Philips ACC2320 Manual de usuario
EN User manual 3
DE Benutzerhandbuch 11
FR Manuel de l‘utilisateur 19
ES Manual del usuario 27
IT Manuale di istruzioni 35
NL Gebruikershandleiding 43
3User manual
ENGLISH
1 Welcome
Congratulations on your purchase and welcome to Philips! Visit our website for comprehensive
support such as user manuals, software downloads, warranty information and much more:
www.philips.com/dictation.
1.1 Overview
Foot control ACC2310
with three pedals
Foot control ACC2320
with three pedals
Foot control ACC2330
with four pedals
4User manual
2 Important
2.1 Safety
• To avoid short circuit, do not expose the
product to rain or water.
• Do not expose the device to excessive
heat caused by heating equipment or direct
sunlight.
• Protect the cables from being pinched,
particularly at plugs and the point where they
exit from the device.
• Back up your files. The manufacturer is not
responsible for any loss of data.
2.2 Disposal of your old product
• Your product is designed and manufactured
with high quality materials and components,
that can be recycled and re-used.
• When this crossed-out wheeled bin
symbol is attached to a product, it
indicates that the product is covered
by the European Directive 2012/19/EU.
• Please become informed about the local
separate collection system for electrical and
electronic products.
• Please act according to your local rules and
do not dispose of old products with your
normal household waste. The correct disposal
of old products will help prevent potential
negative consequences for the environment
and human health.
5User manual
ENGLISH
2.3 Technical support and warranty
This product was designed and manufactured to
the highest quality standards. If your product is
not working correctly or is defective, contact
your supplying dealer who will provide you with
the necessary information on how to proceed.
If you have questions that your dealer cannot
answer or any other related question, visit
www.philips.com/dictation to contact us.
No components are user-serviceable. Do not
open or remove covers and do not insert
objects not suitable for the specific connectors.
Repairs may be made only by authorized service
centers and ocial repair facilities. Failure to do
so will void any warranty, stated or implied. Any
operation expressly prohibited in this manual,
any adjustments, or assembly procedures not
recommended or authorized in this manual will
void the warranty.
6User manual
3 Installation
Philips SpeechControl (Windows only)
1 Connect the foot control to a free USB port
on the PC.
2 Download Philips SpeechControl software
from the website www.dictation.philips.com/
speechcontrol onto your computer.
3 On a Windows computer, extract the
downloaded file.
4 Double-click the .exe file and follow the on-
screen instructions of the set-up program to
install the software.
DNote
Administrator rights are required to install
the software. For more help, contact your
administrator.
7User manual
ENGLISH
4 Use the foot control
4.1 Foot control ACC2310 / ACC2320
The foot control has three pedals: fast rewind
1, fast forward 2and playback 3.
32 1
2
1 3
ACC2310 ACC2320
1Press and hold the pedal for fast rewind.
When rewinding reaches the desired
position, release the pedal.
2Press and hold the pedal to fast forward.
When forwarding reaches the desired
position, release the pedal.
3The pedal starts playback. The behavior for
starting and stopping playback depends on
the setting of the playback switch on the
underside of the foot control:
• N (Neutral) position: Press and hold the
right pedal for playback. When the pedal
is released, playback is stopped.
• T (Toggle) position: Press and release the
right pedal to start continuous playback.
Press the right pedal again to stop playback.
8User manual
Model: ACC2330/00
S/N: 000000
KW: 540
Made in Hungary
NT
NT
4.2 Foot control ACC2330
The foot control has four pedals: a left 1, a
middle 2, a right 3and a top 4pedal.
2
4
1 3
1Press and hold the left pedal to fast forward.
When forwarding reaches the desired
position, release the pedal.
9User manual
ENGLISH
2Press and release the middle pedal to start
continuous playback. Press the middle pedal
again to stop playback.
3Press and hold the right pedal for fast
rewind. When rewinding reaches the desired
position, release the pedal.
4Press and release the top pedal to finish a
dictation.
ETip
If the middle pedal has been disabled with Philips
SpeechControl software (see next chapter), it
can be secured with the switch on the underside
of the foot control.
Model: ACC2330/00
S/N: 000000
KW: 540
Made in Hungary
10 User manual
5 Advanced configuration
Use the Philips SpeechControl software to
change the pedal functions of the foot control
(Windows only).
1 Connect the foot control to a free USB port
on the PC.
2 Start Philips SpeechControl software.
3 Change the function of the pedals according
to your preferences. 1
4 Click the Upload button 2to save the new
settings.
DNote
The foot control can be reset to its factory
default configuration by clicking the Defaults
button 3. Click the Upload button 2to save
the default settings.
1
2 3
