Philco PW 24 FD Manual de usuario

Wine cooler

OWNER’S MANUAL

PW 24 FD

Thank you very much for buying this product.

Before using your new refrigerator, please read this operation manual to ensure that you gain the

maximum benet from it.

EN - 1

CONTENTS

1. INDICATION OF PARTS ................................................................................................................................2

CONTROL PANEL ............................................................................................................................................................................... 2

2. TEMPERATURE CONTROL............................................................................................................................3

SETTING THE TEMPERATURE CONTROL...................................................................................................................................3

3. INSTRUCTION FOR USERS...........................................................................................................................4

4. INSTALLATION INSTRUCTION ....................................................................................................................5

BEFORE USING YOUR WINE CHILLER.........................................................................................................................................5

INSTALLATION OF YOUR WINE CHILLER .................................................................................................................................. 5

5.TROUBLE SHOOTING GUILDS.....................................................................................................................6

6. ELECTRIC DIAGRAM.....................................................................................................................................6

ENERGY SAVING TIPS....................................................................................................................................................................... 7

7. TECHNICAL DATA .........................................................................................................................................8

DATA SHEET......................................................................................................................................................................................... 8

EN - 2

1. INDICATION OF PARTS

1 Cabinet

2 Ventilation holes

3 Cold sink fan cover

4 Shelf (Total 4)

5 Leveling Legs

6 Upper Door Hinge w/ Cover

7 Door gasket

8 Glass door

9 Bottom hinge

CONTROL PANEL

You can select temperature display setting from Fahrenheit to Celsius degree by pushing

this button approximately for 3 seconds. The degrees will appear in blue color in the

temperature display window.

EN - 3

2. TEMPERATURE CONTROL

It is recommended you install the Wine Chiller in a place where the ambient temperature is between

23°-26°C/ 72°-78°F. If the ambient temperature is above or below recommended temperatures, the

performance of the unit may be aected. For example, placing your unit in extreme cold or hot conditions

may cause interior temperatures to uctuate. The range of 8°-18°C/46°-64°F may not be reached. The default

temperature set at the factory is 12°C / 54°F.

Recommended Temperatures for Chilling Wine.

Red Wines 14°-18° C 58- 64° F

Dry/White Wines 9° -14° C 48-58° F

Rose Wines 10°-11°C 50-52° F

Sparkling Wines 7°-9° C 45-48°F

Temperature Ranges For Your Wine Chiller

Upper Zone 8°-18° C 46- 64° F

Lower Zone 12° -18° C 54-64° F

SETTING THE TEMPERATURE CONTROL

• Upperzoneandbottomzoneareeachcontrolledseparatelywhenpress„SET“,theupperdisplaywillush

andcanchangetheupperzonetemperatureaccordingly,press„SET“again,thelowerdisplaywillush

andcanchangetthelowerzonetemperatureaccordingly.

• YourWineCellarhasbeenequippedwithan„automatic“controlpanellock,thatwillactivate12seconds

after the last time a button has been touched.

Push the and button simultaneously for 3 seconds to unlock the control panel. You will hear a

„BEEP“soundtoalertyouthatthecontrolisnowactive.

• Youcansetthetemperatureasyoudesirebypushingthe or button on the control panel for each

zone.Thetemperaturethatyoudesiretosetwillincrease1°For1°Cifyoupushthe button once, on

the contrary the temperature will decrease 1°F or 1°C if you push the button once.

Temperature settings applicable when storing mostly one type of wine:

Red Wines 14°-18° C 58- 64° F

White / Rose / Dry Wines 9° -14° C 48-58° F

Sparkling Wines 7°-9° C 45-48°F

EN - 4

3. INSTRUCTION FOR USERS

1. Note

1.1. Position your refrigerator so that the plug is accessible.

1. 2. Keep your refrigerator out of direct sunlight.

1.3. Do not place next to heat generating appliance.

1.4. Do not place directly on the ground. Provide suitable stand.

2. Very important:

2.1. The minibar will have better performance at ambient of 20-25 degree; We suggest the minibar be

powered o if the ambient temperature is lower than 10 degree.

2.2. After plugging the appliance, allow the unit to cool down for 2-3 hours before placing beverage into the

refrigerator compartment.

2.3. Ventilation is very important for this kind thermoelectric refrigerator; The inside PCB will be broken

easily if the ventilation is bad; It will also reduce the life of the refrigerator.

2.4. If leakage occurs (which can be easily detected due to the unpleasant smell), please

A. Switch o the minibar immediately

B. Ventilate the room thoroughly

C. Call for the after sales service department

2.5. This model uses a heat-pipe cooling system with automatic defrosting system, so there is no need to

defrost it manually.

3. Power supply:

3.1. The refrigerator must be connected to a properly earthed socket in line with relevant valid country

regulations before operating;

3.2. Checkthedatalabel(whichisonthesideoftherefrigerator)forvoltageandfrequencycorrespondsto

your local one; If not, don’t plug your cable into the socket;

4. Cleaning Your Refrigerator

• UNPLUGtherefrigerator,andremovetheshelf.

• Washtheinsidesurfaceswithawarmwaterandbakingsodasolution.Thesolutionshouldbeabout2

tablespoonsofbakingsodatoaquartofwater.

• Washtheshelfwithamilddetergentsolution.

• Theoutsideoftherefrigeratorshouldbecleanedwithmilddetergentandwarmwater.

• Wringexcesswateroutofthespongeorclothbeforecleaningtheareaofthecontrols,oranyelectrical

parts.

