Register your product and get support at
www.philips.com/welcome
Ԛʹ˫ User manual 1
CED229/98
1
English
EN
Contents
1 Important 2
2 Your car audio system 3
Introduction 3
3 Play 4
Load and eject discs 4
Insert and remove USB device 4
Insert and remove SD/SDHC card 5
Skip/search 5
Intro play 6
Repeat play 6
Random play 6
Select Language 7
Dynamic Bass Boost 7
MAX sound 7
Zoom 8
4 Radio 9
Select tuner sensitivity 9
Manual tune to a radio station 9
Auto tune to a radio station 10
Store stations manually 10
Store stations automatically 10
Select the preset station 10
Select stereo or mono broadcasting 10
5 Play with RDS 12
Activate AF/TA/REG/CT functions 12
Search for an RDS station by PTY
information 12
6 System settings 14
Adjust general settings 14
Adjust AV-In setting 14
Select DVD video settings 14
Select language settings 15
Adjust radio settings 15
7 Other settings 16
Select equalizer settings 16
Control zone settings 16
Other sound settings 17
Select Video Output format 17
Turn on or off the screen backlight 18
Reset 18
Replace fuse 18
8 Product information 19
General 19
Disc player 19
Tuner 19
LCD 19
Compatible USB devices 19
Supported formats 19
Unsupported formats 20
9 Troubleshooting 21
10 Notice 22
2EN
1 Important
Read and understand all instructions
before you use the apparatus. If damage is
caused by failure to follow instructions, the
warranty does not apply.
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
This unit is designed for negative ground
(earth) 12 V DC operation only.
watch video during driving.
To ensure safe driving, adjust the volume to
a safe and comfortable level.
Improper fuses can cause damage or
consult a professional.
Use only the supplied mounting hardware
for a safe and secure installation.
To avoid short circuit, do not expose the
apparatus, remote control or remote
control batteries to rain or water.
Never insert objects into the ventilation
slots or other openings on the apparatus.
Never place any objects other than discs
into the disc tray/slot.
Visible and invisible laser radiation when
open. Avoid exposure to beam.
Risk of damage to the screen! Never touch,
push, rub or strike the screen with any
object.
Never use solvents such as benzene,
thinner, cleaners available commercially, or
anti-static sprays intended for discs.
Clean the apparatus with soft, damp cloth.
Never use substances such as alcohol,
chemicals or household cleaners on the
apparatus.
3
English
EN
2 Your car audio
system
Congratulations on your purchase, and
welcome to Philips!
Philips offers, register your product at
www.Philips.com/welcome.
Read this user manual carefully before you
install and use the unit. Save it for future
reference.
Introduction
your drive while you listen to:
Audio from a USB drive, a SD/SDHC card,
external devices.
Music CDs
DVD and VCD video
4EN
3 Play
Make sure that the disc or device contains
playable music or video.
Note
session is played.
Does not support MP3 Pro audio format.
It may not support and display special characters track
name (ID3) or album name properly.
Management (DRM).
that exceed the supporting limit.
Warning
video during driving.
Load and eject discs
1 Press to open the front panel.
2 Insert the disc into the disc slot with label
side facing up.
» Play resumes from the point where it
was last stopped.
3 To remove the disc, press the button.
»
unit switches to TUNER mode
automatically.
4 Close the front panel.
» After a few seconds, the screen
illuminates.
For video discs, press or to select
an item, then press to start playing.
JPEGs, press or to select a folder,
track or picture. Press to start playing.
Tip
If the disc is blocked in the disc compartment, press and
hold the button until the disc comes out.
Insert and remove USB
device
1 Slide down the USB socket cover.
5
English
EN
2 Insert the USB device into the USB socket.
» The unit starts playing from the USB
device automatically.
3 To remove the USB device, press to
turn off the unit.
4 Remove the USB device.
Insert and remove SD/SDHC
card
1 Press to open the front panel.
2 Insert SD or SDHC card into the card slot.
» The unit starts playing from the SD/
SDHC card automatically.
3 To remove the SD or SDHC card, press
to turn off the unit.
4 Press the card until you hear a click sound.
» The card is now disengaged.
Skip/search
During video and audio disc play
press the numeric buttons.
To skip to the previous or next chapter or
track, press or .
To search backward or forward quickly,
press or for 3 seconds.
Press to resume normal play.
6EN
During MP3/WMA play
twice to display the folder list. Press
or to select, and then press to
or within
the folder. Press
press the numeric buttons.
Intro play
audio track.
Press the button to enable and
disable this function.
Repeat play
There are 3 standard modes of repeat play for
Press the button repeated to select.
[REP ONE]: play the current chapter or
track repeatedly.
[REP DIR]: play the current folder
repeatedly.
[REP ALL]: play all chapters in the title or
all tracks repeatedly.
[REP CANCEL]: cancel repeat play.
Random play
There are 3 standard modes of random play for
Press the button repeatedly to select.
7
English
EN
[SHUFFLE ALL]: start random play for all
tracks.
[SHUFFLE DIR]: start random play in
current folder.
[SHUFFLE OFF]: cancel random play.
Select Language
Subtitle
You can select the subtitle language if the DVD
discs contain two or more subtitle languages.
During play, press on the remote
control repeatedly until the language is selected.
Audio
You can select the audio language if the video
discs contain two or more audio channels.
During play, press on the remote control
repeatedly until the language is selected.
Dynamic Bass Boost
1 Press / on the car audio
system for 3 seconds or press on the
remote control.
» [DBB ON]:The Dynamic Bass Boost
(DBB) function is on.
» [DBB OFF]:The DBB function is off.
2 Press again to change the DBB setting.
MAX sound
1 Press / to produce an
instant boost in bass and maximize volume.
2 Press / again to turn off.
8EN
Zoom
To zoom in and out of video images and
pictures:
1 Press on the remote control
repeatedly.
» [ZOOM] is displayed.
2 Press the navigation buttons to pan across
the display.
9
English
EN
4 Radio
Select tuner sensitivity
Before you start to search for radio station, you
can select tuner sensitivity.
1 Press .
» The main menu is displayed.
2 Press the navigation buttons to select
[SETTINGS], then press on remote
control or on the car audio to
3 Press or button to select .
4 Press to select [LOC_DX],
5 Press again to reach the [LOC_DX]
option list.
[LOC]: only broadcast local stations
with strong signals.
[DX]: broadcast any stations with
strong and weak signals.
6 Press or button to select [LOC]
or[DX] , then press on remote control
or
Manual tune to a radio
station
1 Press until you select radio.
2 Press and hold or to select band.
» [FM-1], [FM-2], [FM-3], [FM], [MW-1],
or [MW-2] is display.
