...................switches the player on, starts or pauses CD play
39.....................stops CD play, clears a program or switches the player off
4§....................skips and searches CD tracks forwards
5ESP..................ELECTRONIC SKIP PROTECTION ensures continuous CD playback
regardless of vibrations and shocks
6MODE..............selects the different playing possibilities: SHUFFLE,
SHUFFLE REPEAT ALL, REPEAT, REPEAT ALL and SCAN
7........................display
8PROGRAM.......programs tracks and reviews the program
9BASS...............switches the bass enhancement on and off. This button also
switches acoustic feedback (the beep) on/off when it is pressed for
more than 2 seconds
0∞....................skips and searches CD tracks backwards
!RESUME..........stores the last position of a CD track played
HOLD...............locks all buttons
OFF ..................switches RESUME and HOLD off
@LINE OUT/p....3.5 mm headphone socket, socket to connect the player to another
audio input of an additional appliance, remote control socket (not
on all versions)
#VOL E.........adjusts the volume
$4.5V DC...........socket for external power supply
%........................typeplate
^........................belt clip holder
English
This set complies with the radio interference requirements of the
European Community.
Ultra perf/01 eng 22/11/00 9:41 Page 6
7
English
1OPEN 2
3CD 4 5
HOLD➟OFF
6PLAY 7VOLUME
!!!
AA
LR6
UM3
1.
2. 2.
1.
SS
QUICK START
Ultra perf/01 eng 22/11/00 9:41 Page 7
English
POWER SUPPLY
8
You can use the following batteries with this CD-player:
• normal batteries type LR6, UM3 or AA (preferably Philips), or
• alkaline batteries type LR6, UM3 or AA (preferably Philips).
Note: – Old and new or different types of batteries should not be used in
combination. Remove batteries if they are empty or if the player is
not going to be used for a long time.
Inserting batteries
1Push OPEN 2to open the CD lid.
2Open the battery compartment and insert either
2 normal or alkaline batteries, or the rechargeable
NiMH battery AY 3362 (if supplied).
Battery indication
The approximate power level of your batteries is shown in the display.
Battery full
Battery two-thirds full
Battery one-third full
Battery dead or empty. When the batteries are
dead or empty, the symbol A flashes, bAtt is
displayed, and the beep tone sounds repeatedly.
Average playing time of batteries under normal conditions
Battery type ESP on ESP off
Normal 7 hours 6 hours
Alkaline 22 hours 19 hours
Rechargeable ECO-PLUS NiMH battery 10 hours 9 hours
Batteries contain chemical substances, so they should be disposed
of properly.
Batteries (supplied or optionally available)
Ultra perf/01 eng 22/11/00 9:41 Page 8
POWER SUPPLY
9
Recharging works only on players supplied with the rechargeable ECO-PLUS NiMH
battery AY 3362.
Recharging the ECO-PLUS NiMH battery on board
1Insert the rechargeable ECO-PLUS NiMH battery AY 3362.
2Connect the mains adapter to the 4.5V DC socket of
the player and then to the wall socket.
yAis shown and ChArGE is displayed for 5
seconds.
• Recharging stops after a maximum of 7 hours, or when you start playback.
3When the battery is fully recharged, and
FULL appear briefly in the display, before the
display switches off.
Notes: – It is normal for the batteries to become warm during recharging.
– If the batteries become too warm, recharging will be interrupted for
approximately 30 minutes and
Hot
is displayed.
– To ensure proper recharging on board, take care that contacts are clean.
– Use only the ECO-PLUS NiMH battery AY 3362.
Handling instructions
• Recharging already charged or half-charged batteries will shorten their lifetime.
We therefore recommend that you let the rechargeable ECO-PLUS NiMH battery
run till it is completely empty before you recharge it.
• To avoid a short circuit, do not let the battery touch any metal object.
• If the battery becomes empty soon after recharging, then either its contacts are
dirty or it has reached the end of its lifetime.
ECO-PLUS NiMH battery information (for versions supplied with
the rechargeable ECO-PLUS NiMH battery AY 3362)
English
Ultra perf/01 eng 22/11/00 9:41 Page 9
POWER SUPPLY / GENERAL INFORMATION
10
Use only the AY 3170 adapter (4.5 V/300 mA direct
current, positive pole to the centre pin). Any other
product may damage the player.
1Make sure that the adapter’s voltage corresponds to
the local voltage.
2Connect the adapter to the 4.5V DC socket of the
player and to the wall socket.
Note: Always disconnect the adapter when you are not using it.
1To attach the belt clip to the CD-player, position the
shaped grip (found on the back of the belt clip) so that
it fits into the belt clip hole of the CD-player.
2Turn the clip to LOCK as indicated on the set.
3To detach, gently lift the belt clip and turn
to RELEASE as indicated on the set.
• All redundant packing material has been omitted. We have done our utmost to
make the packaging easily separable into two mono materials: cardboard (box) and
polyethylene (bags, protective foam sheet).
• Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the disposal of
packing materials, exhausted batteries and old equipment.
Environmental information
LIFT LOCK
RELEASE
BELT CLIP
Belt Clip (not on all versions)
4.5
VDC
Mains adapter (supplied or optionally available)
English
Ultra perf/01 eng 22/11/00 9:41 Page 10
