Philips AC3259 Manual de usuario

1 2

G H I J K L M

EDC

4241 210 98081

AC3259

EN User manual 1 ZH-T 使用手冊 19

1EN

English

Contents

1 Important 2

Safety 2

2 Your air purier 5

Product overview (g.a) 5

Controls overview (g.b) 5

3 Getting started 5

Installing lters 5

Wi-Fi setup 6

4 Using the appliance 7

Understanding the air

quality light 7

Switching on and o 7

Changing the Auto mode

setting 7

Changing the fan speed 8

Setting the timer 8

Setting the child lock 8

Using the light on/o function 9

Switching the display mode 9

5 Cleaning 9

Cleaning schedule 9

Cleaning the body of the

appliance 9

Cleaning the air quality

sensor 10

Cleaning the pre-lter 10

6 Replacing the lter 11

Understanding the healthy

air protect lock 11

Replacing the lters 11

Filter type change 12

7 Troubleshooting 13

8 Guarantee and service 16

Order parts or accessories 16

9 Notices 16

Electromagnetic elds (EMF) 16

Recycling 17

Software 17

Environmental friendly paper used. Thanks for your contribution to save trees.

2EN

1 Important

Safety

Read this user manual carefully before

you use the appliance, and save it for

future reference.

Danger

• Do not let water or any

other liquid or flammable

detergent enter the

appliance to avoid electric

shock and/or a fire

hazard.

• Do not clean the

appliance with water,

any other liquid, or a

(flammable) detergent to

avoid electric shock and/

or a fire hazard.

• Do not spray any

flammable materials

such as insecticides or

fragrance around the

appliance.

Warning

• Check if the voltage

indicated on the

appliance corresponds to

the local power voltage

before you connect the

appliance.

• If the power cord is

damaged, you must have

it replaced by Philips, a

service center authorized

by Philips, or similarly

qualified persons in order

to avoid a hazard.

• Do not use the appliance

if the plug, the power

cord, or the appliance

itself is damaged.

• This appliance can be

used by children aged

from 8 years and above

and persons with reduced

physical, sensory or

mental capabilities or

lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the appliance in a safe

way and understand the

hazards involved. Child

shall not play with the

appliance. Cleaning and

maintenance shall not be

made by children without

supervision.

• Do not block the air inlet

and outlet, e.g. by placing

items on the air outlet or

in front of the air inlet.

3EN

English

• Make sure that foreign

objects do not fall into the

appliance through the air

outlet.

• Standard WiFi interface

based on 802.11b/g/n at

2.4 GHz with a maximum

output power of 31.62 mW

EIRP.

Caution

• This appliance is not

a substitute for proper

ventilation, regular

vacuum cleaning, or use

of an extractor hood or

fan while cooking.

• If the power socket used

to power the appliance

has poor connections,

the plug of the appliance

becomes hot. Make

sure that you plug the

appliance into a properly

connected power socket.

• Always place and use the

appliance on a dry, stable,

level, and horizontal

surface.

• Leave at least 20cm free

space behind and on both

sides of the appliance

and leave at least 30cm

free space above the

appliance.

• Do not place anything on

top of the appliance.

• Do not sit or stand on

the appliance. Sitting or

standing on the appliance

may lead to potential

injury.

• Do not place the

appliance directly below

an air conditioner to

prevent condensation

from dripping onto the

appliance.

• Make sure all filters

are properly installed

before you switch on the

appliance.

• Only use the original

Philips filters specially

intended for this

appliance. Do not use any

other filters.

• Combustion of the filter

may cause inreversible

human hazard and/or

jeopardize other lives . Do

not use the filter as fuel or

for similar purpose.

• Avoid knocking against

the appliance (the air inlet

and outlet in particular)

with hard objects.

4EN

• To prevent interference,

place the appliance at

least 2 meters away from

electrical appliances that

use airborne radio waves

such as TVs, radios, and

radio-controlled clocks.

• The appliance is only

intended for household

use under normal

operating conditions.

• Do not use the appliance

in wet surroundings or in

surroundings with high

ambient temperatures,

such as the bathroom,

toilet, or kitchen.

• The appliance does

not remove carbon

monoxide (CO) or radon

(Rn). It cannot be used

as a safety device in

case of accidents with

combustion processes

and hazardous chemicals.

• If you need to move the

appliance, disconnect the

appliance from the power

supply first.

• Do not move the

appliance by pulling its

power cord.

• Always lift or move the

appliance by the handle

on top of the appliance.

• Do not insert your fingers

or objects into the air

outlet or the air inlet to

prevent physical injury

or malfunctioning of the

appliance.

