EN User manual

CAM101

English

Contents

1 Important 4

Safety 4

Notice 5

2 Your camcorder 6

Introduction 6

What’s in the box 6

Functional overview 7

3 Get started 8

Load the Micro SD card 8

Turn on 8

Set the date and time (for ﬁrst-time

users only) 9

Select a menu display language 9

Charge the built-in battery 9

4 Use your camcorder 10

Record video 10

Take pictures 10

Play 10

Options during video play 10

Adjust settings 11

5 Use more of your camcorder 11

View video or pictures on TV 11

Install and use the camcorder software 12

6 Technical speciﬁcations 13

7 Frequently asked questions (FAQ) 13

produce sounds in decibel ranges that

may cause hearing loss for a normal

person, even for exposure less than a

minute. The higher decibel ranges are

offered for those that may have already

experienced some hearing loss.

Sound can be deceiving. Over time your•

hearing ‘comfort level’ adapts to higher

volumes of sound. So after prolonged

listening, what sounds ‘normal’ can

actually be loud and harmful to your

hearing. To guard against this, set your

volume to a safe level before your hearing

adapts and leave it there.

To establish a safe volume level:

Set your volume control at a low setting.•

Slowly increase the sound until you can•

hear it comfortably and clearly, without

distortion.

Listen for reasonable periods of time:

Prolonged exposure to sound, even•

at normally ‘safe’ levels, can also cause

hearing loss.

Be sure to use your equipment•

reasonably and take appropriate breaks.

Be sure to observe the following guidelines

when using your headphones.

Listen at reasonable volumes for•

reasonable periods of time.

Be careful not to adjust the volume as•

your hearing adapts.

Do not turn up the volume so high that•

you can’t hear what’s around you.

You should use caution or temporarily•

discontinue use in potentially hazardous

situations. Do not use headphones while

operating a motorized vehicle, cycling,

skateboarding, etc.; it may create a trafﬁc

hazard and is illegal in many areas.

Any changes or modiﬁcations made to this

device that are not expressly approved by

Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

1 Important

Safety

aRead these instructions.

bKeep these instructions.

cHeed all warnings.

dFollow all instructions.

eDo not use this apparatus near water.

fClean only with dry cloth.

gDo not block any ventilation openings.

Install in accordance with the

manufacturer’s instructions.

hDo not install near any heat sources

such as radiators, heat registers, stoves,

or other apparatus (including ampliﬁers)

that produce heat.

iOnly use attachments/accessories

speciﬁed by the manufacturer.

jRefer all servicing to qualiﬁed service

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the apparatus,

the apparatus has been exposed to rain

or moisture, does not operate normally,

or has been dropped.

kApparatus shall not be exposed to

dripping or splashing.

lDo not place any sources of danger on

the apparatus (e.g. liquid ﬁlled objects,

lighted candles).

Hearing safety

Listen at a moderate volume.

Using headphones at a high volume can•

impair your hearing. This product can

Notice

This product complies with the radio

interference requirements of the European

Community.

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When this crossed-out wheeled bin symbol

is attached to a product it means that the

product is covered by the European Directive

2002/96/EC.

Please inform yourself about the local separate

collection system for electrical and electronic

products.

Please act according to your local rules and

do not dispose of your old products with your

normal household waste. Correct disposal of

your old product helps to prevent potential

negative consequences for the environment

and human health.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed with normal household

waste.Please inform yourself about the local

rules on separate collection of batteries

because correct disposal helps to prevent

negative consequences for the environmental

and human health.

Always bring your product to a professional to

remove the built-in battery.

English

2 Your camcorder

Introduction

With this portable camcorder, you can:

take full HD (1080P) or VGA movies•

take pictures•

play recorded movies or pictures either•

directly or on the large screen of a

connected TV

upload the recorded movies or pictures•

to the Internet directly

What’s in the box

Make sure that the following items are packed

in the box:

Camcorder•

AV cable•

Quick start guide•

Pouch•

Hand strap•

During video play, change the•

volume.

Perform the speciﬁc function as•

shown on the display panel.

dShutter button

In viewﬁnder mode, take a picture or•

start/stop video recording.