• Washtheoutsidecabinetwithwarmwaterandmildliquiddetergent.Rinsewellandwipedrywitha

clean soft cloth.

EN - 5

4. INSTALLATION INSTRUCTION

BEFORE USING YOUR WINE CHILLER

• Removetheexteriorandinteriorpacking.

• Checktobesureyouhaveallofthefollowingparts:

(4) Shelves

(1) Instruction manual

• CleantheInteriorsurfacewithlukewarmwaterusingasoftcloth.

INSTALLATION OF YOUR WINE CHILLER

• ThisWineChillerIsdesignedtobefreestandingInstallationonly,andshouldnotberecessedorbuilt-in

(Fully recessed).

• PlaceyourWineChilleronasurfacethatIsstrongenoughtosupportItwhenItIsfullyloaded.

• Allow5inchesofspacebetweenthebackandsidesofthewinechiller,whichallowstheproperair

circulation to cool the heat sink.

• LocatetheWineChillerawayfromdirectsunlightandsourcesofheat(stove,heater,radiator,etc).Direct

sunlight may aect the acrylic coating and heat sources may Increase electrical consumption. Extreme

cold ambient temperatures may also cause the unit not to perform properly.

• ThisWineChillerusessuperconductorrefrigerationtechnology(nocompressor)andIsnotdesignedfor

storage In hot areas like garages, warehouses or outdoors since it is designed to operate at a maximum of

30 degrees below the ambient temperature.

• Avoidlocatingtheunitinmoistareas.

• PlugtheWineChillerIntoanexclusive,properlyinstalled-groundedwalloutlet.Donotunderany

circumstancescutorremovethethird(ground)prongfromthepowercord.Anyquestionsconcerning

powerand/orgroundingshouldbedirectedtowardacertiedelectricianoranauthorizedAvanti

Products service center.

• AfterpluggingtheWineChillerintoawalloutlet,allowtheunittocooldownfor2-3hoursbeforeplacing

any items in the compartment.

EN - 6

5. TROUBLE SHOOTING GUILDS

PROBLEM POSSIBLE CAUSE

Wine Chiller does not operate or cool. Not plugged in.

The circuit breaker tripped or a blown fuse.

Control panel is locked Push the and button simultaneously for 3 seconds to

unlock the control panel. Wait for beep sound.

Wine Chiller is not cold enough. Check the temperature control setting.

Externalenvironmentmayrequireahighersetting.

The door is opened too often.

The door is not closed completely.

The door gasket does not seal properly.

The Wine Chiller does not have the correct clearances.

Abnormal voltage.

The light does not work. Not plugged in.

The circuit breaker tripped or a blown fuse.

Thelightbuttonis„OFF“.

Vibrations. Check to assure that the Wine Chiller is level.

The door will not close properly. The Wine Chiller is not level.

The door was not properly installed.

The gasket is dirty.

The shelves are out of position.

6. ELECTRIC DIAGRAM

PLUG

Cooling unit

EN - 7

ENERGY SAVING TIPS

The refrigerator should be located in the coolest area of the room, away from heat producing appliances,

and out of the direct sunlight. Overloading the refrigerator forces the superconductor cooling system to run

longer. Reduce door openings and extended searches, remove as many item as needed at one time, and

close the door as soon as possible. One characteristic of superconductor heat-pipe units is the length of time

itrequirestorecoverfromhavingthedooropenedandshutfrequently.Itmaybenecessarytowaitlonger

for the temperature to return to its former level once the door has been opened for too long. This is normal

for the type of unit. Superconductor heat-pipe technology costs just pennies to operate. It is environmental

friendly due to the lack of CFC’s.

Warning

• Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,itsserviceagentorsimilarly

qualiedpersonsinordertoavoidahazard.

• Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryor

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety.

• Childrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.

• WARNING:Toavoidahazardduetoinstabilityoftheappliance,itmustbexedinaccordancewiththe

instruction.

EN - 8

7. TECHNICAL DATA

DATA SHEET

DATA SHEET: Philco

Philco trademark:

Brand: Philco

Model name PW 24 FD

Appliance category 3) 10

Energy eciency class (A… low electricity consumption to G…

high electricity consumption)

Energy consumption over a 365 day period 1) (kWh) 216

Energy consumption (kWh/24h) 0,593

Total usable volume (l) 70

of that: refrigerating section volume (l) 70

ofthat:freezersectionvolume(l) 0

Cooling performance (temperature range) upperzone:8-18°C/46-64°F,

bottomzone:12-18°C/54-64°F

Numberoftemperaturezones 2

Number of bottles 24

Inner humidity 50-80%

Climate class 2) N

Installation Free-standing

Voltage 220-240v/50Hz

Noise level 4) (dB) (re 1pW) 33

Dimensions (mm) (H x W x D) 430 x 520 x 740

Weight (kg) 19,5

This appliance is designed exclusively for storing wine

1) AnnualenergyconsumptioninkWh/yearisbasedontheresultsofanormalized24hr.test.

The actual energy consumption depends on usage conditions and location of the appliance.

2) SN: ambient temperature from +10 °C to +32 °C

ST: ambient temperature from +18 °C to +38 °C

N: ambient temperature from +16 °C to +32 °C

3) 1=Refrigeratorwithoutfreezersections

2 = The appliance is intended for storing wine

 7=Refrigerator/freezerwithfreezersections*(***)

 8=Uprightfreezer

4) Noise level according to the European standard EN 60704.

*FS-free-standingappliance

BI - built-in appliance
