Phantomgogo A8 Manual de usuario
USER MANUAL
A8 Electric Scooter
1
Contents
Product Features.................................................................. 2
Accessories
......................................................................... 2
Specifications
...................................................................... 3
Assembly............................................................................. 3
Charger Your Scooter............................................................ 4
How To Ride...................................................................... 5
Folding.................................................................................. 6
Unfolding............................................................................... 6
Phantomgogo APP ......... ..................................................... 7
Safety Precautions.............................................................. 8
Cleaning And Storage................................................... 12
..................................................12
Battery Maintenance..........................................................12
Environmental Protection.................................................. 13
After-sales Service............................................................. 14
Non-warranty Rule.............................................................. 14
Warranty Content.............................................................. 14
User Stub............................................................................ 15
Manufacturer Stub.............................................................. 16
Fault Code.......................................................................... 17
2
Accessories
Power Adapter T-shape
Allen Key Screw
Service Card
User Manual
Product Features
Brake lever
Front tube
Handlebar
Charging port
Atmosphere light
Motor unit
Folding hook
Accelerator
Folding handle
Function mode: Cruise mode, Pedestrian mode, Error prompt,
Light, Bluetooth, Lock.
Gear mode: The maximum speed limit is 3.8 mph for Gear L,
5.8 mph for Gear M and 15.5 mph for Gear H.
Speedometer : Remaining mileage will be displayed within
the first 6 seconds after powering on; the current speed is
displayed afterwards.
Battery indicator: Displays the remaining battery power;
flashes red when the power is 10%.
Switch button:
Press to turn on, press and hold for 3 seconds
to shut down. When powered-on, press once to turn the light
on/off, and press twice to switch the gear mode.
3
Specifications
Assembly
1. Pull the folding handle upwards until an audible click is heard,
then pull the folding handle confirming the lock is in place.
2. Manually connect the handlebar and data cable in the front tube.
Once connected, check if the scooter powers on normally.
3. Use the included 6 screws to fasten the handlebars. Further
tighten the screws by using the T-shape allen key.
2 3
1
Model A8
Net weight 33 lbs
Unfolded size 45.5×7.5×19 inch
Recommended age 12+
Recommended height 51~78 inch
Maximum load 220 lbs
Maximum speed 15.5 mph
Mileage 28 miles
Gradeability About 15%
Waterproof certification IPX5
Charging time About 5.5 hours
BMS management Over-charge, Over-temperature, Over-discharge,
Over-current, Short circuit, Over-voltage
Brake system Manual disc brake + Electronic brake
Tire size 9-inch puncture-proof tubeless tires
4
Attention:
●Only use the original power adapter when charging.
●Keep away from children and animals when charging, and keep away from
●Do not charge or use the battery if it emits a peculiar smell, overheats or leaks.
●Do not open the battery pack or insert anything into the charging port as the
battery contains dangerous substances.
●
dry place, and fully charge it every 30 days.
Charge Your Scooter
1. The indicator light of the charger turns green when the
scooter is connected to the power supply.
2. When actively charging, the light should switch to red from
green.
3. After charging, the indicator light should switch back to green.
Plug the power adapter
into the charging port
Fasten the rubber
5
How To Ride
1. Press the Switch button to turn the scooter on and check the
battery level. If the battery level is too low, please charge it
before riding.
2. Stand with one foot on the baseboard and kick off against
the ground with your other foot. The motor is active once the
speed of the scooter exceeds 2.5 mph.
3. While riding, place the other foot on the pedal and lightly
press the accelerator to engage the motor.
4. When steering or decelerating, release the accelerator and
use the brake lever to brake.
6
Folding
folding handle; fold the front tube clamp, align the folding hook
and put it into the hook fixing buckle; lift the front tube and
Unfolding
Press the red button on the folding hook to remove the hook
from the folding retaining buckle, straighten the front tube, close
7
Phantomgogo APP
Scan QR code with your mobile phone to download and install the APP.
If the APP has been installed on your mobile phone, make sure
that the APP is the latest.
STEP 1
Press the button to turn on the scooter and then turn on the
Bluetooth function of your mobile phone.
Open the Phantomgogo APP. Please register/log in to your account
according to the app instructions.
STEP 2
APP
STEP 3
On the APP homepage, select “Search the binding”. The
according to the prompt in the APP interface.
Zero Start / Non-zero Start Mode
1. Zero Start Mode:
.
2. Non- zero Start Mode:
After startup, the accelerator can be started only when the initial
speed is ≥2.5 mph with the help of feet.
3. The factory default of scooter is non-zero start mode.
8
Safety Precautions
1. Please carefully read the User Manual, which will assist in
explaining the basic working principles and provide tips on how
to best enjoy your scooter experience.
2. Please wear all appropriate safety and protective gear as
previously mentioned in the User Manual before operating the
scooter.
3. Always wear shoes, make sure to wear comfortable clothes.
4. Do not use any accessories or additional items not approved
by the manufacturer with the scooter. Do not try to open or
modify your scooter, as doing so will void your manufacturer
warranty, and may cause failure to your device leading to
serious bodily injury or death.
5. WARNING! Keep plastic covering away from children to avoid
and/or alcohol.
7. Do not operate the scooter when you are restless or sleepy.
8. Use your best judgment to keep yourself out of dangerous
situations with your scooter.
9. The scooters have a range of about 28miles and a maximum
speed of 15.5mph.
10. Do not turn sharply, especially at high speeds.
11. Do not abuse your scooter, doing so can damage your unit
and cause failure to the operating system leading to injury.
12. Do not drive in or near puddles of water, mud, sand, stones,
gravel, debris or near rough and rugged terrain.
even. If you encounter uneven pavement, please lift your
scooter over and past the obstruction.
14. Do not ride in dangerous weather: snow, rain, hail, sleek, on
icy roads or in extreme heat.
15. Do not ride in or near pools or other large bodies of water.
16. Traffic in the city has many obstacles to cross such as curbs
or steps. It is important to anticipate and adapt your trajectory
and speed to those of a pedestrian before crossing these
obstacles. It is also recommended to get out of the vehicle when
these obstacles become dangerous due to their shape, height or
slippage.
9
17. Do not attempt to ride over bumps or objects greater than 0.6
inch even when prepared and bending your knees.
18. PAY ATTENTION - look to where you are riding and be
attentive of the road conditions, people, places, property and
objects around you.
19. Do not operate the scooter in crowded areas.
20. Operate your scooter with extreme caution when indoors,
especially around people, property, and
narrow spaces like
doorways.
21.
Pay special precautions in dark environments; becareful
not to touch the brake disc.
22. Do not operate the scooter while talking, texting, or looking
at your phone.
23. Do not ride your scooter where it is not permitted.
24. Do not ride your scooter near motor vehicles or on public
roads.
25. Do not climb or travel down steep hills with your scooter.
26. The scooter is intended for use by a single individual, do not
attempt to operate the scooter with two ormore people. Donot
carry anything while riding the scooter.
27.
People who lack balance should not attempt to operate a
scooter.
28.
Women who are pregnant or are preparing for pregnancy
should not operate the scooter.
29. Young children and the elderly should not operate the
scooter without proper instruction and supervision from a
30. At higher speeds, always take into consideration longer
stopping distances.
certified scooter trainer.
31
32
. Do not step forward off your scooter.
33. Do not attempt any stunts or tricks with your scooter.
34. Do not ride the scooter in dark or poorly lit areas.