• Do not use this appliance

when you have used

indoor smoke-type insect

repellents or in places

with oily residues, burning

incense, or chemical

fumes.

• Do not use the appliance

near gas appliances,

heating devices or

fireplaces.

• Always unplug the

appliance after use

and before cleaning

or carrying out other

maintenance.

• Do not use the appliance

in a room with major

temperature changes,

as this may cause

condensation inside the

appliance.

5EN

English

3 Getting started

Installing lters

Note

• Make sure the air purifier is unplugged

from the electrical outlet before

installing the filters.

• Make sure the side of the filter with the

tag is pointing towards you.

1 Pull the bottom part of the front

panel to remove it from the

appliance (fig.c).

2 Press the two clips down and pull

the pre-filter towards you (fig.d).

3 Remove all filters (fig.e).

4 Remove all packaging materials of

the air purification filters (fig.f).

5 Put the unpacked air purification

filters back into the appliance

(fig.g).

6 Put the pre-filter back into the

appliance (fig.h).

Note

• Make sure that the side with the two

clips is pointing towards you, and that

all hooks of the pre-filter are properly

attached to the purifier.

7 To reattach the front panel, mount

the panel onto the top of the

appliance first (1). Then, gently push

the panel against the body of the

appliance (2) (fig.i).

8 Wash your hands thoroughly after

installing filters.

2 Your air purifier

Congratulations on your purchase, and

welcome to Philips!

To fully benefit from the support that

Philips offers, register your product at

www.philips.com/welcome.

Product overview (g.a)

AControl panel

BAir quality light

CAir quality sensors

DNanoProtect Pro S3 filter (FY3137)*

EPre-filter

FFront panel

Controls overview (g.b)

GOn/Off button

HLight on/off button

IAuto mode button

JDisplay screen

KFan speed button

LTimer button

MReset/Child lock button

6EN

Note

• This instruction is only valid when the

air purifier is being set up for the first

time. If the network has changed or the

setup needs to be performed again,

consult section “Setting up the Wi-Fi

connection when the network has

changed” on page 6.

• If you want to connect more than one

air purifier to your smart device, you

have to do this successively. Complete

the set up of one air purifier before you

turn on the other air purifier.

• Make sure that the distance between

your mobile device and the air

purifier is less than 10 m without any

obstructions.

• This app supports the latest versions of

Android and iOS. Please check

www.philips.com/purifier-compatibility

for the latest update of supported

operating systems and devices.

Setting up the Wi-Fi connection

when the network has changed

Note

• This applies when the default network

to which your purifier is connected has

changed.

1 Put the plug of the air purifier in the

power socket and touch to turn

on the air purifier.

2 Touch and simultaneously for

3 seconds until you hear a beep.

»The air purifier goes to pairing

mode.

»The Wi-Fi indicator blinks

orange.

3 Follow the steps 4-5 in "Setting up

the Wi-Fi connection for the first

time" section.

Wi-Fi setup

Setting up the Wi-Fi connection

for the rst time

1 Download and install the 'Air

Matters' app from the App Store or

Google Play.

2 Put the plug of the air purifier in the

power socket and touch to turn

on the air purifier.

»The Wi-Fi indicator blinks

orange for the first time.

3 Make sure that your mobile device

is successfully connected to your

Wi-Fi network.

4 Launch the 'Air Matters' app and

follow the onscreen instructions

to connect the air purifier to your

network.

5 After the successful pairing and

connection, the Wi-Fi indicator

will light up white. If pairing

is not successful, consult the

troubleshooting section, or the

help section in the 'Air Matters'

app for extensive and up-to-date

troubleshooting tips.

7EN

English

Note

• After the appliance is switched off by

the on/off button , if the plug is still

in the power socket, the appliance will

operate under the previous settings

when it is switched on again.

Changing the Auto mode

setting

You can choose the Pollution mode

( ), the Allergen mode ( ) and the

Bacteria/Virus mode ( ).

Pollution mode

The specially designed pollution

mode can effectively remove airborne

pollutants such as PM2.5.

• Touch the Auto mode button to

select the Pollution mode (fig.l).

»Auto(A) and display on the

screen.

Allergen mode

The specially designed Allergen mode

can effectively remove common

allergens such as pollen and pet dander.

• Touch the Auto mode button to

select the Allergen mode (fig.m).

»Auto(A) and display on the

screen.

4 Using the

appliance

Understanding the air

quality light

PM2.5

level

Air quality

light color

Air quality

level

≤12 Blue Good

13-35 Blue-Purple Fair

36-55 Purple-Red Poor

>55 Red Very poor

The air quality light automatically goes

on when the appliance is switched on,

and lights up all colors in sequence.

