Philips SWW1890 Manual de usuario
Register your product and get support at
www.philips.com/welcome
EN User manual 3
ES Manual del usuario 21
FR Mode d’emploi 39
SWW1890
UYYAAWOA'0KPFF
UYYAAWOA'0KPFF
3
Contents
1 Important 4
Safety 4
2 Your PhilipsWireless HD Net Connect 6
What is in the box 6
3 Overview 7
The transmitter 7
The receiver 7
4 Installation 9
Connect the transmitter to your computer 9
Connect the receiver to the HDTV set 9
5 Activate your PhilipsWireless HD
Net Connect and set up the link 10
Turn on the power of your HDTV 10
Activate the wireless link 10
6 Mount your receiver 12
Mount your receiver on the wall 12
Mount your receiver on the back of the
HDTV 13
7 Technical data 14
Supported resolution 14
14
8 Notice 15
Notice for USA 15
Notice for Canada 15
Recycling 16
OneYear Limited Warranty 16
9 Frequently asked questions 17
EN
English
UYYAAWOA'0KPFF
4
Important Safety Instructions
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eDo not use this apparatus near water.
fClean only with dry cloth.
gDo not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
hDo not install near any heat sources such
as radiators, heat registers, stoves, or
produce heat.
iDo not defeat the safety purpose of
the polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong.The wide blade or the third prong
are provided for your safety. If the provided
an electrician for replacement of the
obsolete outlet.
jProtect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
k
by the manufacturer..
lUnplug this apparatus during lightning
storms or when unused for long periods of
time.
m
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
1 Important
Safety
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an electrical
shock.
The ‘exclamation mark’ calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
Warning
apparatus should not be exposed to rain or moisture
be placed on this apparatus.
Caution
To prevent electric shock, fully insert the plug. (For
regions with polarized plugs:To prevent electric shock,
EN
UYYAAWOA'0KPFF
5
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
nApparatus shall not be exposed to
dripping or splashing.
oDo not place any sources of danger on the
EN
English
UYYAAWOA'0KPFF
6
USB cable for the power supply of the
Power adapter for the receiver
Anchors x 2
Screws x 2
Adhesive tape x 2
Quick Installation Guide
Quick start guide
User manual
2 Your Philips
Wireless HD
Net Connect
Congratulations on your purchase and welcome
to Philips!
Philips offers, register your product at
www.philips.com/welcome.
What is in the box
Note
Make sure you have all these items in the box. Contact
your dealer for any missing or damaged items.
Transmitter
Receiver
EN
UYYAAWOA'0KPFF
7
The receiver
Top view
1 LED indicator Displays the status of the
receiver.
2 Power button
with LED
indicator
Press to turn the receiver
on/off or to standby
mode.
3INFO button Displays on the HDTV
the connection status of
the receiver.
Rear view
1DC IN
connector
Connect the power adapter
of the receiver.
2HDMI OUT
connector
Connect to the HDTV with
an HDMI cable
3 Overview
The transmitter
Front view
POWER
1 LED
indicator
Displays the connection status
of the transmitter.
2 USB
power
jack
Connect the transmitter to the
computer with the USB cable.
Top view
1INFO
button
Displays on the HDTV the
connection status of the
transmitter.
2 HDMI IN
connector
Plug into the HDMI port of
the computer.
EN
English
UYYAAWOA'0KPFF
8
The Philips Wireless HD Net Connect
gives you a total wireless solution to enjoy
the content from your computer on your
HDTV.The transmitter can transmit an
uncompressed video content up to 23feet
receive signals for viewing on your HDTV. All
you need to do is to:
Connect the transmitter to your computer.
Connect the receiver to your HDTV set.
EN
UYYAAWOA'0KPFF
9
3Connect the other end of the USB cable
to your the USB port of your computer.
Note
For some computers, the HDMI and USB ports are
located in different sides of the computer.
»The power LED indicator of the
into solid blue when the connection is
established.
Connect the receiver to the
HDTV set
HDMI
HDMI
1Connect the receiver with the supplied
HDMI cable:
Connect one end of the HDMI cable
to HDMI OUT connector of the
receiver.
Connect the other end of the HDMI
cable to the HDMI in connector of
your HDTV.
2Connect the power adapter to the
receiver with the supplied power adapter:
Connect one end of the power
adapter to the DC IN connector of
the receiver.
Connect the other end of the power
adapter to a power socket.
4 Installation
Connect the transmitter to
your computer
a
bc
Connect the transmitter to the computer using
the supplied USB cable.
1Connect the transmitter to the HDMI port
of the computer.
2Connect the small end of the USB cable to
the POWER jack of the transmitter;
EN
English
UYYAAWOA'0KPFF
10
On screen display on HDTV
On screen display Mode and status
Standby mode: it is a
power-saving mode
..... Start up in progress: It
takes 15-20 seconds.
x and .... Searching available
channels: It occurs
when the link cannot
establish over
80 seconds after
initialization.
HDMI CH1 On mode with
unrecognized video
format
HDMI CH1 On mode but
without input from
the computer/source
device
HDMI CH1 1080P On mode with
recognized video
format
Activate the wireless link
Switch on the transmitter and
receiver
When there is power supply for the transmitter
and receiver, they are on automatically.
»The link between the transmitter and
receiver is established..
5 Activate your
Philips Wireless
HD Net
Connect and set
up the link
Turn on the power of your
HDTV
HDMI
HDMI
1Go to the source menu under the settings
menu of your HDTV.
2Select the HDMI input to which the
receiver is connected.
EN