Functional overview

aBuilt-in speaker

bDisplay panel

c+/-

In viewﬁnder mode, zoom in/out.•

Navigate up/down in a menu.•

Change a value in the settings menu.•

English

3 Get started

Load the Micro SD card

1Flap open the protective cover on the

Micro SD card socket.

2Insert a Micro SD card (not supplied) into

the socket.

Ensure that the the Micro SD card is•

not write-protected.

Ensure that the metal contact of the•

card faces down.

3Close the protective cover securely.

Turn on

Press• .

For ﬁrst-time users, a menu for date»

and time setting appears (See ‘’Get

started - Set the date and time).

The camcorder switches to viewﬁnder»

mode.

To turn off the camcorder:

Press and hold• .

The backlight on the display panel»

turns off.

In play mode, switch to viewﬁnder•

mode.

In viewﬁnder mode, switch to play•

mode.

In play mode, play a selected video•

clip.

Conﬁrm settings.•

fMICRO SD

Connect a Micro SD card.•

Navigate left/right in a menu.•

Select a menu option.•

In play mode, turn to the previous/•

next picture/video clip.

In viewﬁnder mode, switch to the•

settings menu.

hUSB connector

Eject the USB connector.•

jTripod socket

kHand strap hole

l/AV OUT

Connect a headphone.•

Connect to a TV through an AV•

cable.

mHDMI

Connect to a TV through an HDMI•

cable with a mini HDMI connector.

Turn on/off the camcorder.•

oLens

pBuilt-in microphone

qMode switch button

Switch between picture and video•

recording modes.

Charge the built-in battery

1Press at the bottom of the camcorder

to eject the USB connector.

2Connect the USB connector to a USB

socket on a PC.

The status indicator on the shutter»

button starts ﬂashing in orange.

3Wait until the status indicator stops

ﬂashing and turns to green steadily.

The built-in battery is fully charged.»

Tip

The camcorder is fully charged for ﬁrst-time•

use.

It takes about 3 hours to fully charge the built-

•

in battery via the PC.

You can also charge the camcorder via a USB

adaptor (not supplied) connected to mains

power.The charge time is about 2 hours.

Tip

To save energy, the camcorder turns off•

automatically after being idle for 3 minutes.

Set the date and time

(for ﬁrst-time users only)

When you turn on the camcorder for the ﬁrst

time, a menu for date and time setting appears.

1Press to highlight [Yes].

A date setting menu appears.»

2Press / to select the day, month and

year ﬁelds successively.

3Press / to change the value of each

ﬁeld.

4Press to conﬁrm the date setting.

A time setting menu appears.»

5Press / to select the hour and minute

ﬁelds successively.

6Press / to change the value of each

ﬁeld.

7Press to conﬁrm the time setting.

The date and time setting is complete.»

The camcorder enters viewﬁnder»

mode.

Select a menu display language

1In viewﬁnder mode, press .

A settings menu appears.»

2Press /to highlight [Language].

3Press / to select a language.

4Press /to highlight [Resolution].

5Press /to select the resolution (HD,

full HD or standard).

6Press to conﬁrm the setting and

return to viewﬁnder mode.

English

Play

1In viewﬁnder mode, press to enter

play mode.

The last recorded video clip is played»

automatically.

2Press /to select a picture or video clip

for play.

3If the selected ﬁle is a video clip, press

to start play.

Delete a ﬁle

1In play mode, press / to select a ﬁle.

2Press to enter deletion mode.

3Press to highlight [Yes] and conﬁrm the

deletion operation.

»[Deleted!] appears brieﬂy.

Preview

In play mode, press• .

The thumbnails of 6 ﬁles are displayed»

on each page.

To select a ﬁle, press»/ / / .

Options during video play

Fast forward/reverse

During video play, press and hold• / .

To return to the normal speed, release• / .

Adjust volume level

During video play, press• / .

Listen through headphone

Plug a headphone into the• /AV OUT

socket on the camcorder.

4 Use your

camcorder

Record video

1Switch the mode switch button to .

The selected resolution and remaining»

recording time appear on the display

panel.

2Hold the camcorder steadily and aim the

lens as needed.

3Press the shutter button to start

recording.

A red time indicator appears on the»

display panel.

The status indicator on the shutter»

button starts ﬂashing in red.

4Press the shutter button again to end

recording.