In a short time the air quality sensors

select the color that corresponds to the

ambient air quality.

Switching on and o

1 Put the plug of the appliance in the

power socket.

2 Touch to switch on the

appliance (fig.j).

»The appliance operates under

the auto mode by default.

»After measuring the air quality

for a short time, the air quality

sensor automatically selects the

color of the air quality light.

»After measuring the particle

matters in the air, the

icon and the PM2.5 level are

displayed on the screen. (fig.k).

3 Touch and hold for 3 seconds to

switch off the appliance.

8EN

Bacteria/Virus mode

The specially designed Bacteria & Virus

mode can effectively remove bacteria

& viruses such as staphylococcus albus

and H1N1.

• Touch the Auto mode button to

select the Bacteria & Virus mode

(fig.n).

»Auto(A) and display on the

screen.

Changing the fan speed

There are several fan speeds available.

You can choose the sleep mode ( ),

turbo mode( ) and speed 1, 2, or 3.

Sleep (SL)

In sleep mode, the appliance operates

quietly under speed 1. One minute into

the sleep mode, the power and light

on/off indicators are dimmed, and all

the other lights are off.

• Touch the fan speed button to

select the sleep mode ( ) (fig.o).

Manual

• Touch the fan speed button

repeatedly to select the fan speed

you need (fig.p).

Turbo (t)

In turbo mode, the appliance operates

under the highest speed.

• Touch the fan speed button to

select the turbo mode ( ) (fig.q).

Setting the timer

With the timer, you can let the

appliance operate for a set number of

hours. When the set time has elapsed,

the appliance will automatically switch

off.

• Touch the timer button

repeatedly to choose the number

of hours you want the appliance to

operate (fig.r).

»The timer is available from 1to

12 hours.

To deactivate the timer, touch the timer

button repeatedly until displays

on the screen.

Setting the child lock

1 Touch and hold the child lock

button for 3 seconds to activate

child lock (fig.s).

»displays on the screen.

»When the child lock is on,

all the other buttons are not

responsive.

2 Touch and hold the child lock

button for 3 seconds again to

deactivate child lock (fig.t).

»disappears from the screen.

Otros manuales para AC3259

Tabla de contenidos

Otros manuales de Purificador de aire de Philips

Philips

Philips AC1382 Manual de usuario

Philips

Philips AC4062 Manual de usuario

Philips

Philips HR4366/22 Manual de usuario

Philips

Philips AC1214 Manual de usuario

Philips

Philips AC4012 Manual de usuario

Philips

Philips AC2889/10 Manual de usuario

Philips

Philips AC1711/21 Manual de usuario

Philips

Philips UVCA110 Manual técnico

Philips

Philips AC2959/53 Manual de usuario

Philips

Philips AC4012 Manual de usuario

Philips

Philips GoPure GP3201 Manual de usuario

Philips

Philips AC4081/80 Manual de usuario

Philips

Philips AC0650 Manual de usuario

Philips

Philips 2000i Series Manual de usuario

Philips

Philips 4500i Series Manual de usuario

Philips

Philips AC1217/20 Manual de usuario

Philips

Philips AC0820 Manual de usuario

Philips

Philips AC3033 Manual de usuario

Philips

Philips AC3033/86 Manual de usuario

Philips

Philips AC1386 Manual de usuario

Philips

Philips AC4072/11 Manual de usuario

Philips

Philips AC2959/63 Manual de usuario

Philips

Philips AC1215/10 Manual de usuario

Philips

Philips AC4012 Manual de usuario

Manuales populares de Purificador de aire de otras marcas

IKEA

IKEA UPPÅTVIND Manual de usuario

Nash

Nash AP-1 PureSmart Manual de usuario

LG PH-U450 Series Manual de usuario

DeLonghi

DeLonghi DDSX 220WFA Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manual de usuario

Sharp

Sharp FU-40SE Manual de usuario

Hitachi

Hitachi EP-A3000 Manual de usuario

TruSens

TruSens Z-2000 Manual de usuario

Motorola

Motorola MBP87SN Manual de usuario

Beko

Beko ATP 7100I Manual de usuario

Carrier

Carrier INFINITY 1620 Manual de usuario

AtmosAir

AtmosAir P2002 Manual de usuario

Winix

Winix NK300 Manual de usuario

Friedrich

Friedrich C-90A Instrucciones de funcionamiento e instalación

Surgically Clean Air

Surgically Clean Air JADE2.0 Manual de usuario

Base aire

Base aire 555 Pro Manual de usuario

Champion

Champion CP25 Manual de usuario

vollara

vollara Air & Surface Pro+ Manual de usuario