»[Recording saved!] appears brieﬂy.

Take pictures

1Switch the mode switch button to .

The ﬁle size and remaining number of»

pictures that can be taken appear on

the display panel.

2Hold the camcorder steadily and aim the

lens as needed.

3Press the shutter button to take a picture.

»[Picture saved!] appears brieﬂy.

5 Use more of

your camcorder

View video or pictures on TV

1Connect the supplied AV cable to:

the• /AV OUT socket on the

camcorder

the component video and audio•

input sockets on the TV

2Select a ﬁle and start play.

To enjoy high-quality video/picture:

1Connect an HDMI cable (not supplied) to:

the• HDMI socket on the camcorder

(requiring a mini HDMI connector)

the HDMI input socket on an HDTV•

Adjust settings

1In viewﬁnder mode, press .

A settings menu appears.»

2Press /to highlight an option.

3Press / to select a setting.

4Press to conﬁrm the setting and

return to viewﬁnder mode.

Description

[Scene] Select an automatic exposure

mode that matches your shot

for easy shooting.

[Effects] Add a special effect to your

shooting.

[Resolution] Select a video resolution.

[Volume] Change the keypad tone and

operation sound.

[Date] Set the date.

[Time] Set the time.

[Auto

power]

Enable/disable automatic

power-off mode.

[Capture

sound]

Turn on/off the capture sound.

[Language] Select your desired menu

language.

[Pre-record] Enable/disable 3-second pre-

record mode.

[TV system] Change this setting if the

output video does not appear

correctly on your TV.

[Format] Clear contents from the micro

SD card or internal memory

(when no micro SD card is

inserted).

English

Otros manuales para CAM101BL/00

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Videocámara de Philips

Philips

Philips M 876 Manual de usuario

Philips

Philips Explorer M880 Manual de usuario

Philips

Philips Explorer VKR6847 Manual de usuario

Philips

Philips Explorer VKR6880 Manual de usuario

Philips

Philips CAM100PK Manual de usuario

Philips

Philips VKR6843 Manual de usuario

Philips

Philips CAM150 Manual de usuario

Philips

Philips Explorer M885 Manual de usuario

Philips

Philips M 660/21 Manual de usuario

Philips

Philips Explorer VKR6847 Manual de usuario

Philips

Philips CAM110BL Manual de usuario

Philips

Philips Explorer VKR6865 Manual de usuario

Philips

Philips CAM300BL Manual de usuario

Philips

Philips CAM100 Manual de usuario

Philips

Philips Explorer VKR6853 Manual de usuario

Philips

Philips CAM101BL/00 Manual de usuario

Philips

Philips Explorer M821 Manual de usuario

Philips

Philips VKR6853/21 Manual de usuario

Philips

Philips miniExplorer VKR9015 Manual de usuario

Philips

Philips Explorer M 875 Manual de usuario

Philips

Philips CAM300BL Manual de usuario

Philips

Philips M 826 Manual de usuario

Philips

Philips M 640/21 Manual de usuario

Philips

Philips CAM101BL/12 Manual de usuario

Manuales populares de Videocámara de otras marcas

Toshiba

Toshiba CAMILEO Z100 Manual de usuario

Panasonic

Panasonic NV-VS40B Manual de usuario

Canon

Canon RC 260 Manual de usuario

Sony

Sony Handycam DCR-DVD7E Manual de usuario

Brinno

Brinno TimeLapse TLC200 Manual de usuario

JVC

JVC GR-SXM68AC Guía de inicio rápido

Panasonic

Panasonic AG-HMC152EN Manual de usuario

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manual de usuario

MYDLINK

MYDLINK DCS-6100LH Manual de usuario

Sony

Sony video Hi8 Handycam CCD-TR555 Manual de usuario

SECURECOM

SECURECOM V-5014B Manual de usuario

Panasonic

Panasonic HDC-SD100 Manual de usuario

Sharper Image

Sharper Image U-VIDEO Manual de usuario

JVC

JVC AA-V15EG Manual de usuario

Canon

Canon LEGRIA HV40 Manual de usuario

Sony

Sony Handycam DCR-VX2000 Manual de usuario

RCA

RCA CC616 Manual de usuario

Panasonic

Panasonic NVM40 Manual de usuario
